INSTALLATION MANUAL
ID TITANIUM SERIES 6 - SLIDING

Advertisement

loading
Need help?

Need help?

Do you have a question about the ID TITANIUM 6 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Haier ID TITANIUM 6 Series

  • Page 1 INSTALLATION MANUAL ID TITANIUM SERIES 6 - SLIDING...
  • Page 2 PRESERVE LIFE’S FLAVOUR EN | IT...
  • Page 5 WELCOME This installation manual is designed for kitchen manufacturers who will deal with these products. To ensure safety and get the best results, please read this manual carefully, including the safety instructions, and keep it for future reference. Before proceeding with the installation, take note of the serial number, as you may need it in case of re- pairs.
  • Page 6 index Safety warnings for installation Where to install the product Refrigerator dimensions Installation tools Cabinet dimensions Precautions Dimensions Cabinet installation and ventilation p.10 Installation in column Installation video step by step p.11 Change the direction of door opening p.12 Unlocking the doors Removing the bottom screw Hinges inversion Attaching the bottom screw on the opposite side of the refrigerator...
  • Page 7 index Connection to the mains p.28 10.1 Warnings 10.2 Other advices Delivery to the user p.30 Disassemble the product p.30...
  • Page 8 Safety warnings for installation Observe these directions before beginning the installation of the product. Please observe the following guidelines before starting the installation of the product. Your safety is very important to us. Read these instructions carefully be- fore using the product. The installation must be carried out by a qualified technician who is familiar with and ●...
  • Page 9 Where to install the product Important warnings Do not install the appliance in areas exposed to direct sunlight to avoid altering the ● product's performance; Install and use this product in an enclosed, covered, dry, and well-ventilated environment; ● Do not install the product in outdoor areas exposed to weather elements; ●...
  • Page 10 Refridgerator dimensions Dimensions in mm Front axonometric view Rear axonometric view cable length 2270mm Models A(mm) B(mm) C(mm) D(mm) E(mm) F(mm) G(mm) HBW7518C HBW7518DT 540±2 550±2 1772±2 HBW7518BT HBW7518CTK HBW7519C 540±2 550±2 1935±2 1133 HBW7519DT HBW7719C 690±2 550±2 1935±2 1133 HBW7719DT...
  • Page 11 Refridgerator dimensions Dimensions in mm Side view Side view with doors closed with doors open Top view Top view with doors closed with doors open 550±2 550±2 Product codes HBW7518C HBW7518BT HBW7519C HBW7719C HBW7518DT HBW7518CTK HBW7519DT HBW7719DT...
  • Page 12: Cabinet Dimensions

    Installation tools Tools needed phillips flathead gloves tape measure screwdriver screwdriver screwdriver box cutter scissors wire cutters square level Accessories provided Cabinet dimensions Precautions Provide the built-in compartment without a back wall; ● For product ventilation, follow the instructions in this manual; ●...
  • Page 13 Cabinet dimensions Dimensions in mm Front axonometric view with doors open socket presa max 2100mm Models A(mm) B(mm) C(mm) D(mm) E(mm) Remark Min. 1778 HBW7518C HBW7518DT Recommended 1780 HBW7518BT HBW7518CTK Max. 1782 Min. 1941 HBW7519C Recommended 1943 Hinges: 17mm HBW7519DT Max.
  • Page 14 Cabinet installation and ventilation Installation in column Side section Side section min. 50 min. 200 cm2 min. 200 cm2 min. 200 cm2 min. 200 cm If it is not possible to create an opening in the base- board, find an alternative solution to ensure proper air circulation.
  • Page 15 Installation video step by step You can view the product installation video by scanning the Qr Code. or by clicking this link...
  • Page 16 Change the direction of door opening 8.1 Unlocking the doors Loosen the screw 5mm ,push down the gasket blocks to re- move them , discard them (not the screws because you will need them in a later stage). 8.2 Removing the bottom screw Remove the screw as shown in the diagram and keep it for the step 8.4.
  • Page 17 Change the direction of door opening NOTE: Follow the following instructions only if it is necessary to reverse the direc tion of door opening; otherwise, proceed to the next paragraph (page 16). Hinges inversion Rotate the hinges 180° and mount them as shown in the diagram. Attaching the bottom screw on the opposite side of the refrigerator Tighten the screw (of the step 8.2) on the opposite side of the refrigerator as shown in the diagram.
  • Page 18 Change the direction of door opening Securing the upper trim panel Disassemble the upper trim panel and reposition the sensor, as shown in the diagram. Rotate the trim panel 180° and secure the sensor on the inside.
  • Page 19 Installation instructions for the refrigerator Before proceeding, if you have not completed step 8.1 yet, do it now. Applying the top installation bar of the refrigerator Insert the top installation bar of the refrigerator fol- lowing the existing guides. Applying the spacer at the back of the refrigerator Apply the spacer at the back of the refrigerator as shown in the diagram.
  • Page 20 Installation instructions for the refrigerator Applying the wadhesive spacers on the side of the refrigerator On the side opposite to the hinges, place the adhesive spac- ers after removing the protec- tive film.
  • Page 21 Installation instructions for the refrigerator 9.4 Centering the refrigerator feet Install the centering gauges for the feet on the bottom of the cabinet using the provid- ed screws. Remove any excess parts as shown in the diagram.
  • Page 22 Installation instructions for the refrigerator WARNING: before inserting the refrigerator into the cabinet, thread the power cord through and temporarily secure it on top with tape. Then, lift the product with two people and insert it into the recess, taking care not to damage the power cord. Ensure that the outlet must be freely accessible.
  • Page 23 Installation instructions for the refrigerator Built-in installation The top installation bar should rest against the shelf of the cabinet. Allow a tolerance of 3 mm between the refrig- erator and the cabinet on the side opposite to the hinges. 3 mm...
  • Page 24 Installation instructions for the refrigerator 9.6 Securing the refrigerator feet Remove the fin from the foot centering component. Adjust to the desired height and secure the refrigerator feet to the cabinet using the provided screws.
  • Page 25 Installation instructions for the refrigerator 9.7 Mounting the central brackets and covers Using the provided screws, attach the bracket on the refrigerator's opening side. Remove the positioning fin. Finally, place the cover.
  • Page 26 Installation instructions for the refrigerator 9.7 Mounting the central brackets and covers Using the provided screws, attach the bracket on the side opposite to the hinges. Remove the positioning fins. Finally, place the cover.
  • Page 27 Installation instructions for the refrigerator 9.8 Mounting the bottom covers Apply the three bottom covers, securing them as shown in the diagram.
  • Page 28 Installation instructions for the refrigerator 9.9 Applying gaskets on the side of the refrigerator Cut the gaskets to size and apply them to the side of the refrigerator, on the side opposite to the hinges.
  • Page 29 Installation instructions for the refrigerator 9.10 Mounting the top covers and securing the refrigerator to the upper shelf Using the provided screws, secure the upper front panel to the cabinet shelf and cover the upper hinge with the cover.
  • Page 30 Installation instructions for the refrigerator 9.11 Attaching the sliding hinges to the cabinet door Before starting, ensure that both the cabinet door and the refrigerator door are per- fectly open at 90 degrees. Unscrew the previously tightened screws on the doors and attach the rollers to the refrigerator doors.
  • Page 31 Installation instructions for the refrigerator 9.11 Attaching the sliding hinges to the cabinet door Using a screwdriver, secure the rollers to the cabinet doors. Then, remove the guides as shown in the diagram.
  • Page 32: Connection To The Mains

    Connection to the mains 10.1 Warnings To safely perform the electrical connection of the appliance, observe the following warnings: Any repair, installation, and maintenance not performed correctly can seriously en- ● danger the user; The manufacturing company declares no responsibility for direct or indirect damag- ●...
  • Page 33 Connection to the mains Ensure that the main cable is not caught under the appliance during and after ● transportation/movement, to prevent the main cable from being cut or damaged. If the power cord of the appliance should be damaged, do not proceed with the installation and contact service;...
  • Page 34 Deliver to the user At the end of installation: Inform the user about essential functions; ● Inform the user about all aspects relevant to safe use and handling; ● Deliver accessories and instructions for use and assembly to the user to be kept ●...
  • Page 37 BENVENUTI Questo manuale di installazione è pensato per i produttori delle cucine che accoglie- ranno questi prodotti. Per garantire la sicurezza e ottenere i migliori risultati, leggere attentamente questo manuale, comprese le istruzioni di sicurezza, e conservarlo per riferimenti futuri. Prima di procedere con l’installazione, prendere nota del numero di serie, in quanto potrebbe essere necessario in caso di riparazioni.
  • Page 38 indice Avvisi di sicurezza per l’installazione p.36 Dove installare il prodotto p.37 Dimensioni frigorifero p.38 Strumenti per l'installazione p.40 Dimensione del mobile p.40 Precauzioni Dimensioni Mobili e ventilazione p.42 Installazione in colonna Video di installazione step by step p.43 Cambiare il verso di apertura delle ante p.44 Sblocco delle ante Rimozione della vite in basso...
  • Page 39 indice Connessione alla rete elettrica p.60 Avvertenze 10.1 Altri consigli 10.2 Consegna all'utente p.62 Smontaggio del prodotto p.62...
  • Page 40 Avvisi di sicurezza per l'installazione Osservare le presenti indicazioni prima di iniziare l’installazione del prodotto. La vostra sicurezza è molto importante per noi. Leggere attentamente queste informazioni prima di utilizzare il prodotto. L’installazione deve essere effettuata da un tecnico qualificato che deve conoscere e ●...
  • Page 41 Dove installare il prodotto Avvertenze importanti Non installare l’elettrodomestico in punti in cui risulterebbe esposto alla luce sola- ● re diretta al fine di non alterare le prestazioni del prodotto; Installare e utilizzare questo prodotto in un ambiente chiuso, coperto, asciutto e ●...
  • Page 42 Dimensioni frigorifero Dimensioni in mm Vista assonometrica frontale Vista assonometrica posteriore Lunghezza cavo 2270mm Modelli A(mm) B(mm) C(mm) D(mm) E(mm) F(mm) G(mm) HBW7518C HBW7518DT 540±2 550±2 1772±2 HBW7518BT HBW7518CTK HBW7519C 540±2 550±2 1935±2 1133 HBW7519DT HBW7719C 690±2 550±2 1935±2 1133 HBW7719DT...
  • Page 43 Dimensioni frigorifero Dimensioni in mm Vista laterale Vista laterale con ante chiuse con ante aperte Vista superiore Vista superiore con ante chiuse con ante aperte 550±2 550±2 Codici prodotto HBW7518C HBW7518BT HBW7519C HBW7719C HBW7518DT HBW7518CTK HBW7519DT HBW7719DT...
  • Page 44 Strumenti per l'installazione Strumenti necessari cacciavite cacciavite guanti metro avvitatore a croce a taglio taglierino forbici tronchesi squadra livella Strumenti forniti con il prodotto Dimensioni del mobile Precauzioni Prevedere il vano incasso senza parete posteriore; ● Per la ventilazione del prodotto seguire le istruzioni riportate in questo manuale; ●...
  • Page 45 Dimensioni del mobile Dimensioni in mm Vista assonometrica frontale con ante aperte presa presa max 2100mm Modelli A(mm) B(mm) C(mm) D(mm) E(mm) Nota Min. 1778 HBW7518C HBW7518DT Consigliato 1780 HBW7518BT HBW7518CTK Max. 1782 Min. 1941 HBW7519C Consigliato 1943 Cerniere: 17mm HBW7519DT Max.
  • Page 46 Mobili e ventilazione Installazione in colonna Sezione laterale Sezione laterale min. 50 min. 200 cm2 min. 200 cm2 min. 200 cm2 min. 200 cm Nel caso in cui non fosse possibile praticare un'aper- tura nello zoccolo, trovare una soluzione alternativa per garantire la circolazione dell'aria.
  • Page 47 Video di installazione step by step È possibile visionare il video dell'installazione del prodotto scansionando il Qr Code. oppure cliccando al seguente link...
  • Page 48 Cambiare il verso di apertura delle porte 8.1 Sblocco delle porte Allentare la vite di 5 mm, spin- gere verso il basso i blocchi di guarnizione per rimuoverli, scartarli (non le viti perché ser- viranno in una fase successiva). 8.2 Rimozione della vite in basso Rimuovere la vite come mo- strato nel disegno e conservala per il passaggio 8.4.
  • Page 49 Cambiare il verso di apertura delle porte NOTE: seguire le seguenti indicazioni solo se risulta necessario invertire il verso d’apertura delle porte, altrimenti passare al paragrafo successivo (pag.16). Inversione delle cerniere Ruotare le cerniere di 180° e montarle come da disegno. Fissaggio della vite in basso sul lato opposto del frigorifero Avvitare la vite (del passaggio 8.2) sul lato opposto del frigorifero come da disegno.
  • Page 50 Cambiare il verso di apertura delle porte Fissaggio della mascherina superiore Smontare la mascherina superiore e riposizionare il sensore, come da disegno. Ruotare la mascherina di 180° e fissare il sensore nella parte interna.
  • Page 51 Indicazioni relative all'installazione del frigorifero Prima di proseguire, se non hai eseguito il passaggio 8.1 prima, eseguilo adesso. 9.1 Applicazione del frontalino sulla parte superiore del frigorifero Inserire il frontalino sulla sommità del frigorifero se- guendo le guide presenti. Applicazione del distanziale sul retro del frigorifero Applicare il distanziale sul retro del frigorifero come da disegno.
  • Page 52 Indicazioni relative all'installazione del frigorifero Applicazione dei distanziali adesivi sul laterale del frigorifero Sul lato opposto a quello delle cerniere posizionare i distanzia- li adesivi, una volta rimossa la pellicola di protezione.
  • Page 53 Indicazioni relative all'installazione del frigorifero 9.4 Centraggio dei piedi del frigorifero Installare le dime di centraggio dei piedi sul fondo del mobile utilizzando le viti in dota- zione. Rimuovere le parti in eccesso come da disegno.
  • Page 54 Indicazioni relative all'installazione del frigorifero ATTENZIONE: prima di inserire il frigorifero nel mobile, far passare il cavo di alimentazione all'interno e fissarlo temporaneamente sulla sommità con del nastro adesivo. In seguito, sollevare il prodotto in due persone ed inserirlo nel vano incasso, facendo attenzione a non danneggiare il cavo di alimentazione.
  • Page 55 Indicazioni relative all'installazione del frigorifero 9.5 Incasso Il frontalino del frigorifero deve andare in battuta sul ripiano del mobile. Considerare una tolleranza di 3 mm tra frigo- rifero e mobile sul lato opposto a quello delle cerniere. 3 mm...
  • Page 56 Indicazioni relative all'installazione del frigorifero 9.6 Fissaggio dei piedi del frigorifero Eliminare l'aletta del componente del centraggio dei piedi. Regolare l'altezza desiderata e, utilizzando le viti in dotazione, fissare i piedi del frigorifero al mobile.
  • Page 57 Indicazioni relative all'installazione del frigorifero 9.7 Montaggio delle staffe centrali e cover Utilizzando le viti in dotazione, fissare la staffa dal lato di apertura del frigorifero. Rimuovere l'aletta di posizionamento. Infine, posizionare la cover.
  • Page 58 Indicazioni relative all'installazione del frigorifero 9.7 Montaggio delle staffe centrali e cover Utilizzando le viti in dotazione, fissare la staffa sul lato opposto alle cerniere. Rimuovere le alette di posizionamento. Infine, posizionare la cover.
  • Page 59 Indicazioni relative all'installazione del frigorifero 9.8 Montaggio delle cover inferiori Applicare le tre cover inferiori, fissandole come da disegno.
  • Page 60 Indicazioni relative all'installazione del frigorifero 9.9 Applicazione delle guarnizioni sul lato del frigorigero Tagliare su misura le guarnizioni e applicarle sul fianco del frigorifero, sul lato opposto a quello delle cerniere.
  • Page 61 Indicazioni relative all'installazione del frigorifero 9.10 Montaggio delle cover superiori e fissaggio del frigorifero al ripiano superiore Utilizzando le viti in dotazione, fissare il frontalino superiore al ripiano del mobile e coprire la cerniera superiore con la cover.
  • Page 62 Indicazioni relative all'installazione del frigorifero 9.11 Fissaggio delle cerniere sliding all'anta del mobile Prima di cominciare, assicurarsi che le ante del mobile e del frigorifero siano aperte perfettamente a 90°. Svitare le viti precedentemente av- vitate sulle ante e applicare i carrelli alle porte del frigorifero.
  • Page 63 Indicazioni relative all'installazione del frigorifero 9.11 Fissaggio delle cerniere sliding all'anta del mobile Con l'ausilio di un avvitatore, fissare i carrelli alle ante del mobile. Successivamente, rimuovere le guide come da disegno.
  • Page 64: Connessione Alla Rete Elettrica

    Connessione alla rete elettrica 10.1 Avvertenze Per eseguire il collegamento elettrico dell’apparecchio in sicurezza, osservare le seguenti avvertenze: Qualsiasi riparazione, installazione e manutenzione non eseguita correttamente ● può mettere seriamente in pericolo l’utente; L’azienda produttrice dichiara di non assumersi alcuna responsabilità per danni di- ●...
  • Page 65 Connessione alla rete elettrica Accertarsi che il cavo di rete non sia impigliato sotto l’elettrodomestico durante ● e dopo il trasporto/spostamento, per evitare che il cavo di rete venga tagliato o danneggiato. Se il cavo di alimentazione dell’elettrodomestico dovesse essere dan- neggiato, non procedere con l’installazione e rivolgersi all’assistenza;...
  • Page 66 Consegna all'utente A conclusione dell'installazione: Informare l’utente circa le funzioni essenziali; ● Informare l’utente su tutti gli aspetti rilevanti per la sicurezza dell’uso e della ma- ● nipolazione; Consegnare all’utente gli accessori e le istruzioni per l’uso e il montaggio da con- ●...
