SHELBY TEACHER DESK
Hardware Included:
#14 x 7/8"
1/4" Washers
Wood Screws
Step 1: Assembling the Steel Post Legs
•
Determine Desk Handedness. (Pedestal on Left or Right)
•
Place the top upside down on a clean smooth surface.
•
Install legs on the end of the desk that doesn't recieve a storage unit.
•
Use #14 X 7/8" Wood Screws along with 1/4" washers to secure the legs to the bottom of the top.
Assemble units only as described in this
!
guide. All fasteners must be tightened
securely and checked regularly. Failure to
CAUTION
do so could cause instability and injury.
DETERMINE DESK HANDEDNESS.
WHILE THE TOP IS UPSIDE DOWN ON A CLEAN
SMOOTH SURFACE, INSTALL LEGS (IF
APPLICABLE) ON THE END OF THE DESK THAT
DOESN'T RECEIVE A STORAGE UNIT. USE #14 X
WOOD SCREWS ALONG WITH
Steel Post Legs
SECURE THE LEGS TO THE BOTTOM OF THE
TOP.
1
1
" WASHERS TO
4
Desks
Tools Required:
• #2 Phillips Head Screwdriver
instructions-shelbyteacher-240912
7
8
Advertisement
Related Manuals for Media Technologies SHELBY TEACHER DESK
Summary of Contents for Media Technologies SHELBY TEACHER DESK
- Page 1 WHILE THE TOP IS UPSIDE DOWN ON A CLEAN SMOOTH SURFACE, INSTALL LEGS (IF APPLICABLE) ON THE END OF THE DESK THAT SHELBY TEACHER DESK DOESN'T RECEIVE A STORAGE UNIT. USE #14 X WOOD SCREWS ALONG WITH " WASHERS TO...
-
Page 2: Modesty Panel
STEP 2: INSTALL MODESTY PANEL. USING 2" L BRACKETS, SECURE THE MODESTY SHELBY TEACHER DESK PANEL TO THE BOTTOM OF THE TOP USING #10 STEP 2: INSTALL MODESTY PANEL. " PH SCREWS THROUGH THE L BRACKETS. Desks Modesty Panel USING 2" L BRACKETS, SECURE THE MODESTY... - Page 3 SHELBY TEACHER DESK STEP 3: INSTALL STORAGE PED(S). Desks REMOVE THE TOP DRAWER (IF APPLICABLE). Storage Pedestal POSITION STORAGE PED AND SECURE TO THE TOP USING #8 X 1- " FH SCREW (4X). INSTALL L BRACKET TO HOLD THE MODESTY PANEL TO THE PED IN THE SAME MANNER AS STEP #2.
- Page 4 STEP 3: INSTALL STORAGE PED(S). SHELBY TEACHER DESK REMOVE THE TOP DRAWER (IF APPLICABLE). POSITION STORAGE PED AND SECURE TO THE Desks TOP USING #8 X 1- " FH SCREW (4X). Double Storage Pedestals INSTALL L BRACKET TO HOLD THE MODESTY PANEL TO THE PED IN THE SAME MANNER AS STEP #2.
- Page 5 SHELBY TEACHER DESK STEP 4: INSTALL GROMMETS & SUPPLIED WIRE CHASE. SECURE WIRE CHASE WITH #10 X 3/4" SCREWS. Desks Grommets & Wire Chase L GROMMETS & SUPPLIED WIRE CHASE. E WIRE CHASE WITH #10 X 3/4" SCREWS. Hardware Included: Tools Required: •...
