- Page 1 Minimal Control QUICK START 2022-05-REV 02...
-
Page 2: Table Of Contents
CONTENT DISPLAY ....................3 FUNCTIONS AND BUTTONS ............4 DISPLAY INFO ..................5 THROTTLE ....................6 WHEEL SIZE SETTINGS ..............7 TROUBLESHOOTING ................8 PAGE 2... -
Page 3: Display
DISPLAY The display is accessed with 5 buttons and the throttle from the left side of the handlebar. Read this guide for more information about display functionality and bike information. Light ON/OFF Speed indicator Units Assist-level Up/Down Menu Assist-level ON/OFF Batteri indicator See next page for a detailed walkthrough of functionalities and the display PAGE 3... -
Page 4: Functions And Buttons
FUNCTIONS AND BUTTONS Menu Light ON/OFF Press the Menu button to switch between Toggle the light ON/OFF by pressing the ODO and Trip Counter. TRIP is reset by button. NB! The background light will holding down the Menu button for 2 dim down when the light is “ON”. -
Page 5: Display Info
DISPLAY INFO Current speed Here the current speed is displayed Units Displayed in km/h or mp/h. If the field is blank, then mp/h is displayed. Toggle by pressing the "Down" button for 10 seconds Assist-level The selected assist-level is displayed in the right side of the display. -
Page 6: Throttle
THE THROTTLE When the throttle is turned downwards then the assist functionality is bypassed and the „Booster effect“ is activated. Release the throttle and the system returns to assist mode. The throttle have more than one purpose, for example: • When pushing the bike up a hill, turning the throttle will activate “walk-assist”. -
Page 7: Wheel Size Settings
WHEEL SIZE SETTINGS The speed display can be adjusted by changing the wheel size. The wheel size is found by measuring the inner circumference of the tyre or by reading the numbers on the side of the tyre (Check the table below for reference). Setting wheel size 1. -
Page 8: Troubleshooting
TROUBLESHOOTING If an error is displayed then it is a signal about an error in the electrical system. The error must be remedied before the motor is able to start. Check the table on this page for more information covering error codes. ERROR CODE MEANING SOLUTION...
