jablotron JI-114C Quick Start Manual

jablotron JI-114C Quick Start Manual

Network camera outdoor 5 mpx - bullet
Hide thumbs Also See for JI-114C:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
www.jablotron.com
JI-114C (JABLOTRON 100+)
Print / Save as PDF
If you want to save to PDF, please select
'Save as PDF' when the print dialog opens.
Network camera outdoor 5 MPx –
bullet
switch to the manual for the JABLOTRON Mercury system
The JI-114C IP camera is used for video verification of events from the JABLOTRON security
system. Depending on the settings, the video recording is taken in a resolution of up to 5 MPx.
The footage is transmitted via LAN and the Internet to a secure server storage. The user has
access to live video via MyJABLOTRON application, to the recording created on the basis of set
events and according to the subscription service, to the continuously stored recording from the
camera. The camera is equipped with IR illumination to ensure image capture even in low light
conditions. The camera is intended for installation only by a trained technician with a valid
Jablotron certificate.

Advertisement

loading
Need help?

Need help?

Do you have a question about the JI-114C and is the answer not in the manual?

Questions and answers

Related Manuals for jablotron JI-114C

Summary of Contents for jablotron JI-114C

  • Page 1 JABLOTRON Mercury system The JI-114C IP camera is used for video verification of events from the JABLOTRON security system. Depending on the settings, the video recording is taken in a resolution of up to 5 MPx.

  • Page 2: Camera Function

    The maximum number of video sequences is limited according to the selected type of service. Connection to ARC – access to video data from the camera is granted to a security agency for visual verification of an alarm event. Fig. 2: Diagram of JABLOTRON CLOUD functioning Installation...
  • Page 3 As standard, the camera is powered over LAN using PoE. Alternatively, the camera can be connected via a cable terminated with an RJ-45 data connector for LAN connection and a 12V DC, 500 mA power connector. A waterproof LAN connector housing is included, preventing moisture from penetrating the data connector contacts.
  • Page 4 9. Remove the protective film and polish the camera of any dirt and fingerprint marks, should be any present. Installation procedure for the camera without using the mounting socket If the camera is to be installed on a support that can be used to protect the cables and connectors from intentional damage (e.g., lowered ceiling, plasterboard ceilings and partitions, etc.), the camera can be installed directly on such a support and the cables and connectors can be pushed through the prepared hole.
  • Page 5 Caution: The camera is not physically connected to the JABLOTRON 100 system, it doesn´t occupy any positions. Power from the alarm system is not required and the camera status is not monitored by the control panel. Registration to the server All setting options below can only be set/changed by the company that registered the camera.
  • Page 6 bitrate. Video retention period (record export to MyJABLOTRON): 3 days / 7 days / 15 days / 30 days Depending on the subscription service, 10 or 60 clips are available. The recordings are deleted either after the set period of time or when the number of clips is exhausted. Only after this selected retention period, it is also possible to request the export of video clips.

  • Page 7: Technical Parameters

    camera under the cover, which is secured with two screws. After unscrewing the cover, it is necessary to hold the button, connect the power and hold the button for about 15 seconds. Recommendations In the case of connecting more cameras to the system, it is necessary to take into account a larger data flow and therefore to ensure a separate data flow for each camera in the upload direction.
  • Page 8 European Union: directives No: 2014/30/EU, 2011/65/EU, when used as intended. The original Declaration of Conformity is available at www.jablotron.com in the Downloads section. Importer: streamhosting.cz, s. r. o., Kališnická 10, 130 00, Praha 3 Note: Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling.
  • Page 9 manuals.jablotron.com...
