SMC Networks WBR14S-N2 - FICHE TECHNIQUE Overview

WIRELESS
OVERVIEW
The Barricade™ N Broadband Router (SMCWBR14S-N2) is the perfect all-in-
one networking solution for connecting and sharing your high speed cable/
xDSL internet connection. Designed for the home, this platform independent
multi-functional router combines a 4-port 10/100 LAN switch, High speed
Wireless-N (802.11n) access point, NAT firewall with Stateful Packet Inspec-
tion (SPI) and User friendly web-based management interface in one conve-
nient device.
The built-in wireless access point is Wi-Fi CERTIFIED™ for full compliance
with the 802.11n standard, as well as the popular Wireless-G (802.11g) and
Wireless-B (802.11b) standards. This next generation wireless networking
standard utilizes advanced MIMO (Multiple-In, Multiple-Out) technology to
deliver incredible speed and range. With wireless speeds up to 300Mbps
and up to 4x the coverage, the SMCWBR14S-N2 provides better perfor-
mance than existing 802.11g technology. Upgrading to Wireless-N provides
an excellent solution for sharing an Internet connection and files such as
FEATURES
Share your high speed cable/xDSL internet connection
4-port 10/100 LAN switch with auto MDI-MDIX
Built-in Wireless-N (802.11n) access point
NAT firewall with Stateful Packet Inspection (SPI)
WPA/WPA2 Encryption
Wi-Fi Protected Setup™ (WPS)
Web-Based management interface
www.smc.com
SMCWBR14S-N2
Wireless N 4-port Broadband Router
video, music, photos, and documents. With security being a key consider-
ation, SMCWBR14S-N2 supports the latest WPA and WPA2 wireless encryp-
tion standards, which prevent unauthorized access to wireless networks and
ensure data is secure. Wireless security can also be set up easily using Wi-Fi
Protected Setup™ (WPS) that enables push button or PIN configuration.
The integrated NAT firewall with SPI provides protection from hackers and
Denial of Service attacks by analyzing individual data packets, to ensure
that only authorized packets are allowed access to the network. Using the
Access Control feature parents or network administrators can block certain
websites, limit web access based on time or dates, and/or block internet
access for applications like P2P utilities or games. Finally, configuration of
your internet connection and advanced router functions is made simple and
straightforward with the EZ Installation Wizard and intuitive web-based man-
agement interface.
BENEFITS
Simply connect your cable or xDSL modem with Ethernet connection to the
10/100 WAN port for instant always on internet.
Directly connect four computers or expand your network by connecting additional
switches. Auto MDI-MDIX means you do not need to worry about cross-over cables.
With wireless speeds up to 300Mbps and up to 4x the coverage, the
SMCWBR14S-N2 provides better performance than existing 802.11g technology.
Provides protection from hackers and Denial of Service attacks by analyzing
individual data packets, to ensure that only authorized packets are allowed access
to your network.
Prevents unauthorized access to your wireless network and insures your data is
secure.
Makes wireless security setup easy with push button and PIN configuration methods.
Simple and straightforward set-up with the intuitive web-based management
interface and EZ™ Installation Wizard.
