General hazard information:
• The screws for mounting the TV must not be too long, otherwise the TV could be
damaged inside.
• Please ensure that the cables are not damaged during installation. Damaged cables must
be replaced immediately to avoid short circuits.
• Screws must always be screwed in straight way. Please do not damage the threads of
the screws, otherwise the stability of the product cannot be guaranteed.
• Observe the weight limit of the respective TV mount as specified:
raumobjekte.de
• TV mounts are not suitable as children's toys (damage to the product and risk of injury
can be the result of improper handling)
• Claims for damage or possible warranty claims due to incorrect installation or incorrect
handling cannot be made to the manufacturer.
• Products made of glass: observe the weight limit at
www.wissmann-raumobjekte.de.
Caution, glass is brittle and splinters if tilted. Always place on soft surfaces. Broken or
splintered glass is a risk of accidents and should therefore be disposed of immediately.
• TV mounts with wheels: replace stiff wheels to avoid damage to soft wooden floors.
• TV mounts with a rotating function: To prevent damage to the cables due to
tension, insert them loosely so that the cables are not pulled too tightly when the
TV is rotated. To avoid chafing of the cables, use the spiral cover as cable
protection at the cable entry.
• TV mounts with a rotating function: If a rotation axis is stiff (TV can hardly be
rotated or cannot be rotated at all), please stop using the product and contact the
manufacturer immediately: info@wissmann-raumobjekte.de
• TV mounts for wall mounting: our dowels are not suitable for all types of walls.
Therefore, only use dowels suitable for your wall.
• TV mounts for wall mounting: If the wall holes were drilled too large, be sure to use
larger dowels or alternatively adhesive dowels.
• TV mounts for wall mounting: The load-bearing capacity of the wall must be
ensured by the user (the upper screws of the wall bracket bear the weight of the TV
under tensile load)
www.wissmann-
Advertisement
Related Manuals for wissmann Solution art128-0
Summary of Contents for wissmann Solution art128-0
- Page 1 • TV mounts with a rotating function: If a rotation axis is stiff (TV can hardly be rotated or cannot be rotated at all), please stop using the product and contact the manufacturer immediately: info@wissmann-raumobjekte.de • TV mounts for wall mounting: our dowels are not suitable for all types of walls.
- Page 2 Installation instruction: TV mount solution art128-0 Before starting the assembly please read these instructions with patience and follow step by step. I.) Wall fixation (Time needed: approx. 20 min.) The vertical column can be placed either on the right or left-hand side of the TV.
- Page 3 5) Pull the axle (Fig 3, green arrow) out of the socket (Fig 3, red arrow) on the end of the extension arm. Fig. 3 6) Bring the cover shell over the extension arm (Fig 4) up to the wall bracket Please note: The film on the extension arm acts a scratch protector.
- Page 4 II.) Mounting of the flat screen 1) Assemble the flat profiles attached, length 620mm (24,4 inches) horizontal backwards on to the flat screen. There are two threads on the upper profile (Fig 5, red arrow). Note: The screws attached may be too short and must be replaced with longer screws. When fitting the TV-Bracket, washers are to be used.
- Page 5 4) Bring the cable out of the black cable holder into the vertical cover shell and then mount the cover shell to cover the cable. Fig. 7 Note: As the bracket art128 Size 0 is designed for smaller TV’ s, there is space for a maximum of 2 to 4 cables (depending on the diameter of the cables).
