Promovec 50951 Quick Start Manual

Lcd mini display with buttons

Advertisement

Quick Links

LCD MINI DISPLAY
WITH BUTTONS
QUICK START
2021-04-REV 2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 50951 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Promovec 50951

  • Page 1 LCD MINI DISPLAY WITH BUTTONS QUICK START 2021-04-REV 2...
  • Page 2: Table Of Contents

    Table of contents Display - LCD Mini with buttons ..........3 Turn display on/off .................3 Light ......................4 Battery indicator .................4 Assist functions ..................5 Trip counter ...................6 Wheel size settings .................6 Troubleshooting .................7 PAGE 2...
  • Page 3: Display - Lcd Mini With Buttons

    DISPLAY - LCD MINI DISPLAY WITH BUTTONS The display is mounted on the handlebar and acts as both battery indicator and assist level function. Use the 3 buttons on left side to navigate. Display Speed Level up On/Off Assist level Level down Trip counter Battery indicator...
  • Page 4: Light

    LIGHT Turn on/off the light by pressing the "level up" button for 1-2 seconds. Level up BATTERY INDICATOR The battery indicator is shown on the left side of the display and allows you to see the approximate battery level using 4 segments. When reaching the lowest level, it will start flashing.
  • Page 5: Assist Functions

    ASSIST FUNCTIONS The display has 2 different assist functions: * Assist levels (1-4) - selectable by using the "level up" and "level down" buttons. Level 4: Highest level Level 1: Lowest level Level 0: Assist function disabled * Walk assist: If the bike support this, it is activated by holding down the "level down"...
  • Page 6: Trip Counter

    TRIP COUNTER/ODOMETER This display can change between trip counter and odometer (total distance): Change between trip counter and odometer by pressing the "power button" shortly. The odometer cannot be reset. Resetting the trip counter: Keep "On/Off" and "Level down" pressed simultaneously for 2-3 seconds. On/Off Trip counter Level down...
  • Page 7: Troubleshooting

    TROUBLESHOOTING An error code appears on the display in case of any system errors. The error is indicated by a number, which will be displayed. If an error is displayed, it is a signal about an error in the electrical system. The motor can not start before the error is remedied.
  • Page 8 Promovec manufactures e-bikes for major international brands and advanced battery solutions for e-bikes In the production of all Promovec's products we seek sustainable and high- quality solutions to best serve both the planet and our customers. For more information about Promovec visit www.promovec.com or drop by one of our social media platforms.
