Summary of Contents for LTE MATSING MS-MBC-2-L2-15
- Page 1 MS-MBC-2-L2-15 Instruction Manual www.matsing.com technicalsupport@matsing.com phone: (800) 867-6429...
- Page 2 Table of Contents 1.00 Pattern diagram 1.10 Horizontal pattern 1.20 Vertical pattern 2.00 Beams and connectors 2.10 Plan view resultant beam layout 2.20 Connector port table 2.30 Connector detail 2.40 Connector layout 3.00 Bracket installation 3.10 Bolts and nuts / Tools 3.11 Bolts and nuts 3.12...
- Page 3 1.00 Pattern diagram 1.10 Horizontal pattern Frequency: 698 - 960 MHz 1.20 Vertical pattern Frequency: 698 - 960 MHz MS-MBC-2-L2-15 Instruction Manual Rev0 251024 Page 3 of 5...
- Page 4 2.00 Beams and connectors 2.10 Plan view resultant beam layout 2.20 Connector port table 0˚ BEAM 2 BEAM 1 Port 3 Port 4 Port 1 Port 2 (+45) (-45) (+45) (-45) Plan View Resultant Beam Directions Frequency: 698 - 960 MHz 2.30 Connector detail 2.40...
-
Page 5: Bracket Installation
3.00 Bracket installation 3.10 Bolts and nuts / Tools 3.11 Bolts and nuts 3.20 Tools requirement 3.12 Bracket 3.21 Adjustable spanner 3.22 M12 spanner 3.30 Bracket spacing and installation sample MS-MBC-2-L2-15 Instruction Manual Rev0 251024 Page 5 of 5...
