SMC Networks SMCWBR14-G Specifications

OVERVIEW
The Barricade™ g 2.4GHz 54Mbps Wireless Cable /DSL
Broadband Router (SMCWBR14-G) is the perfect networking
solution for the user that is looking for a simple, all-in-one
home or small offi ce network product.
This platform independent multi-functional router com-
bines a 4-port 10/100 Mbps dual-speed switch with
Automatic MDI-MDIX feature, and a high speed 54Mbps
wireless access point with security features that include
802.1x for authentication, Wi-Fi Protected Access (WPA),
MAC address fi ltering and 64/128-bit Wired Equivalent
Privacy (WEP).
FEATURES
Share your Cable/DSL connection
EZ 3-Click Installation Wizard
802.11g/ 802.11b compliant High Speed Wireless LAN connection
4-port 10/100 Mbps Auto MDI-MDIX switch and one
detachable antenna
Stateful Packet Inspection (SPI) Firewall
Access Control and URL Blocking
High Level of Security
www.smc.com
SMCWBR14-G
2.4GHz 54Mbps Wireless Cable/DSL Broadband Router
The SMCWBR14-G also includes a firewall with Stateful
Packet Inspection, web-based network management and
support for Virtual Private Network (VPN) pass-through
for secure remote offi ce connections.
Supporting NAT, the SMCWBR14-G can provide simultaneous
Internet access for multiple PCs using a single purchased IP
address. Finally, installation is made simple and straight-
forward with the EZ 3-Click Installation Wizard utility.
BENEFITS
Ability to connect to cable/xDSL modem for instant internet
access. Allows a single broadband Internet connection to be
used by multiple computers. Share fi les, printers, and other
devices on a network.
A new and improved way to install your Wireless Barricade. In 3
simple clicks, you will be connected to the Internet.
The new Barricade G offers a high data rate that is up to 5 times
faster than the widely used 802.11b wireless LAN and is backward
compatible with existing 802.11b network devices.
Multi-port auto-sensing switch for integration to your wired LAN
with Auto MDI-MDIX support. No need for the use of crossover
cable. One detachable antenna can be replaced with SMC high gain
antennas for added performance and coverage.
Robust Stateful Packet Inspection fi rewall provides a high level of
security against Denial of Service (DoS) attacks. The SPI fi rewall
analyzes each individual data packet as it passes through SMCBR14-G
and ensures that only authorized packets can access the local
network.
Access Control based on a pre defi ned-scheduled time, IP
address fi ltering, and Mac Address Filtering. Parental control to
protect your family with URL blocking capability.
Provides secure data transmissions across the network by using
robust security features include 802.1x for authentication, Wi-Fi
Protected Access (WPA), 64-bit/128-bit WEP encryption, disable
SSID broadcast and MAC address fi ltering.
