- Page 1 STEALTH 3D 3000 (PCI) INSTALLATION GUIDE Rel. 0996 Copyright by Diamond Multimedia Systems Inc.
-
Page 2: Table Of Contents
STEALTH 3D 3000 - INSTALLATION GUIDE Table of Contents Introducing your Stealth 3D 3000 ......................3 System Compatibility..........................3 Memory Extension ..........................3 Installing the Card.............................5 Installing Windows 95 Software........................6 Installing the Basic Software and Utilities .....................6 InControl Tools 95 for Windows® 95 ....................7 Quick start instructions..........................7... -
Page 3: Introducing Your Stealth 3D 3000
Memory Extension Necessity of Memory Extension Your Stealth 3D 3000 is fitted with 2 MB VRAM or 4 MB VRAM. This memory size is adequate for many applications on the market. 4 MB VRAM is recommended for higher resolutions, faster refresh rates, and/or higher color depths. - Page 4 Extending Memory Warning! Prevent static electric damage. Static charges can cause severe damage to microcircuits, but here are some easy ways to see that it doesn't happen: Hold the cards on the edges only. Don't touch edge connectors or exposed circuitry.
-
Page 5: Installing The Card
Installing the Card The installation is easy and straightforward. These installation instructions presume that you are familiar with your computer system. You may need to seek assistance from your dealer or consult your computer operations guide. Warning! Prevent static electric damage. Static charges can cause severe damage to microcircuits, but here are some easy ways to see that it doesn't happen: Hold the graphics card on its edges only. -
Page 6: Installing Windows 95 Software
Installing Windows 95 Software Installing the Basic Software and Utilities In order to use your card in your PC it is necessary to install a package of basic programs, regardless of the operating system in use. Please execute the following steps in order to install the basic software. -
Page 7: Incontrol Tools 95 For Windows® 95
InControl Tools 95 for Windows® 95 InControl Tools 95 provides a set of easy-access display and desktop utilities that help you maintain a picture perfect environment for work or pleasure. With InControl Tools 95 you can: Use a popup menu to instantly switch desktop and viewport resolutions and zoom in and out on your viewport. -
Page 8: Installing Windows 3.1X Software
Installing Windows 3.1x Software Installing the Basic Software and Utilities In order to use your board in your PC it is necessary to install a package of basic programs, regardless of the operating system in use. Please execute the following steps in order to install the basic software. -
Page 9: Autocad For Windows - Bigfocus Driver
AutoCAD for Windows - BigFocus Driver The BigFocus driver is supplied for use with AutoCAD 13 running under Windows 95 or under Windows NT. The driver allows view and layer manipulation, spyglass lens, bird's-eye view, and view export. Using BigFocus is self-explanatory but if you should need further information, consult the integrated online help and/or the separate BigFocus documentation. -
Page 10: Having Problems
If you have tried all above suggestions, please contact the Technical Support for additional help. Note : The Stealth 3D 3000 card uses the following address areas. I/O Address 3B0-3DF... -
Page 11: Video Problems
Video Problems Video Flicker Scrambled Video Screen Display is Small Monitor is not Listed Solutions Video Flicker Increase the vertical frequency for the resolution that you are using. Do not specify a frequency that exceeds your monitor´s frequency range. Scrambled Video ... -
Page 12: Difficulty Starting Windows And Other Applications
Difficulty Starting Windows and Other Applications Solutions Check your CONFIG.SYS file for a memory manager like QEMM386, EMM386, or 386MAX. A memory manager may be mapping devices in the video area, particularly in the “A000” or “B000” page. All Diamond cards use the memory area “A000-C7FF”... -
Page 13: General Protection Fault (Gpf) In Windows
General Protection Fault (GPF) in Windows Solutions Follow the steps below to determine the cause of the problem. Change your display driver to ‘Microsoft Standard VGA’ - not ‘VGA Version 3.0’ If the problem still exists, an application may have been corrupted or has a conflict with Windows. -
Page 14: Diamond Tech Support Team Europe - If You Need Help
Diamond for technical support: The exact designation of your Diamond Multimedia product The operating system you are using, as well as information about the computing environment in which you use your product ... -
Page 15: Diamond's Online Services: Bbs, Compuserve, Internet
Diamond’s Online Services: BBS, CompuServe, Internet Among other things, you can find the following kinds of information in the Diamond BBS as well as in Diamond’s CompuServe forums and Internet services: the most current releases of Diamond drivers and software updates; ... -
Page 16: Diamond's Fax-Back System
Diamond’s Fax-back System You also have access to a variety of information through our fax-back system. All you need is a touch-tone phone to select documents such as: technical tips, tricks and suggestions, compiled by our support staff; answers to frequently asked questions; and ... -
Page 17: Trademarks, Copyright And Warranty
Trademarks, Copyright and Warranty Trademarks The Stealth 3D 3000 is a trademark of Diamond Multimedia Systems, Inc. All other products named in this manual are either trademarks or copyrights of their respective owners. Copyright Notice This manual is copyrighted. All rights reserved. This document may not, in whole or... -
Page 18: Fcc And Ce Information
FCC and CE Information This device complies to CE Certification pursuant to EN55002 IEC 801-2, 1991. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
