- Page 1 USER MANUAL English HY502-4CH QUAD SoundImpress – because the best is just about good enough.
- Page 2 I N T R O D U C I N G HY502-4CH SoundImpress HY502-4CH Quad 500WPC | Ncore® | Powered by Hypex This SoundImpress amplifier is a self- • Ncore® technology contained high-end class-D four channel • Impressive performance despite load ...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION SAFETY INSTRUCTIONS WARRANTY TERMS DISPLAY OF CONTROL FUNCTIONS GET STARTED SPECIFICATIONS... - Page 4 0.0018%. tiniest of details in every recording. An amplifier is only as good as the power supply All SoundImpress amplifiers are hand assembled it contains. In this SoundImpress amplifier, in the Netherlands. The custom milled aluminum...
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS SAVE THESE SAFETY REQUIREMENTS FOR FUTURE REFERENCE. HEED ALL WARNINGS AND SAFETY REQUIREMENTS MARKED IN THIS MANUAL AND ON THE AMPLIFIER. OBJECTS AND LIQUIDS - Never push objects C LEANING Unplug this product from the of any kind into this product as they may touch electrical outlet before cleaning. -
Page 6: Warranty Terms
WARRANTY TERMS LIMITED WARRANTY - Sound Imports warrants this device for a period of five years after the original date of purchase against defects due to faulty workmanship or materials arising from Normal Use of the device. The warranty covers working parts that affect the function of the device. It does NOT cover cosmetic deterioration caused by fair wear and tear, or damage caused by accident, misuse or neglect. -
Page 7: Display Of Control Functions
DISPLAY OF CONTROL FUNCTIONS Channel output (+) On / off switch Channel output (-) Power input ' Balanced input Fuse tray " Attention: Risk of electric shock. " The fuse is supplied as standard. When replacing it, only use the original value. H Y 5 0 2 - 4 C H | P a g e 7... - Page 8 DISPLAY OF CONTROL FUNCTIONS Front panel with engraved logo Dimmable LED indicator Bottom view Switch for LED indicator ' See the next page for an explanation of the LED switch. H Y 5 0 2 - 4 C H | P a g e 8...
- Page 9 DISPLAY OF CONTROL FUNCTIONS 0 --- LED OFF 1 --- Normal brightness 2 --- Max brightness H Y 5 0 2 - 4 C H | P a g e 9...
-
Page 10: Get Started
GET STARTED START - Before turning on your new amplifier, first make all connections. Ensure that the volume on your pre-amplifier or playback device is set to a minimum. CONNECTION - The HY502-4CH has four sets of speaker connections. Connect the speaker terminals marked “+”... -
Page 11: Specifications
SPECIFICATIONS Rated power output (RMS) 4 x 500 watts at 4 ohms 4 x 350 watts at 8 ohms Minimum load 4 ohm Signal-to-noise ratio (SNR) 124 dB Distortion 0.0018% THD+N (20-20,000 Hz at 0.5 x rated power output) Efficiency Frequency response 10 - 48,000 Hz Circuit Topology... - Page 12 Do you wish to read this manual in a different language? Or prefer a digitial version? Scan the QR code! SoundImports Peizerweg 97A 9727AJ Groningen Nederland Tel: +3185-0711860 E-mail: info@soundimports.nl Btw-nummer: NL861325254B01 KvK-nummer: 78268753...
