- Page 1 Neousys Technology Inc. NRU-170-PPC Series User Manual Revision 1.0...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Table of Contents ........................2 Legal Information ........................4 Contact Information ....................... 5 Notices ............................ 6 Safety Precautions ......................... 7 Service and Maintenance ...................... 8 ESD Precautions ........................8 About This Manual ......................... 9 Introduction NRU-171V-PPC Specification .................. - Page 3 Accessing the Port ....................50 Reflash/ Recovery ....................51...
-
Page 4: Legal Information
Legal Information Legal Information All Neousys Technology Inc. products shall be subject to the latest Standard Warranty Policy. Neousys Technology Inc. may modify, update or upgrade the software, firmware or any accompanying user documentation without prior notice. Neousys Technology Inc. will provide access to these new software, firmware or documentation releases from download sections of our website or through our service partners. -
Page 5: Contact Information
Neousys Technology Inc. (Taipei, Taiwan) 15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan Tel: +886-2-2223-6182 Fax: +886-2-2223-6183 Email, Website Americas Neousys Technology America Inc. (Illinois, USA) 3384 Commercial Avenue, Northbrook, IL 60062, USA Tel: +1-847-656-3298 Email, Website China Neousys Technology (China) Ltd. -
Page 6: Notices
This manual is intended to be used as an informative guide only and is subject Disclaimer to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights. -
Page 7: Safety Precautions
Safety Precautions Safety Precautions Read these instructions carefully before you install, operate, or transport the system. ⚫ Install the system or DIN rail associated with, at a sturdy location ⚫ Install the power socket outlet near the system where it is easily accessible ⚫... -
Page 8: Service And Maintenance
Service and Maintenance Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions ⚫... -
Page 9: About This Manual
About This Manual About This Manual This manual introduces and describes how to setup/ install Neousys Technology NRU-171V-PPC/ NRU- 172S-PPC featuring NVIDIA® Jetson Orin™ NX or Orin™ Nano SoM bundled with JetPack. Revision History Version Date Description Oct. 2024 Initial release... -
Page 10: Introduction
NRU-170-PPC Series Introduction The NRU-170-PPC series is an IP66-rated, 10.1” AI panel PC, powered by NVIDIA® Jetson Orin™ NX or Orin™ Nano, delivering up to 100 TOPS of AI processing capability. This series is tailored for edge AI applications that demand water resistance and human-machine interaction, including ADAS for off-highway vehicles, autonomous marine vessels, AI-driven inspection in food processing, smart livestock management, and precision agriculture. -
Page 11: Nru-171V-Ppc Specification
NRU-170-PPC Series NRU-171V-PPC Specification System Core NVIDIA® Jetson Orin™ Nano system on- Processor NVIDIA® Jetson Orin™ NX system-on- module (SOM), comprising NVIDIA® module (SOM), comprising NVIDIA® Ampere GPU and ARM Cortex CPU Ampere GPU and ARM Cortex CPU 16GB/ 8GB LPDDR5 @ 3200 MHz on... - Page 12 NRU-170-PPC Series M.2 NVMe 1x M.2 2242 M key socket (PCIe Gen 3x1) for NVMe SSD Power Supply 8V to 35V DC input and ignition power control via M12 A-coded, 5-pin connector (IGN/ DC Input GND/ V+) * Mechanical Dimension...
-
Page 13: Nru-172S-Ppc Specification
NRU-170-PPC Series NRU-172S-PPC Specification System Core NVIDIA® Jetson Orin™ Nano system on- Processor NVIDIA® Jetson Orin™ Nano system-on- module (SOM), comprising NVIDIA® module (SOM), comprising NVIDIA® Ampere GPU and ARM Cortex CPU Ampere GPU and ARM Cortex CPU 8GB/ 4GB LPDDR5 @ 2133 MHz on... - Page 14 NRU-170-PPC Series Power Supply 8V to 35V DC input and ignition power control via M12 A-coded, 5-pin connector (IGN/ DC Input GND/ V+) * Mechanical Dimension 257 mm (W) x 65 mm (D) x 176 mm (H) Weight 3.8 kg...
-
Page 15: Dimensions
NRU-170-PPC Series Dimensions NOTE Both systems share the same dimensions. Therefore, NRU-171V-PPC will be used for dimension demonstration purposes. All measurements are in millimeters (mm). 1.3.1 Front View 1.3.2 Top view... -
Page 16: Side View
NRU-170-PPC Series 1.3.3 Side view 1.3.4 Bottom view... -
Page 17: Setting Up Your Nru-170-Ppc
Unpacking Your System Upon receiving the NRU-170-PPC system, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology. Item Description... -
Page 18: Front I/O Panel
NRU-170-PPC Series Front I/O Panel Item Description M12 A-coded 5-pin connector Supports 8V to 35V DC input and ignition power control (4A with ignition power control maximum current input per pin). FAKRA Z connectors (NRU- Supports GMSL2 cameras 171V-PPC) PoE+ ports (NRU-172S-PPC) The M12 X-coded Power over Ethernet ports (IEEE 802.3at PoE+... -
Page 19: M12 A-Coded Dc-In Port With Ignition Power Control
NRU-170-PPC Series 2.2.1 M12 A-coded DC-in Port with Ignition Power Control The system accepts a wide range of DC power input from 8V to 35V via a M12 A-coded connector. The M12 A-coded connectors offer COTS availability and ultra-rugged connection reliability when wiring DC power. -
Page 20: Fakra Z Connector For Gmsl2 Camera (Nru-171V-Ppc Only)
NRU-170-PPC Series 2.2.2 FAKRA Z Connector for GMSL2 Camera (NRU-171V-PPC Only) Fachkreis Automobil (FAKRA) connector is a German standard for SubMiniature version B based automotive-grade connectors. There are eight FAKRA Z connectors on the rear panel side to connect to automotive GMSL2 cameras. -
Page 21: Power Over Ethernet + (Nru-172S-Ppc Only)
NRU-170-PPC Series 2.2.3 Power Over Ethernet + (NRU-172S-PPC Only) The system offers four Power over Ethernet ports utilizing Intel® I350-AM4 via an M12 X-coded, 8- pin connector. The combined total power budget is 50W. Connector Pin Definition Panel side Cable connector end... -
Page 22: M12 X-Coded Gigabit Ethernet
NRU-170-PPC Series 2.2.4 M12 X-coded Gigabit Ethernet The system offers one Gigabit Ethernet port, implemented via M12 X-coded connector on the I/O panel. Connector Pin Definition Panel side Cable connector end Signal M12 panel M12 cable connector Wire color side... -
Page 23: M12 A-Coded Can Fd, Com & Di (Gps Pps)
NRU-170-PPC Series 2.2.5 M12 A-coded CAN FD, COM & DI (GPS PPS) The connector includes one CAN FD, one RS232 COM port, and a GPS PPS input signal. The CAN FD features bandwidth up to 8x that of CAN 2.0, and is a robust industrial bus with a pair of differential signals and is commonly used in various industrial and in-vehicle applications. -
Page 24: Rear I/O Panel
NRU-170-PPC Series Rear I/O Panel Item Description M12 A-coded USB 2.0 The M12 A-coded USB 2.0 port is backward-compatible with ports USB 1.1 / 1.0. Power button Press the button to turn on/ off the system. -
Page 25: M12 A-Coded Usb 2.0 Port
NRU-170-PPC Series 2.3.1 M12 A-coded USB 2.0 Port The USB2.0 ports are implemented via native xHCI (eXtensible Host Controller Interface) and are backward compatible with USB 1.1 and USB 1.0 devices. UEFI USB support is also provided so you can use USB keyboard/ mouse in UEFI shell environment. -
Page 26: Power Button
NRU-170-PPC Series 2.3.2 Power Button The power button is a non-latched switch for ATX mode on/off operation. Press to turn on the system, the button should light up and to turn off, you can either issue a shutdown command in the OS, or just press the power button. -
Page 27: Internal I/Os
WiFi, GPS, etc. NOTE If the module is installed after the initial purchase, you may need to contact Neousys Technology or an authorized distributor for a customized panel with the required number of waterproof SMA... - Page 28 +3.3V +1.5V +3.3V WARNING Some off-the-shelf mini-PCIe 4G modules are not compliant to standard mini-PCIe interface. They use 1.8V I/O signals instead of standard 3.3V I/O and may have signal conflict. Please consult with Neousys for compatibility when in doubt!
-
Page 29: B Key 3042/ 3052 & Sim Slots
NOTE If the module is installed after the initial system purchase, you may need to contact Neousys Technology or an authorized distributor for a customized panel with the required number of waterproof SMA antenna holes. - Page 30 NRU-170-PPC Series M.2 (B Key) Slot Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 USB_D+ USB_D- Mechanical Key USB3.0-RX- USB3.0-RX+ UIM1-RESET UIM1-CLK USB3.0-TX- UIM1-DATA USB3.0-TX+ UIM1-PWR UIM2-DATA UIM2-CLK UIM2-RST UIM2-PWR PERST_N RESET_N +3V3 +3V3 +3V3...
-
Page 31: Ignition Rotary Switch
NRU-170-PPC Series 2.4.3 Ignition Rotary Switch The ignition power control switch features multiple modes for pre and post ignition settings. Please refer to the section Ignition Power Control for details. -
Page 32: M.2 M Key 2242 For Nvme Ssd
NRU-170-PPC Series 2.4.4 M.2 M Key 2242 for NVMe SSD The system has a Gen3 x1 PCIe M.2 2242 slot with a pre-installed NVMe SSD. The PCIe Gen3 x1 slot features a maximum speed of 8Gbps (1GB/s). M.2 (M Key) Slot Pin Definition... -
Page 33: System Installation
NOTE Due to waterproof IP66 rating, for the installation/ replacement of following items, please contact Neousys Technology or an authorized dealer 1. NVIDIA® Jetson module replacement 2. M.2 2242 NVMe SSD replacement 3. Wireless module (WiFi, 5G, 4G, etc.) requiring SMA antenna installation. -
Page 34: Disassembling The Enclosure
NRU-170-PPC Series Disassembling the Enclosure 1. Remove the screws holding the touch screen panel onto the enclosure. 2. Gently separate the touch screen panel from the enclosure. - Page 35 NRU-170-PPC Series 3. Remove the screws indicated to access the onboard expansion slots. The touch panel has been disconnected and removed for demonstration purposes. You DO NOT need to disconnect the touch panel to install internal components. 4. Gently lift and remove the heatspreader to gain access to the expansion slots.
-
Page 36: Installing Internal Modules
NRU-170-PPC Series Installing Internal Modules NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. 3.2.1 Installing Mini-PCIe Module (PCIe + USB Signal) There is a mini-PCIe slot for the system to install a WiFi wireless module. Please follow the procedures below for installation. - Page 37 Please refer to the module’s manual for clip-on connection. Clip on IPEX-to-SMA cable NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. Reinstall the heatspreader.
-
Page 38: Key 3042/ 3052 & Sim Installation
SIM card, you can access the internet via the provider’s network. NOTE If the module is installed after the initial purchase, you may need to contact Neousys Technology or an authorized distributor for a customized panel with the required number of... - Page 39 NRU-170-PPC Series If you are installing a 5G/ 4G wireless module that requires a SIM card, please install the SIM card first by pushing the SIM slot holder in the direction shown (OPEN), and flip open the holder to place the SIM into the slot. Otherwise go to the next step.
- Page 40 Clip on the IPEX-to-SMA cable NOTE If the module is installed after initial purchase, you may need to return the unit to Neousys Technology or an authorized distributor for SMA antenna installation. Remove the protective film on the thermal pad.
-
Page 41: Reinstalling The Enclosure
NRU-170-PPC Series Reinstalling the Enclosure Ensure the O-ring is properly seated in the groove. With the O-ring seated in the groove, place the touch screen panel onto the enclosure. NOTE Please make sure the O-ring is seated properly in the groove to ensure the system’s IP66... - Page 42 NRU-170-PPC Series Secure the touch screen panel onto the enclosure with screws indicated. NOTE Please secure each screw with a torque range of 8.1 – 9.9 kgf for waterproof capability.
-
Page 43: Mounting The System
NRU-170-PPC Series Mounting the System The system is compliant with standard VESA 75 x75 mm mounting specifications. The mounting threads can be found on the heatsink side of the system. VESA 75 x75 mm mounting threads on the heatsink. -
Page 44: Powering On The System
NRU-170-PPC Series Powering on the System The system can be powered on using the power button. This is the simplest way to turn on your system. The power button on the side panel is a non-latched switch and behaves as the ATX-mode on/off control. -
Page 45: Ignition Power Control
NRU-170-PPC Series Ignition Power Control The ignition power control module for in-vehicle applications is an MCU-based implementation that monitors the ignition signal and reacts to turn on/off the system according to predefined on/off delay. Its built-in algorithm supports other features such as ultra-low power standby, battery-low protection, system hard-off, etc. -
Page 46: 4.1.1 Additional Features Of Ignition Power Control
NRU-170-PPC Series 4.1.1 Additional Features of Ignition Power Control In addition to the typical timing correlation, the ignition power control module offers additional features to provide additional reliability for in-vehicle applications. ⚫ Low battery detection The ignition power control module continuously monitors the voltage of DC input when the system is operational. -
Page 47: Wiring Ignition Signal
NRU-170-PPC Series 4.1.2 Wiring Ignition Signal To have ignition power control for in-vehicle usage, you need to supply IGN signal to the system. The IGN input is located on the M12 L-coded 5-pin connector (shared with DC power input). For in- vehicle ignition control wiring, please do the following: 1. -
Page 48: Operation Modes Of Ignition Power Control
NRU-170-PPC Series 4.1.3 Operation Modes of Ignition Power Control You can use the rotary switch to configure the operation mode. The system offers 16 (0~15) operation modes with different power-on/power-off delay configurations. Please refer to the section “Disassembling the system” to gain access to the rotary switch. - Page 49 NRU-170-PPC Series ⚫ Mode 2 Mode 2 is designed to have a very minor power on/ off delay of 160ms for applications that requires the system to start up almost at the same as the rest of the equipment it is working in collaboration with.
-
Page 50: Reflashing The System
This section will show you how to reflash the system with a pre-built system image by Neousys. Just like Jetson Orin NX Developer Kit, the system can't install on its own. In other words, you will need another computer, Host Machine, enter recovery mode and reflash the system using a USB Type-A/ Type-C to Type-C cable. - Page 51 NRU-170-PPC Series 5.2 Reflash/ Recovery 1. For detailed reflash process procedure, please refer to this link. 2. When done recovering/ reflashing, disconnect the Type-C cable from the system, and secure the port cover. Note that the port cover MUST be secured in the specific orientation shown, or it will lose it waterproof capability.
