Summary of Contents for filtreau Excellent COMBI DRUM 30/45L PUMP
- Page 1 Manual Excellent Line Filters English...
- Page 2 Symbolism and terms Warning symbols and/or signal words The warning symbols and/or signal words below are covered in this manual: Danger imminent due to electric shock Its meaning is that there is a danger due to electric shock. This could lead to serious or fatal injury and/or serious damage to the appliance or environment if safety instructions are not followed.
-
Page 3: Warranty Conditions
Meaning of symbols on the product The warning symbols and/or signal words below are covered in this manual: Recycling The appliance must not be disposed of together with normal household waste. It should be disposed of at an offi cial collection point, such as the Environmental Centre, or at the point of sale when purchasing a new similar product. -
Page 4: Operation
In addition, the reliability and service life of the product will be increased. Please read this information thoroughly before installing the Filtreau Excellent drum fi lter and keep the instructions with the product! If there are any uncertainties regarding the operating instructions, always contact your Filtreau Excellent dealer. - Page 5 Placing PUMP and GRAVITY Installation of drum fi lter pump-fed system For the drum fi lter pump-fed set-up, the pond pump is placed in the pond at the bottom. The diff erence with a pump-fed system is that it is easy to connect to an existing pond. The pond pump is placed in the deepest part of the pond.
- Page 6 Excellent Line Technical drawing Excellent Line Illustration 1. Parts - Manual fl ush button - On/off button - UVC socket - Rinse pump socket - Pump socket - Motor socket 1F- Plug control box - Plug fl oater - Plug cover protection - Fuse 1 - Fuse 2 - Plug UVC...
-
Page 7: Maintenance & Disassembly
/ fl oating debris decreases, so will the fl ushing cycle. When adjusting the fl oat / opening the lid (A), the power supply is always disconnected by the lid guard! All Filtreau excellent fi lters are equipped with a 120micron polypropylene fi lter panel. Maintenance & disassembly See illustration 1. -
Page 8: Safety First
Floater Technical drawings 3000045 stainless steel fl oater Illustration 2. Safety fi rst The fl oat switch has several circuits, the exact circuits with their meanings are explained below. Before using/installing the system, read the entire manual carefully!If in doubt, always consult a recognised installer. - Page 9 Excellent Line Replace Strainer Panel See illustration 1 & 3. (15A) When you notice that the sieve panel shows signs of wear, it is important to replace it as soon as possible with a new sieve panel (15A). This will maintain the optimal performance of the fi lter. Disconnect the power supply and shut off the water circuit.
- Page 10 Excellent Line Replace UV-C lamp Illustration 4. Disconnect the power supply and shut off the water circuit. Remove the housing cover. Ensure that the water can drain from the fi lter. Loosen the locking nut (2F) and disconnect the UV-C lamp (2C) from the lamp holder.
- Page 11 Excellent Line Technical drawing Excellent Line Control Box Illustration 5. The control box consists of the following functions: (1I) (1J) (1F) To operate the control box, check the connection of fuses . Then insert the plug into the socket. (1G) The box has both automatic cleaning by means of a fl...
-
Page 12: Address Details
The best solution for water pollution Address details: Contact details: Website: Ekkersrijt 7418 Phone: +31(0)499-462929 www.fi ltreau.nl 5692HK Son E-mail: info@wimaca.nl The Netherlands...
