- Page 1 USER MANUAL English ICE1000-1CH MONO SoundImpress – because the best is just about good enough.
- Page 2 • XLR and RCA input, binding posts output systems to ultrahigh-fidelity replay systems • Assembled by hand in the Netherlands for studio and home use. The SoundImpress • 5 year Warranty brand stands for outstanding quality, timeless designs, and Dutch craftsmanship.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION SAFETY INSTRUCTIONS WARRANTY TERMS DISPLAY OF CONTROL FUNCTIONS GET STARTED SPECIFICATIONS... - Page 4 ICE1000-1CH SoundImpress ICE1000 Mono Amplifier 1000WPC | Powered by ICEpower State-of-the-art, high efficiency amplification This SoundImpress ICE1000-1CH is a fully All SoundImpress amplifiers are hand assembled integrated, intelligent amplifier, designed for in the Netherlands. The custom milled aluminum a wide range of audio applications, ranging...
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS SAVE THESE SAFETY REQUIREMENTS FOR FUTURE REFERENCE. HEED ALL WARNINGS AND SAFETY REQUIREMENTS MARKED IN THIS MANUAL AND ON THE AMPLIFIER. OBJECTS AND LIQUIDS - Never push objects C LEANING Unplug this product from the of any kind into this product as they may touch electrical outlet before cleaning. -
Page 6: Warranty Terms
WARRANTY TERMS LIMITED WARRANTY - Sound Imports warrants this device for a period of five years after the original date of purchase against defects due to faulty workmanship or materials arising from Normal Use of the device. The warranty covers working parts that affect the function of the device. It does NOT cover cosmetic deterioration caused by fair wear and tear, or damage caused by accident, misuse or neglect. -
Page 7: Display Of Control Functions
DISPLAY OF CONTROL FUNCTIONS Balanced input On / off switch Channel output (+) Fuse tray ' Channel output (-) Power input " The fuse is supplied as standard. When replacing it, only use the original value. " Attention: Risk of electric shock. I C E 1 0 0 0 - 1 C H | P a g e... - Page 8 DISPLAY OF CONTROL FUNCTIONS Front panel with engraved logo Dimmable LED indicator Bottom view Switch for LED indicator ' See the next page for an explanation of the LED switch. I C E 1 0 0 0 - 1 C H | P a g e...
- Page 9 DISPLAY OF CONTROL FUNCTIONS 0 --- LED OFF 1 --- Normal brightness 2 --- Max brightness I C E 1 0 0 0 - 1 C H | P a g e...
-
Page 10: Get Started
GET STARTED START - Before turning on your new amplifier, first make all connections. Ensure that the volume on your pre-amplifier or playback device is set to a minimum. CONNECTION - The ICE1000-1CH has one set of speaker connections. Connect the speaker terminals marked “+”... -
Page 11: Specifications
SPECIFICATIONS Rated power output (RMS) 1x 1000 watts at 4 ohms 1x 525 watts at 8 ohms Minimum load 2 ohms Signal-to-noise ratio (SNR) 117 dB Distortion 0.003 % THD+N Efficiency Frequency response 20 Hz to 20 kHz Circuit Topology ICEpower Amplifier classification Class D... - Page 12 SoundImports Peizerweg 97A 9727AJ Groningen Nederland Tel: +3185-0711860 E-mail: info@soundimports.nl Btw-nummer: NL861325254B01 KvK-nummer: 78268753...
