Neousys POC-500 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Neousys Technology Inc.
POC-500 Series
User Manual
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Neousys POC-500 Series

Summary of Contents for Neousys POC-500 Series

  • Page 1 Neousys Technology Inc. POC-500 Series User Manual Revision 1.0...

  • Page 2: Table Of Contents

    COM and Audio Port Panel View ..............24 1.6.4 Bottom View ...................... 25 System Overview Unpacking the System ..................... 26 POC-500 Series Front Panel ..................27 2.2.1 3-pin Terminal Block for DC Input (Optional Ignition Input) ....... 28 2.2.2 3-pin Remote On/ Off ..................29 2.2.3...
  • Page 3 Table of Content 3.2.2 mini-PCIe Module, SIM Card and Antenna Installation ........55 3.2.3 M.2 2880 M Key NVMe SSD Installation ............59 3.2.4 MezIO Module Installation ................61 Installing the System Enclosure ................63 DIN Rail Installation ....................66 Wall Mount Installation (Optional) ................
  • Page 4 Table of Content Appendix B PoE On/ Off Control PoE On/ Off Control Function Reference ................. 110 GetStatusPoEPort ........................ 110 EnablePoEPort ........................111 DisablePoEPort ........................112...

  • Page 5: Legal Information

    For questions in regards to hardware/ software compatibility, customers should contact Neousys Technology Inc. sales representative or technical support. To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be responsible for any interoperability or compatibility issues that may arise when (1) products, software, or options not certified and supported;...

  • Page 6: Contact Information

    3384 Commercial Avenue, Northbrook, IL 60062, USA (Illinois, USA) Tel: +1-847-656-3298 Email, Website China Neousys Technology China Co., Ltd. Room 612, Building 32, Guiping Road 680, Shanghai Tel: +86-2161155366 Email, Website Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 7: Copyright Notice

    Disclaimer This manual is intended to be used as an informative guide only and is subject to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights.

  • Page 8: Safety Precautions

    Safety Precautions Safety Precautions  Read these instructions carefully before you install, operate, or transport the system.  Install the system or DIN rail associated with, at a sturdy location  Install the power socket outlet near the system where it is easily accessible ...

  • Page 9: Service And Maintenance

    Service and Maintenance/ ESD Precautions Service and Maintenance  ONLY qualified personnel should service the system  Shutdown the system, disconnect the power cord and all other connections before servicing the system  When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions...

  • Page 10: About This Manual

    About This Manual About This Manual This manual introduces and demonstrates installation procedures of Neousys POC-500 series systems featuring AMD Ryzen™ Embedded V1000 4-core/ 8-thread processor. The manual also demonstrates the system’s general installation procedures. Revision History Version Date Description Oct.

  • Page 11: Introduction

    4x COM ports. And best of all, all data ports come with screw-lock mechanisms so you can be rest assured that cables are always secured. POC-500 series is available in two CPU variants, the V1807B (45W) variant is for high computing power...

  • Page 12: Specification Of Poc-515

    Internal I/O Interface Mini PCI-E 1x full-size mini PCI Express socket with internal SIM socket Expandable 1x MezIO expansion interface for Neousys MezIO modules Storage Interface M.2 NVMe 1x M.2 2280 M key NVMe socket (PCIe Gen3 x2) for NVMe SSD...
  • Page 13 POC-500 Series Operating, MIL-STD-810G, Method 514.6, Category 4 Vibration Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II CE/ FCC Class A, according to EN 55032 & EN 55024 * For sub-zero and over 60°C operating temperature, a wide temperature HDD or...

  • Page 14: Specification Of Poc-516

    POC-500 Series Specification of POC-516 System Core Processor AMD Ryzen V1605B CPU ( 4C/ 8T, 2M Cache, 2.0/ 3.6 GHz) Graphics Vega GPU with 8 compute units Memory Up to 16 GB DDR4-2400 SDRAM (one SODIMM socket) Panel I/O Interface...
  • Page 15 POC-500 Series Storage -40°C ~85°C temperature Humidity 10%~90% , non-condensing Operating, MIL-STD-810G, Method 514.6, Category 4 Vibration Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II CE/ FCC Class A, according to EN 55032 & EN 55024 * For sub-zero and over 60°C operating temperature, a wide temperature HDD or...

  • Page 16: Specification Of Poc-545

    Internal I/O Interface Mini PCI-E 1x full-size mini PCI Express socket with internal SIM socket Expandable 1x MezIO expansion interface for Neousys MezIO modules Storage Interface M.2 NVMe 1x M.2 2280 M key NVMe socket (PCIe Gen3 x2) Power Supply...
  • Page 17 POC-500 Series Humidity 10%~90% , non-condensing Operating, MIL-STD-810G, Method 514.6, Category 4 Vibration Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II CE/ FCC Class A, according to EN 55032 & EN 55024 * For sub-zero and over 60°C operating temperature, a wide temperature HDD or Solid State Disk (SSD) is required.

  • Page 18: Specification Of Poc-546

    POC-500 Series Specification of POC-546 System Core Processor AMD Ryzen V1807B CPU ( 4C/ 8T, 2M Cache, 3.35/ 3.8 GHz) Graphics Vega GPU with 11 compute units Memory Up to 16 GB DDR4-3200 SDRAM (one SODIMM socket) Panel I/O Interface...
  • Page 19 POC-500 Series Storage -40°C ~85°C temperature Humidity 10%~90% , non-condensing Operating, MIL-STD-810G, Method 514.6, Category 4 Vibration Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II CE/ FCC Class A, according to EN 55032 & EN 55024 * For sub-zero and over 60°C operating temperature, a wide temperature HDD or Solid State Disk (SSD) is required.

  • Page 20: Dimension Of Poc-515/ Poc-516

    POC-500 Series Dimension of POC-515/ POC-516 NOTE All measurements are in millimeters (mm). The POC-515 and POC-516 systems share the same dimensions. 1.5.1 Front Panel View...

  • Page 21: Dio Panel View

    POC-500 Series 1.5.2 DIO Panel View 1.5.3 COM and Audio Port Panel View...

  • Page 22: Bottom View

    POC-500 Series 1.5.4 Bottom View...

  • Page 23: Dimension Of Poc-545/ Poc-546

    POC-500 Series Dimension of POC-545/ POC-546 NOTE All measurements are in millimeters (mm). The POC-545 and POC-546 systems share the same dimensions. 1.6.1 Front Panel View...

  • Page 24: Dio Panel View

    POC-500 Series 1.6.2 DIO Panel View 1.6.3 COM and Audio Port Panel View...

  • Page 25: Bottom View

    POC-500 Series 1.6.4 Bottom View...

  • Page 26: System Overview

    Upon receiving and unpacking your POC-500 systems, please check immediately if the package contains all the items listed in the following table. If any item(s) are missing or damaged, please contact your local dealer or Neousys Technology. Unpacking the System...

  • Page 27: Series Front Panel

    POC-500 Series POC-500 Series Front Panel The front panel of POC-500 series feature rich I/O ports, it has four PoE+ Gigabit Ethernet ports, four USB 3.1 Gen1 ports, one DisplayPort, one VGA port, remote control and 3-pin terminal block for DC input.

  • Page 28: 3-Pin Terminal Block For Dc Input (Optional Ignition Input)

    POC-500 Series 2.2.1 3-pin Terminal Block for DC Input (Optional Ignition Input) The system accepts a wide range of DC power input from 8 to 35V via a 3-pin pluggable terminal block, which is fit for field usage where DC power is usually provided.

  • Page 29: 3-Pin Remote On/ Off

    POC-500 Series 2.2.2 3-pin Remote On/ Off The “Remote On/ Off” 3-pin connection allows for external switch extension. It is useful when the system is placed in a cabinet or a not easily accessed location. You may connect an external remote with an external status LED indicator (15mA) by...

  • Page 30: Ieee 802.3At Power Over Ethernet Port

    POC-500 Series 2.2.3 IEEE 802.3at Power over Ethernet Port The Gigabit Power over Ethernet (PoE) port supply power and data on a standard CAT-5/CAT-6 Ethernet cable. Acting as a PSE (Power Sourcing Equipment), compliant with IEEE 802.3at, each port delivers up to 25W to a Powered Device (PD).

  • Page 31: Usb 3.1 Gen1

    POC-500 Series 2.2.4 USB 3.1 Gen1 The system offers four USB 3.1 Gen1 (SuperSpeed USB) ports on its front panel. They are backward compatible with USB 2.0, USB 1.1 and USB 1.0 devices. Legacy USB support is also provided so you can use USB keyboard/mouse in DOS environment while USB 3.1 Gen1 driver is supported natively in Windows 10.

  • Page 32: Displayport

    POC-500 Series 2.2.6 DisplayPort The system has a DisplayPort (DP) output which is a digital display interface that mainly connect video source and carry audio to a display device. When connecting a DP, it can deliver up to 4K UHD (4096 x 2160 @ 30Hz) in resolution. The system is designed to support passive DP adapter/ cable.

  • Page 33: Vga Port

    POC-500 Series 2.2.7 VGA Port VGA connector is the most common video display connection. The VGA output supports up to 1920x1200@60Hz resolution. The system supports dual independent display outputs by connecting display devices to VGA and DisplayPort connection. To support dual display outputs and achieve best VGA output resolution in Windows, you need to install corresponding graphics drivers.

  • Page 34: Com Port Panel

    POC-500 Series COM Port Panel The COM port panel of POC-500 series features additional I/O functions, such as COM ports, 3.5mm speaker-out/ microphone-in jack, and reserved antenna openings for SMA antenna installation. In addition, the power and reset button can also be located on this panel.

  • Page 35: Power Button

    POC-500 Series 2.3.1 Power Button The power button is a non-latched switch for ATX mode on/off operation. Press to turn on the system, PWR LED should light up and to turn off, you can either issue a shutdown command in the OS, or just press the power button. In case of system halts, you can press and hold the power button for 5 seconds to force-shutdown the system.

  • Page 36: Com 1 Port

    POC-500 Series 2.3.2 COM 1 Port Implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provide up to 921600 bps baud rate, COM1 is a software-configurable RS-232/422/485 port via 9-pin D-Sub male connector. The operation mode, slew rate and termination of COM1 can be set in BIOS setup utility.

  • Page 37: Com Port (Com2/ Com3/ Com4)

    POC-500 Series 2.3.3 COM Port (COM2/ COM3/ COM4) Implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provide up to 921600 bps baud rate, the D-Sub male connector (COM2/ 3/ 4) can be configured in the BIOS as single RS-422/ 485 port (COM2) or three 3-wire RS-232 ports (COM2/COM3/COM4).

  • Page 38: 4-Pole 3.5Mm Microphone-In/ Speaker-Out Jack

    POC-500 Series 2.3.4 4-Pole 3.5mm Microphone-in/ Speaker-out Jack There is a female 4-pole audio jack for headphone (speaker) output and microphone input. To utilize the audio function in Windows, you need to install corresponding drivers. Please refer to the section, Driver Installation.

  • Page 39: Sma Antenna Opening

    POC-500 Series 2.3.5 SMA Antenna Opening The system offers three SMA antenna openings reserved for SMA antenna installations. Users can take advantage of these three openings when installing mini-PCIe module for wireless communication reception such as 3G, 4G, GPS or...

  • Page 40: Reserved Port Opening Panel

    POC-500 Series Reserved Port Opening Panel The reserved port opening panel has reserved openings for DIO or extra COM ports. Choose from a wide range Neousys' MezIO modules and find one that best suit your needs.

  • Page 41: Internal I/O

    POC-500 Series Internal I/O The system’s internal I/O connectors consist of an mini-PCIe slot with SIM slot, an M.2 slot for NVMe SSD, SO-DIMM socket, slot and a MezIO port for application-oriented expansion purposes. 2.5.1 Full-size mini-PCIe Slot and SIM Socket The system provides a full-size mini-PCIe socket.
  • Page 42 Some off-the-shelf mini-PCIe 4G modules use 1.8V I/O signals instead of 3.3V I/O and may cause signal interference. Installing an incompatible 4G module may damage the system or the module itself may be damaged. Please consult with Neousys when in doubt!

  • Page 43: 2280 (M Key) Slot For Nvme Ssd

    POC-500 Series 2.5.2 M.2 2280 (M Key) Slot for NVMe SSD The system has an M.2 2280 slot (M key PCIe Gen3 x2) to install an NVMe SSD for the ultimate disk read/ write performance. An NVMe SSD offers doubled the disk...
  • Page 44 POC-500 Series M.2 (M Key) Slot Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 DAS/DSS_N +3V3 +3V3 +3V3 +3V3 PERN1 PERP1 PETN1 PETP1 PERn0 + PERp0 - PETn0 - PETp0 + PERST_N REFCLKN REFCLKP Mechanical Key SUSCLK PEDET...

  • Page 45: So-Dimm Socket

    POC-500 Series 2.5.3 SO-DIMM Socket The system supports one 260-pin SO-DIMM socket for installing DDR4 memory module up to 16GB in capacity. Please refer to the following table for details. System POC-515/ POC-516 POC-545/ POC-546 Memory type DDR4-2400 Supported Supported...

  • Page 46: Mezio Tm Interface

    The system incorporates MezIO interface and universal mechanical design to accommodate Neousys’ standard MezIO modules. For customers who want to develop their own MezIO module, Neousys provides MezIO design documents on a NDA basis. Please contact Neousys for further information.

  • Page 47: Mezio Interface Pin Definition

    P1V8 1.8V power 3.3V power P3V3 Ground 5V power P12V 12V power 5V power P12V 12V power * PCIe lanes 2/ 3 are only supported by A2 version PCB. If you are unsure, please contact your sales representative or Neousys.

  • Page 48: Mezio Tm Modules For Poc-500 Series

    MezIO Modules for POC-500 Series Neousys offers MezIO modules to expand I/O functions for Neousys systems. With the addition of a MezIO module into your system, it offers extra RS-232/ 422/ 485 ports, isolated digital I/ O, 2.5” HDD/ SSD accommodation or ignition power control.

  • Page 49: System Installation

    POC-500 Series System Installation Before disassembling the system enclosure and installing components and modules, please make sure you have done the following:  It is recommended that only qualified service personnel should install and service this product to avoid injury or damage to the system.

  • Page 50: Disassembling The System Enclosure

    POC-500 Series Disassembling the System Enclosure NOTE For POC-515/ 516 systems, you may skip steps 2 & 3. To install internal components such as M.2 SSD, memory module, mini-PCIe or MezIO module, you need to disassemble the system enclosure. Please refer to the following procedures: Remove the two (2) screws indicated in red.
  • Page 51 POC-500 Series Remove the two (2) screws (indicated in red) and remove the power cable cover. Unplug the 3-pin fan power connector.
  • Page 52 POC-500 Series Remove the two (2) screws (indicated in red). For POC-545/ 546 systems, please also separate the fan from the enclosure. POC-515/ POC-516 systems POC-545/ POC-546 systems Turn the system upside down and place it on a flat sturdy surface. Unscrew the...
  • Page 53 POC-500 Series Unscrew the two (2) VGA hexa bolt screws (indicated in red); unscrew the three (3) screws (indicated in blue) and gently remove the front I/O panel. Unscrew the two (2) screws (indicated in red) to remove the DRAM/ NVMe SSD heat spreader and unscrew the screw (indicated in blue) to remove the DIO panel.

  • Page 54: Installing Internal Components

    POC-500 Series Installing Internal Components 3.2.1 DDR4 SO-DIMM Installation There is one SO-DIMM memory slot on POC-500 motherboard. Please follow the procedures below to install the memory module. Disassemble the system enclosure. 2. Locate the SO-DIMM slot on the motherboard shown below.

  • Page 55: Mini-Pcie Module, Sim Card And Antenna Installation

    POC-500 Series 3.2.2 mini-PCIe Module, SIM Card and Antenna Installation There are mini-PCIe with SIM slots on MezIO module and the motherboard. Please follow the procedures below to install the mini-PCIe module and SIM card, as well as the antenna for wireless communication.
  • Page 56 POC-500 Series 4. The SIM card slot utilizes a slide-and-clamp mechanism. To open the slot, slide the top section away from the VGA port, flip open the slot and insert the SIM card. Push away from the VGA port Flip open the slot and inset SIM card 5.
  • Page 57 POC-500 Series 6. Clip-on mini-PCIe module’s antenna (please refer to the module’s user manual on antenna cable connection). 7. Remove one of the antenna covers from the enclosure.
  • Page 58 POC-500 Series 8. Secure the SMA antenna connector, reinstall the enclosur and attach the external SMA antenna. Securing antenna connection Attach external antenna Reinstall the enclosure when done.

  • Page 59: 2880 M Key Nvme Ssd Installation

    POC-500 Series 3.2.3 M.2 2880 M Key NVMe SSD Installation There is one M.2 2280 M Key slot (PCIe Gen3 x2) for you to install an NVMe SSD. Please follow the procedures below to install the M.2 module Disassemble the system enclosure.
  • Page 60 POC-500 Series 4. Gently push it towards the motherboard and secure the NVMe SSD with the supplied screw. 5. Once you have installed the NVMe SSD, you need to reinstall the heat spreader but before you do so, please make sure the protective film on the thermal pads have been removed.

  • Page 61: Mezio Tm Module Installation

    POC-500 Series 3.2.4 MezIO Module Installation The MezIO module is situated above the heat spreader. Please make sure that you have installed the memory module, mini-PCIe, SIM card, NVMe SSD before installing the MezIO module. To install the MezIO module, please refer to the following procedure.
  • Page 62 POC-500 Series 3. Secure the stand-off hex bolts that came with the MezIO card onto the motherboard. Gently lower the module onto the motherboard. The MezIO connector should engage the port if the three (3) standoffs and screw holes meet.

  • Page 63: Installing The System Enclosure

    POC-500 Series Installing the System Enclosure To reinstall the system enclosure, install the DIO port panel and secure it into the lower screw opening (indicated in red). Install the front panel by securing it with three (3) screws (indicated in blue green) and the two (2) hexa bolt (indicated in red) on the VGA connector.
  • Page 64 POC-500 Series Place the L-shaped enclosure panel back into place and secure it with three (3) screws. 10. Secure the two (2) screws (indicated in red) to complete the enclosure assembly for POC-515/ 516 systems. For POC-545/ 546 systems, please secure the fan onto the enclosure.
  • Page 65 POC-500 Series 11. For POC-545/ 546, plug in the 3-pin fan power connector and secure the power cable cover with screws (indicated in red) to complete the enclosure assembly procedure. Plug in the 3-pin fan power connector Secure the power cable cover...

  • Page 66: Din Rail Installation

    POC-500 Series DIN Rail Installation The system comes with a DIN rail clip (in the accessory box) that allows the system to be mounted vertically. To install, secure the DIN rail clip to the rear side panel of the system enclosure...
  • Page 67 POC-500 Series To install the DIN rail clip onto the DIN rail, you must come over the top of the DIN rail, tilting, overlap the top clip edge of the DIN rail clip onto the DIN rail first, and then firmly press the bottom-front of the enclosure to clip the bottom edge...
  • Page 68 POC-500 Series Confirm the mount plate has indeed clipped onto the DIN rail for proper fit to complete the installation.

  • Page 69: Wall Mount Installation (Optional)

    POC-500 Series Wall Mount Installation (Optional) The optional wall mount bracket allows the system to be mounted horizontally. Please refer to the following installation procedure to install the wall mount. To install, secure the wall mount bracket to the bottom of the system enclosure using the M4 screws provided.

  • Page 70: Vertical Wall Mount Bracket (Optional)

    POC-500 Series 3.5.1 Vertical Wall Mount Bracket (Optional) To install, secure the wall mount bracket to the rear side panel of the system enclosure using the M4 screws provided. Dimension illustration of the install vertical wall mount bracket for you...

  • Page 71: Powering On The System

    POC-500 Series Powering On the System There are three methods to power on the system  Pressing the power button  Via an external non-latched switch  Sending a LAN packet via Ethernet (Wake-on-LAN) 3.6.1 Powering On Using the Power Button This is the simplest way to turn on your system.

  • Page 72: Powering On Using An External Non-Latched Switch

    POC-500 Series 3.6.2 Powering On Using An External Non-Latched Switch If your application demands the system to be placed inside a cabinet, you may use an external non-latched switch to power on/ off the system. The system provides a 3-pin “Remote On/ Off” plug for connecting a non-latched switch and acts as the ATX-mode power on/off control switch.

  • Page 73: Powering On Using Wake-On-Lan

    POC-500 Series 3.6.3 Powering On Using Wake-on-LAN Wake-on-LAN (WOL) is a mechanism to wake up a computer system from a S3 (standby), S4 (Hibernate) or S5 (system off with standby power) state via issuing Subnet Directed Broadcasts (SDB) or a magic packet. The system implements the Wake-on-LAN function for the GbE ports highlighted in blue, shown below.
  • Page 74 POC-500 Series Click the Power Management tag, and check the following two options accordingly  Wake on Magic Packet The system can wake from S3 or S4 state when receiving a magic packet. The magic packet is a broadcast frame containing anywhere within its payload 6 bytes of all 255 (FF FF FF FF FF FF in hexadecimal), followed by sixteen repetitions of the target computer's 48-bit MAC address.
  • Page 75 POC-500 Series 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C 78 D0 04 0A 0B 0C...

  • Page 76: Bios Settings

    NOTE Not all BIOS settings will be discussed in this section. If a particular setting/ function you are after requires specific BIOS settings but is not discussed in this section, please contact Neousys Technical Support staff.

  • Page 77: Com1/ 2 Port Configuration

    POC-500 Series COM1/ 2 Port Configuration The system’s COM1/ 2 ports support RS-232 (full-duplex), RS-422 (full-duplex) and RS-485 (half-duplex) mode. You can set the COM1/ 2 operating mode via BIOS settings. The option in the BIOS setting called “Slew Rate” defines how sharp the rising/falling edge is for the output signal of COM1/ 2.

  • Page 78: Com 3/ 4 Port Configuration

    POC-500 Series COM 3/ 4 Port Configuration The system’s COM 3/ 4 ports support RS-232 (full-duplex) and to enable it, COM 2 must be set to RS-232 mode. Another option in COM port’s BIOS setting is called HS (High Speed) and when enabled, the input clock for baud rate generator is multiply by 8.

  • Page 79: Com Port High Speed Mode

    POC-500 Series COM Port High Speed Mode The high speed mode of each COM port effectively allows for the port's baud rate generator to operate at 8x the speed with an effective baud rate of 921,600 bps (115,200 x 8). Please refer to the following instructions on how to enable the high speed mode for your COM port (COM1 used as an example).

  • Page 80: Sata Configuration For Mezio

    POC-500 Series SATA Configuration for MezIO Module The SATA configuration setting should be configured according to the MezIO card installed. For detail settings, please refer to the following table. Module & description MezIO Description SATA configuration module MezIO-R11 1x 2.5” SATA HDD/ SSD SATA set to <Auto>...

  • Page 81: Tpm Availability

    POC-500 Series TPM Availability Trusted Platform Module (TPM) is a hardware-based cryptoprocessor to secure hardware by integrating cryptographic keys into devices. The system is designed with on-board TPM 2.0 module. It is enabled in the BIOS by default. To enable TMP availability: When system boots up, press F2 to enter BIOS setup utility.

  • Page 82: System Power Configuration (Poc-515/ 516)

    POC-500 Series System Power Configuration (POC-515/ 516) The system power configuration allows you to set the maximum power consumption of the system. Depending on your application, you can configure the option to 25W for higher performance or 12W for lower power-consumption. You may also leave the setting on Auto and allow the system to auto regulate power consumption according to application needs.

  • Page 83: System Power Configuration (Poc-545/ 546)

    POC-500 Series System Power Configuration (POC-545/ 546) The system power configuration allows you to set the maximum power consumption of the system. Depending on your application, you can configure the option to 54W for higher performance or 35W for lower power-consumption. You may also leave the setting on Auto and allow the system to auto regulate power consumption according to application needs.

  • Page 84: Power Over Ethernet (Poe)

    POC-500 Series Power over Ethernet (PoE) The Power over Ethernet (PoE) setting in the BIOS allows you to enable/ disable the PoE function of the designated port upon system boot up. To enable/ disable Power over Ethernet settings: Press F2 when the system boots up to enter the BIOS setup utility.

  • Page 85: Wake-On-Lan

    POC-500 Series Wake-on-LAN Wake-on-LAN (WOL) is a mechanism which allows you to turn on your system via Ethernet connection. To utilize Wake-on-LAN function, you have to enable this option first in BIOS settings. Please refer to Powering on via Wake-on-LAN function.

  • Page 86: 4.10 Power On After Power Failure

    POC-500 Series 4.10 Power On after Power Failure This option defines the system’s behavior when DC power is supplied. Value Description S0 – Power On System is powered on when DC power is supplied. S5 – Power Off System is kept in off state when DC power is supplied.

  • Page 87: 4.11 Boot Menu

    POC-500 Series 4.11 Boot Menu The Boot menu in BIOS allows you to specify the system’s boot characteristics by setting bootable device components (boot media) and method. Or, you may press F12 upon system start up and select a device you wish boot from.
  • Page 88 POC-500 Series Newly detected boot media are placed at the top Add Boot Options First of the boot order. Newly detected boot media are placed at the Last bottom of the boot order. Newly detected boot media order will be Auto automatically detected and placed in boot order.

  • Page 89: Boot Type (Legacy/ Uefi)

    POC-500 Series 4.12 Boot Type (Legacy/ UEFI) The system supports both Legacy and Unified Extensible Firmware Interface (UEFI) boot modes. UEFI is a specification proposed by Intel to define a software interface between operating system and platform firmware. Most modern operating systems, such as Windows 10 and Linux support both Legacy and UEFI boot modes.

  • Page 90: 4.13 Position New Boot Device

    POC-500 Series 4.13 Position New Boot Device The “Add Boot Options” allow you to determine whether a newly added device (eg. USB flash disk) is to boot as the first device to boot or the last in the boot sequence.

  • Page 91: 4.14 Watchdog Timer

    POC-500 Series 4.14 Watchdog Timer The watchdog timer secures the boot process by means of a timer. Once the timer expires, a reset command is issued to initiate another booting process. There are two options in BIOS menu, “Automatically after POST” and “Manually after Entering OS”.

  • Page 92: Os Support And Driver Installation

    I350-AM4 GbE controller if the driver is not embedded in kernel. You can visit AMD website for further information. Neousys may remove or update operating system compatibility without prior notice. Please contact us if your operating system of choice is not on the list.

  • Page 93: Driver Installation

    POC-500 Series Driver Installation The system comes with a “Drivers & Utilities” DVD that offers “one-click” driver installation process. It automatically detects your Windows operating system and installs all necessary drivers for you system with a single click. 5.2.1 Install Drivers Automatically To install drivers automatically, please refer to the following procedures.

  • Page 94: Install Drivers Manually

    POC-500 Series 5.2.2 Install Drivers Manually You can also manually install each driver for the system. Please note when installing drivers manually, you need to install the drivers in the following sequence mentioned below. Windows 10 (x64) The recommended driver installation sequence is Chipset/ graphics driver (x:\ Driver_Pool\AMD_V1000\Win_10_64\Setup.exe)

  • Page 95: Driver For Watchdog Timer And Dio

    POC-500 Series Driver for Watchdog Timer and DIO Neousys provides a driver package which contains function APIs for WDT function and isolated DIO control function. You should install the driver package (WDT_DIO_Setup.exe) in prior to use these functions. NOTE Please download from Neousys website and install WDT_DIO_Setup_v2.2.9.9 or...

  • Page 96: Appendix A Using Wdt & Dio

    WDT and keeping resetting the timer to make sure the system or program is running. Otherwise, the system shall be reset. In this section, we’ll illustrate how to use the function library provided by Neousys to program the WDT functions. Currently, WDT driver library supports Windows 10 x64 and WOW64 platform.

  • Page 97: Wdt And Dio Library Installation

    POC-500 Series WDT and DIO Library Installation To setup WDT & DIO Library, please follow instructions below. 1. Execute WDT_DIO_Setup.2.2.9.9.exe. 2. Click “Next >” and specify the directory of installing related files. The default directory is C:\Neousys\WDT_DIO. 3. Once the installation has finished, a dialog will appear to prompt you to reboot the...
  • Page 98 POC-500 Series 4. When programming your WDT or DIO program, the related files are located in Header File: \Include Library File: \Lib Function \Manual Reference: Sample Code: \Sample\WDT_Demo (Demo for Watchdog Timer) \Sample\DIO_Demo (Demo for isolated DIO Control) \Sample\COS_Demo (Demo for change-of-state DI)

  • Page 99: Wdt Function Reference

    POC-500 Series WDT Function Reference InitWDT Syntax BOOL InitWDT(void); Description: Initialize the WDT function. You should always invoke InitWDT() before set or start watchdog timer. None Parameter Return Value TRUE: Successfully initialized FALSE: Failed to initialize Usage BOOL bRet = InitWDT()

  • Page 100: Startwdt

    POC-500 Series StartWDT Syntax BOOL StartWDT(void); Description Starts WDT countdown. Once started, the WDT LED indicator will begin blinking. If ResetWDT() or StopWDT is not invoked before WDT countdowns to 0, the WDT expires and the system resets. Parameter None...

  • Page 101: Using Dio Function (Poc516/ Poc-546 Only)

    POC-500 Series Using DIO Function (POC516/ POC-546 Only) Wiring for DIO The digital input function of System series is implemented using a photo-coupler with an internally series-connected 1kΩ resistor. You need to provide a voltage to specify the logic high/low state. The input voltage for logic high is 5~24V, and the input voltage for logic low is 0~1.5V.

  • Page 102: Dio Pin Definition

    POC-500 Series DIO Pin Definition Pin# Pin Definition Pin# Pin Definition DI_0 DI_GND DI_1 DI_2 DI_GND DI_3 DO_GND DO_GND DO_0 DO_2 DO_1 DO_3 DO_GND...

  • Page 103: Dio Function Reference

    POC-500 Series DIO Function Reference InitDIO Syntax BOOL InitDIO(void); Initialize the DIO function. You should always invoke InitDIO() Description: before write/read any DIO port/channel. Parameter None Return Value TRUE: Successfully initialized FALSE: Failed to initialize BOOL bRet = InitWDT() Usage...

  • Page 104: Dowriteline

    POC-500 Series DOWriteLine Syntax void DOWriteLine(BYTE ch, BOOL value); Description: Write a single channel of isolated digital output. BYTE value specifies the DO channel to be written. ch should be a value of 0 ~ 3. Parameter value BOOL value (TRUE or FALSE) specifies the status of DO channel.

  • Page 105: Dowritelinechecked

    POC-500 Series DOWriteLineChecked Syntax void DOWriteLineChecked(BYTE ch, BOOL value); Write a single channel of isolated digital output and read-back the value of DO register. Note that this function is not returned Description: until the DO register is checked and identical to the written value.

  • Page 106: Cos Function Reference

    POC-500 Series COS Function Reference SetupDICOS Syntax BOOL SetupDICOS(COS_INT_SETUP *lpSetup, DWORD cbSetup); Setup Digital-Input(DI) Change-of-State(COS) interrupt Description parameters. Parameter lpSetup [in] A pointer to a COS_INT_SETUP structure that contains the COS configuration information for the DI device. This data structure contains the following variables:...

  • Page 107: Registercallbackdicos

    POC-500 Series RegisterCallbackDICOS Syntax BOOL RegisterCallbackDICOS(COS_INT_CALLBACK callback); Description: Registers a callback function, which is called when the DICOS interrupt occurred. Parameter callback [in] Specifies the callback function. The prototype for this function is descripted as follow. void __stdcall callback_func(COS_INT_CALLBACK_ARG* arg);...

  • Page 108: Di Cos Example

    POC-500 Series DI COS Example #include <stdio.h> #include <stdlib.h> #include <windows.h> #include "WDT_DIO.h" //Step 0, define a Change-of-State Interrupt callback function void __stdcall callback_function(COS_INT_CALLBACK_ARG* arg) printf("data=0x%02x, flag=0x%02x, seq=%02d\n", arg->portData, arg->intrFlag, arg->intrSeq); int main(int argc, char* argv[]) //Step 1, initialize DIO library by invoking InitDIO() if ( ! InitDIO() ) printf("InitDIO -->...
  • Page 109 POC-500 Series //Step 3, register the callback function if ( ! RegisterCallbackDICOS(callback_function) ) printf("RegisterCallbackDICOS --> FAILED\n"); return -3; printf("RegisterCallbackDICOS --> PASSED\n"); //Step 4, start the DI Change-of-State Interrupt if ( ! StartDICOS() ) printf("StartDICOS --> FAILED\n"); return -4; printf("StartDICOS --> PASSED\n");...

  • Page 110: Appendix B Poe On/ Off Control

    PoE port. This can be function can be useful in power device (PD) fault-recovery or power reset. The function APIs are encapsulated in Neousys WDT_DIO driver package. Please follow the instructions in Appendix A Watchdog Timer &...

  • Page 111: Enablepoeport

    POC-500 Series EnablePoEPort Syntax BOOL EnablePoEPort (BYTE port); Description Turn on PoE power of designated PoE port. Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4...

  • Page 112: Disablepoeport

    POC-500 Series DisablePoEPort Syntax BOOL DisablePoEPort (BYTE port); Description Turn off PoE power of designated PoE port Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4...

This manual is also suitable for:

Poc-515Poc-516Poc-545Poc-546

Table of Contents
