- Page 1 ROLLER COMPACTOR Operation Manual MODEL NUMBER: TRC17H • — “ ” • ™ • › – ¥ To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. SAFETY INFORMATION 1.1 Operating Safety 1.2 Roller Safety 1.3 Engine Safety 1.4 Fuel Safety 1.5 Transporting Safety 1.6 Environmental Safety/Decommissioning 1.7 Emissions Information 1.8 Emission Control Label 2. TECHNICAL PERFORMANCE 3. SPECIFICATIONS 3.1 Roller Compactor Parts 3.2 Unpacking the Unit 4. - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK equipment! Your product is covered by the TOMAHAWK Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
TOMAHAWK®. The information contained in this manual is based on equipment’s production at the time of publication. TOMAHAWK® reserves the right to change any portion of this information without notice. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from TOMAHAWK®. -
Page 5: Operating Safety
1.1.7 ALWAYS clear the work area of any debris, tools, etc. that would constitute a hazard while the equipment is in operation. 1.1.8 ALWAYS use only the accessories or attachments recommended by the Tomahawk Power for this equipment. Using unapproved accessories or attachments can result in damage to the equipment and/or injury to the user. -
Page 6: Roller Safety
1.2 Roller Safety 1.2.1 ALWAYS keep the machine in proper running condition. DANGER Never operate the equipment in an explosive atmosphere or near combustible materials. Doing so could cause an explosion or fire, resulting in severe bodily harm or even death. DANGER WARNING Never disconnect any emergency or safety devices, as they are intended for operator safety. -
Page 7: Fuel Safety
1.3.4 DO NOT place hands or fingers inside engine compartment when engine is running. 1.3.5 NEVER operate the engine with heat shields or guards removed. 1.3.6 DO NOT remove the radiator cap while the engine is hot. High pressure boiling water will gush out of the radiator and severely scald any persons in the general area of the compactor. -
Page 8: Transporting Safety
CAUTION Always keep battery cables in good working condition. Repair or replace all worn cables. CAUTION 1.5 Transporting Safety 1.5.1 NEVER allow any person or animal to stand underneath the equipment while it is being lifted. NOTE: Before lifting, ensure that the equipment parts (hook and vibration insulator) are not damaged, and that screws are neither loose nor missing. -
Page 9: Emissions Information
Honda Engine Distributor. 2. TECHNICAL PERFORMANCE Take your paving projects to the next level with the Tomahawk 17"x12" Roller Compactor, powered by the industry-leading Honda GX160 engine. Built for professionals who demand top performance and reliability, this roller compactor delivers exceptional compaction force in a compact, easy-to-maneuver design, perfect for tight spaces and small job sites. - Page 10 Dry Net Weight Dimensions 12.0 x 13.6 x 13.0 in. (305 x 346 x 329 mm) TRC17H NOISE AND VIBRATION EMISSIONS Measured Sound Power Level in dB(A) Guaranteed Sound Power Level in dB(A) Guaranteed Sound Pressure Level at Operator Station in dB(A) Hand-Arm Vibration in m/s2 NOTE: 1.
-
Page 11: Roller Compactor Parts
3.1 Roller Compactor Parts 1. Handle Bar 6. Exciter 2. Handle Bar Adjuster Bolt 7. Exciter Drain Plug 3. Lifting Bale 8. Rubber Rollers 4. Engine 9. Belt Cover 5. Hand Grip • — “ ” • ™ • › –... -
Page 12: Unpacking The Unit
Do not throw away the packaging or packing material until you have inspected all parts and successfully operated the machine. Do not discard this operations manual. If any parts are missing or damaged, please contact TOMAHAWK® customer support by email at support@tomahawk-power.com or call (866) 577-4476. 4. INSPECTION 4.1 Engine Initial Servicing... -
Page 13: Engine Oil Check
5.1.4 If the oil level is low , fill to the edge of the oil filler hole UPPER LIMIT with the recommended oil type as listed in Oil Type Table. Figure 2. LOWER LIMIT FIGURE 2 TRC17H OIL TYPE Season Temperature Oil Type FUEL Summer 25°C or Higher... -
Page 14: V-Belt Tension
DANGER EXPLOSIVE FUEL! Motor fuels are highly flammable and can be dangerous if mishandled. DO NOT smoke while refueling. DO NOT attempt to refuel the compactor DANGER if the engine is hot or running. 5.4.2 Check if the belt is oil-soaked or "glazed" CORRECT V-BELT TENSION 10-15 MM CLUTCH... -
Page 15: Startup
6. STARTUP 6.1 Starting The Engine 6.1.1 Place the engine fuel valve lever in the “ON” position. FUEL VALVE FIGURE 9. LEVER 6.1.2 Move the throttle lever to the idle position. FIGURE 10. 6.1.3 Place the choke lever in the “CLOSED” position if starting a cold engine. -
Page 16: Operation
7. OPERATION 7.1 Operating the Compactor 7.1.1 Once the engine has started, quickly move the engine THROTTLE throttle lever to the run position. FIGURE 15. LEVER 7.1.2 Push and pull the handlebar to move the compactor forward and backward and flatten the interlocking block. IDLE 7.2 Shutting Down the Compactor FIGURE 15... -
Page 17: Engine Oil
NOTE: Never brush off the dirt, as brushing will force dirt into FIGURE 20 the fibers. Replace the filter element if very dirty. 8.1.3 Clean the foam element in warm, soapy water or a nonflammable solvent. DRAIN BOLT 8.1.4 Rinse and dry thoroughly. SEALING WASHER 8.1.5 Dip the element in clean engine oil and completely squeeze out the excess oil before installing. -
Page 18: Park Arrester Cleaning
8.5 Park Arrester Cleaning FIGURE 23 4 MM SCREW NOTE: Clean the spark arrester every year or 100 hours. PROTECTOR V-belt exhibits any of the above wear conditions, replace 5 MM 4 MM SCREW the V-belt immediately. SCREW 8.5.1 Remove the 4 mm screws (3) from the exhaust MUFFLER deflector, then remove the deflector. -
Page 19: Storage
9.6 When using the machine after a long storage period, check the level of engine oil before use. 10. REPLACEMENT PARTS 10.1 For replacement parts and technical questions visit www.tomahawk-power.com or scan the QR code on the front of this manual. 10.2 Not all equipment components are available for replacement. The illustrations within this manual are a convenient reference to the location and position of parts in the assembly sequence. - Page 20 SYMPTOM POSSIBLE PROBLEM SOLUTION Spark plug bridging? Check gap, insulation or replace spark plug. Carbon deposit on spark plug? Clean or replace spark plug. Short circuit due to defi cient spark plug Check spark plug insulation, replace if worn. insulation? Improper spark plug gap? Set to proper gap.
- Page 21 SYMPTOM POSSIBLE PROBLEM SOLUTION Air cleaner dirty? Clean or replace air cleaner. Improper level in carburetor? Check fl oat adjustment, rebuild carburetor. Weak in power, compression is proper and does not misfi re. Defective spark plug? Clean or replace spark plug. Improper spark plug? Set to proper gap.
-
Page 22: Maintenance Record
12. MAINTENANCE RECORD TOMAHAWK® tools are assembled with care and will provide years of service when properly maintained. Preventative maintenance and routine service are essential to the long life of your quipment. Adhere to reading through this manual thoroughly. You will find that you can do some of the regular maintenance yourself. -
Page 23: Equipment Warranty
13. EQUIPMENT WARRANTY Your new TOMAHAWK® equipment is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The TOMAHAWK® warranty is against defects in design, materials and workmanship. The following are not covered under the warranty: 13.1.1 Damage caused by abuse, misuse, dropping or other similar damage caused by or as... -
Page 24: Plate Compactor
ALL MUSCLE. PURE PERFORMANCE. Great for safe compaction of brick or stone patios. Item #: TPC80H 21 VIBRATORY PLATE COMPACTOR www.tomahawk-power.com... - Page 25 POUND FOR POUND THE HARDEST HITTING RAMMER Achieve 100% Compaction Ratings on field density tests Powered by Honda engines, Tomahawk Rammers are Item #: TR68H 3,550 LBS/FT TAMPING RAMMER www.tomahawk-power.com...
-
Page 27: Parts Manual
ROLLER COMPACTOR Parts Manual MODEL NUMBER: TRC17H • — “ ” • ™ • › – ¥... -
Page 29: Parts List
PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION CNP80GL001 Hex socket bolt M8X65 CNP80GL043 Skeleton oil seal 20*52*7 CNP80GL002 Spring washer￠8 CNP80GL044 Deep groove ball bearing 6304-2RS CNP80GL003 Flat washer￠8 CNP80GL045 Shaft of roller CNP80GL004 Hex socket bolt M8X30 CNP80GL046 Roller CNP80GL005 Spring washer￠8... - Page 30 30" Diameter, 4-Blade Assembly 10 ft Full Hydrostatic, 74 HP Hatz TRT60V TPT46H Adjustable Blade Pitch from 0-28 4 ft, Honda GX270/GX390, 0-28 Blade Pitch Diesel HAVE QUESTIONS? Contact us. We’re here to help! (866) 577-4476 Email us at sales@tomahawk-power.com...
- Page 31 Tilt, 8 Hour Run Time 4" Pump, Honda GX390, 581 GPM, 210 Amp Welder, 60% Duty Cycle, TW4H TWG210A Elevation: 92ft, Suction: 26ft Snow Plow Attachment & Bucket Extender Available 2000w, Includes Wheel Ki ASSEMBLED IN THE (866) 577-4476 www.tomahawk-power.com PARTS SOURCED GLOBALLY...
- Page 32 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today! TOMAHAWK®, LLC...
