Summary of Contents for EVERCROSS EV85F
- Page 1 EV85F User Manual EU V1.2.1...
- Page 2 Step 3: Click the "Ask a Question" button. Choose your topic from list displayed. Step 4: Select Contact seller. *If you purchased EVERCROSS products by other platforms or channels, please also find the corresponding seller contact support. Thanks for your support and patience!
-
Page 3: Table Of Contents
CONTENTS Package Contents···························································03 Product Overview·······················································04~06 Assembly and Set-Up·······················································07 Charge Your Scooter························································08 How To Ride······························································09~10 Smart Phone App·····························································11 Safety Reminder························································12~15 Safety Instructions······················································16~17 Folding your scooter·························································18 Daily Care and Maintenance·········································19~21 Specifications····························································21~22 Product Warranty·····························································23... - Page 4 Thanks for choosing the EVERCROSS Electric Scooter EV85F (hereinafter referred to as EV85F)! The EV85F is not only a short-distance transportation product that is easy to fold and carry, also a stylish sport entertainment equipment. Enjoy your ride and connect with riders worldwide!
-
Page 5: Package Contents
EV85F. *Please retain the box and packaging materials in case you need to ship your EV85F in the future. *Remember to power off your EV85F and unplug the charge cable before assembling or mounting... - Page 6 PRODUCT OVERVIEW PACKAGE CONTENTS PACKAGE CONTENTS 1. Product Diagram Handlebar Accelerator Headlight Control Panel & Power Button Brake Lever Bell Stem Quick Release Lever Buckle Folding Mechanism Brake Light Disc Brake Front Shock Absorption Kickstand Battery Compartment Wheel Motor Charging Port Solid Front Wheel...
- Page 7 2. Dashboard & Power Switch Speedometer: Display the current speed of the scooter, as well as to display error codes. Bluetooth: The icon indicates that the scooter has been successfully connected to the mobile device. Modes: for pedestrian mode (the maximum speed is 6 km/h, it is easier to push the scooter along as you walk).
-
Page 8: Troubleshooting
4. Troubleshooting Error Code Failure Description Solution Check if the brake wire is connected properly or “E1/F1” Brake Failure replace the brake lever. Check if the accelerator wire is connected “E2/F2” Accelerator Failure properly or replace the accelerator. Check if the communication wire between the “E3”... -
Page 9: Assembly And Set
ASSEMBLY AND SET-UP 1. Unfold the scooter, erect the standpipe and 2. Insert the scooter's head into the standpipe, fasten the lock, then prop up the foot support. and pay attention to the orientation of the head Folding system, double insurance. of it during installation. -
Page 10: Charge Your Scooter
Please connect the DC charging port first, then connect to the socket power supply for charging, finally unplug the outlet when charging is complete. Your EV85F is fully charged when the LED on the charger changes from red (charging) to green. -
Page 11: How To Ride
HOW TO RIDE Warning: Wear a helmet, elbow pads and knee pads. 1. Turn on the scooter, and check the power indicator. Please read the instruction carefully before using. Please Note: Do not touch the accelerator when you are not ready to ride! 2. - Page 12 4. Release the accelerator and the speed will slowly 5. Tilt your body to the steering direction as you turn, drop to a stop; If you need to decelerate quickly, slowly and slowly turn the handlebar. squeeze the brake lever while releasing the accelerator. WARNING When sudden braking, you may risk serious injury due to loss of traction and falls.
-
Page 13: Smart Phone App
SMART PHONE APP SMART PHONE APP Your EV85F is an App-enabled electric scooter that works with most mobile devices. You must download the app in order to change certain features of your electric scooter. You could download the APP in the following two ways: Method 1: Search for the APP from either the App Store or Google Play Store to download. -
Page 14: Safety Reminder
SAFETY REMINDER Do not ride in the rain. Keep your speed between 5-10 km/h when you ride through speed bumps, elevator door stills, bumpy roads or other uneven surfaces. Slightly bend your knee to better adjust mentioned surfaces. Avoid hitting your head on door frames, Do not accelerate when going downhill, and brake in time elevators, and other overhead obstacles. - Page 15 To prevent inappropriate use of the scooter, the rear wheel of the scooter must be locked with a padlock when parked. Do not press the accelerator when Always steer clear of obstacles. you’re walking alongside the scooter. Do not hang bags or other heavy stuff Do not ride on one foot.
- Page 16 Do not try dangerous actions. Do not ride in traffic lanes or Do not abruptly change the steering residential areas where vehicles and direction at high speed. pedestrians are both allowed. Do not ride through puddles or any other Do not ride with anyone else, including (water) obstacles.
- Page 17 Do not keep your feet on the rear Do not touch the disc brake. mudguard. Do not let go of the handlebar while Do not try riding up or down stairs, nor riding. try jumping over obstacles.
-
Page 18: Safety Instructions
SAFETY INSTRUCTIONS 1. This electric scooter is a leisure device. But once they're in a public area, they'll be seen as vehicles, subjecting to any risks faced by vehicles. For your safety, please follow instructions in the manual and traffic laws and regulations set forth by government and regulatory agencies. We will not be liable for any property damage, personal injury, accident or legal dispute caused by the rider's inexperience or failure to use the product. - Page 19 5. Check the scooter before every use. When you note loosen parts, low battery alerts, flat tires, excessive wear, strange sounds, malfunctions and other abnormal conditions, stop riding immediately and call for professional support. 6. Please pay attention to the road surface when riding, avoid obstacles (including but not limited to wet and slippery ground, loose sand, gravel ground and ice surface).
-
Page 20: Folding Your Scooter
FOLDING YOUR SCOOTER *The scooter needs to be turned off before folding. Folding Hold the handlebar stem, turn it counterclockwise to open the safety hook and open the quick release lever. Align the bell and the buckle and hook them. Unfolding When opening, disengage the bell lever from the buckle on the mudguard. -
Page 21: Daily Care And Maintenance
DAILY CARE AND MAINTENANCE Cleaning If you see stains on the scooter’s body, wipe them off with a damp cloth. If the stains won’t scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. If you see scratches on plastic parts, use sandpaper or other abrasive materials to polish them. - Page 22 If the scooter is expected to be left idle for more than 30 days, please fully charge the battery and place it in a dry and cool place. Keep in mind to recharge it every 60 days to protect the battery from potential damage which is beyond limited warranty.
-
Page 23: Specifications
SPECIFICATIONS Electric Scooter Name Product EV85F Model Scooter: L × W × H 1081*476*1143mm Dimensions After Folding: L × W × H 1081*476*496mm Net Weight (kg) 15 kg (33 LBS) Weight Gross Weight (kg) 17.6 kg (38.8 LBS) Load Weight (kg) - Page 24 Unusual temperature/short circuit/under voltage/ Intelligent Battery Battery Pack overcurrent/dual overcharge/ Management System dual overdischarge protections Wheel Motor Motor Power (W) 350 W 100–240 ~ Input Voltage (V) Charging Adapter Output Voltage (V) 42 V Output Current (A) 1.5A Tire Tires 8.5 inch honeycomb solid tire Applicable Terrain Flat cement or asphalt roads...
-
Page 25: Product Warranty
2)The warranty will be performed in such a way that we shall decide whether to repair the defective parts or to replace them with working parts free of charge. EVERCROSS reserves the right to exchange the product for a replacement product of equal value if the product sent in cannot be repaired within a reasonable time or at a reasonable cost. - Page 26 CONTACT Please contact us directly if you experience any riding, maintenance, safety, errors/faults issues with your EVERCROSS product. E-mail Service: support@evercross.eu official_evercross official_evercross Evercross Official EVERCROSS https://www.evercross.eu/...
