Summary of Contents for Promovec Display Graphic Slim D700
- Page 1 Display Graphic Slim D700 QUICK START 2022-06-REV 01...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION - DISPLAY D700+ ............3 DISPLAY LAYOUT .................... 4 ASSIST FUNCTIONS ..................5 HEADLIGHT AND BLUETOOTH CONNECTION........5 DISPLAY VIEWS ....................6 DATA RESET ....................... 7 BATTERY INDICATOR ..................7 TROUBLESHOOTING ..................8 SETTINGS ......................9 EXTENDED FEATURES BY MOBIL APP ..........12 CONNECTING NEW DEVICES ..............13 TROUBLESHOOTING IN APP ..............14 YOUTUBE VIDEOS ..................14... -
Page 3: Introduction - Display D700
INTRODUCTION - DISPLAY D700+ ON/OFF Press and hold to turn ON/OFF MENU Toggle between views and go to settings UP/DOWN • Adjust assist level Navigate in and adjust settings • The display is operable by four buttons from the left side of the handlebar. •... -
Page 4: Display Layout
DISPLAY LAYOUT Boot display Battery indicator Front-light indicator Speed Unit Mobile connection Trip counter Unit Assist level PAGE 4... -
Page 5: Assist Functions
ASSIST FUNCTIONS The display has 2 different assist functions: • Assist levels (1-5), see picture top right. Select with up/down buttons. • Walk assist function, press and hold the down button. In "Walk-assist" state the bike will drive 6 km/h without the use of pedals regardless of the assist-level setting. -
Page 6: Display Views
DISPLAY VIEWS Toggle between views with "MENU" Standard view: When the speed is > 0 the display will return to standard view after a few seconds. Standard View 1: AVG - Average speed - Resettable MAX - Maximum speed registered - Resettable TRIP - Trip distance - Resettable View 1 View 2:... -
Page 7: Data Reset
DATA RESET • Turn on the display and wait 10 seconds • Go to View 1 • Press and hold "MENU" • The "Clear data" window displays CLEAR DATA • Select "YES" or "NO" with BATTERI INDICATOR Battery level displays with and icon and in percentage. When the display boots, the battery icon will flash as if it is full. -
Page 8: Troubleshooting
TROUBLESHOOTING Errors displays, with a code and a description in the display info area. An error code is a signal about an error in the electrical system. When an error displays, it must be remedied before the motor is able to start. Check the table on this page for more information covering error codes. -
Page 9: Settings
SETTINGS Press and hold the "MENU" button, within 10 seconds after rebooting the display, to access the settings. Navigate through the settings with "UP" or "DOWN" and select with "MENU" EXIT: Return to Standard display with "MENU" UNIT - Select either KM/H or MP H EXIT: Select with "MENU"... - Page 10 SETTINGS AUTO OFF: Set the timer for AUTO OFF, select with "MENU". Select OFF if the display must stay ON EXIT: Select with "MENU" to return to "SETTINGS" PSWORD - When the value is set to ON, the user must set a password.
- Page 11 SETTINGS BATIFO - Information only - Displays battery state Press and hold "MENU" to return to "SETTINGS". CTLIFO - Hardware information, for dealers and technicians Press and hold "MENU" to return to "SETTINGS". AVDSET - Only for dealers and technicians. Requires a password.
-
Page 12: Extended Features By Mobil App
SETTINGS RESET: Warning! Only for dealers. EXTENDED FEATURES BY MOBIL APP When the phone is connected by Bluetooth, it is possible to access more real time features such as: • Current speed. • Trip counter. • Assist type (eco/speed/dist) • •... -
Page 13: Connecting New Devices
CONNECTING NEW DEVICES Attention! Download the app “Promovec Connect+” to access the above functions. Links: IOS: https:/ /apps.apple.com/gb/app/ebike-connect/id1458723615 Android: https:/ /play.google.com/store/apps/details?id=com.ektos.e.bike.client Turn on the Bluetooth, open for the app and the follow the onscreen instructions. Start by turning on the display on the bike. -
Page 14: Troubleshooting In App
TROUBLESHOOTING IN APP If problems occur when using the app try the following list to troubleshoot: 1. Turn on Bluetooth in the mobile settings 2. Restart the app 3. Update Connect+ to the latest version 4. Make sure the Smartphone is not connected in both the app and in Bluetooth settings Contact you dealer if this list does not solve the problem. - Page 15 PAGE 15...
- Page 16 Promovec is a Danish e-bike developer and manufacturer. Promovec manufactures e-bikes for major international brands and also supplies advanced battery technology for the e-bikes. For more information about Promovec visit www.promovec.com or drop by our various social media platforms. DANISH DESIGN...
