I:\Drawings\SPECS\Assembly BOOK DWGS\edison\eds edison install.dwg, 4/16/2024 11:40:04 AM, Microsoft Print to PDF
Hardware Included:
#8 x 1-1/2"
FH Phillips Screw
M6 x 10mm
PH Truss Screw
Tools Required:
• 5/32" Allen Wrench
• #2 Phillips
Assemble units only as described in this
!
guide. All fasteners must be tightened
securely and checked regularly. Failure to
CAUTION
do so could cause instability and injury.
Edison
5/16-18 x 7/8"
Washer
Particle Board PH Screw
3" locking caster
#10 x 3/4"
10-32 x 1/2"
PH Tap Tite Screw
Tables
1/4-20 x 60mm
Joint Connector Bolt
instructions-edison-240417

Advertisement

loading
Need help?

Need help?

Do you have a question about the Edison and is the answer not in the manual?

Questions and answers

Related Manuals for Media Technologies Edison

Summary of Contents for Media Technologies Edison

  • Page 1 Edison Tables I:\Drawings\SPECS\Assembly BOOK DWGS\edison\eds edison install.dwg, 4/16/2024 11:40:04 AM, Microsoft Print to PDF Hardware Included: #8 x 1-1/2” 5/16-18 x 7/8” #10 x 3/4” 10-32 x 1/2” 1/4-20 x 60mm FH Phillips Screw Washer Particle Board PH Screw PH Tap Tite Screw...
  • Page 2 Tables Step 1 – Assembling the Rolling Chassis I:\Drawings\SPECS\Assembly BOOK DWGS\edison\eds edison install.dwg, 4/16/2024 11:41:00 AM, Microsoft Print to PDF Snap casters into pre-installed caster socket in bottom of each vertical leg. Fasten steel end frame weldment to mid frame using ¼-20 x 60mm JC Bolt through end frame into threaded weld plate in the mid frame.
  • Page 3 Edison Tables I:\Drawings\SPECS\Assembly BOOK DWGS\edison\eds edison install.dwg, 4/16/2024 11:41:42 AM, Microsoft Print to PDF Step 3 – Attach Bottom Shelf (if applicable) Place bottom shelf upon supports installed in step 2. Fasten bottom shelf through brackets and support rail using #10 x ¾”...
  • Page 4 Storage units are secured to Edison Table using #8 x 1-1/2” FH Screws through the storage unit subtop panels pre-drilled holes, into the bottom of the Edison top panel. Low profile storage such as the row of drawers have holes through the bottom panel to aid the fastening of the storage unit to Edison top.
