MELSECNET/10
Network Module
A1SJ71QLP21,A1SJ71QLP21S
A1SJ71QLR21,A1SJ71QBR11
Thank you for buying the Mitsubishi general-purpose programmable
controller MELSEC-QnA Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
© 1999 MITSUBISHI ELECTRIC CORPORATION
User's Manual
MODEL A1SQ-NET10-M-U-JE
MODEL
CODE
IB(NA)-0800091-F(1112)MEE
(Hardware)
13JQ87

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELSECNET/10 A1SJ71QLP21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi MELSECNET/10 A1SJ71QLP21

Summary of Contents for Mitsubishi MELSECNET/10 A1SJ71QLP21

  • Page 1 MELSECNET/10 Network Module User’s Manual (Hardware) A1SJ71QLP21,A1SJ71QLP21S A1SJ71QLR21,A1SJ71QBR11 Thank you for buying the Mitsubishi general-purpose programmable controller MELSEC-QnA Series Prior to use, please read both this manual and detailed manual thoroughly and familiarize yourself with the product. MODEL A1SQ-NET10-M-U-JE MODEL...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. In this manual, the safety precautions are classified into two levels: "...
  • Page 3 [Design Precautions] WARNING When there are communication problems with the data link, the communication problem station will enter the following condition. Build an interlock circuit into the sequence program that will make sure the system operates safely by using the communication state information. Not doing so could result in erroneous output or erroneous operation.
  • Page 4 [Installation Precautions] CAUTION Use the programmable controller in an environment that meets the general specificaitons contained in CPU module user’s manual. Using this programmable controller in an environment outside the range of the general specifications could result in electric shock, fire, erroneous operation, and damage to or deterioration of the product.
  • Page 5 [Wiring Precautions] WARNING Before installation or wiring, be sure to shut off all phases of the external power supply used by the system and the one for the network (A1SJ71QLP21S). Failure to do so may cause electric shocks or damage the product. CAUTION Always connect the FG terminals to the ground using class D (class 3) or higher grounding exclusively designed for programmable controller.
  • Page 6 [Startup and Maintenance Precautions] CAUTION Please read this manual thoroughly and confirm the safety before starting online operations (especially, program modifications, forced outputs, and operating status modifications), which are performed by connecting the GX Developer via the MELSECNET/10 network system to a running CPU module of other station.

  • Page 7: Conditions Of Use For The Product

    CONDITIONS OF USE FOR THE PRODUCT (1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; and...
  • Page 8 PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.
  • Page 9 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 10: Table Of Contents

    CONTENTS 1. OVERVIEW ....................1 2. PERFORMANCE SPECIFICATIONS ............. 2 3. HANDLING ..................... 7 3.1 Cable length restrictions between stations ..........7 4. THE NAME AND SETTING OF EACH PART ..........8 5. WIRING ......................16 5.1 Precautions for Laying Optical Fiber Cables .......... 16 5.2 Precautions when Installing the Coaxial Cables ........

  • Page 11: About The Manuals

    System Reference Manual COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES (1) Method of ensuring compliance To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated into other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals.

  • Page 12: Overview

    1. OVERVIEW This manual explains the specifications and names of each part, etc., of the A1SJ71QLP21(S),A1SJ71QLR21 and A1SJ71QBR11 model MELSECNET/10 network module (abbreviated as Network Modules) which are used with MELSECNET/10 network system of the MELSEC- QnA series. (1) The use, cable used and installation position of the Network Modules are indicated on the following chart.

  • Page 13: Performance Specifications

    2. PERFORMANCE SPECIFICATIONS The performance specifications for Network Modules are indicated as follows. (1) A1SJ71QLP21, A1SJ71QLP21S Specifications Item A1SJ71QLP21 A1SJ71QLP21S 8192 points Maximum link points per 8192 points network 8192 points PLC to PLC <2000 bytes network • Remote master station → remote I/O station <1600 bytes Maximum link •...
  • Page 14 Specialised training and specific tools are required to connect the connector to the optical-fiber cable; the connector itself is a custom product. Please contact your nearest Mitsubishi Electric System Service Corporation when purchasing these items. The weight for the hardware version F or earlier is 0.30kg.
  • Page 15 Example: Set 10 as the "Starting I/O No." when the module is mounted on slot 0. (Set 0 as the "Starting I/O No." when 0 has been set to slot 0 on the "I/O assignment" tab screen.) For general specifications of the network module, refer to the user's manual for the programmable controller CPU that is to be used.
  • Page 16 (2) A1SJ71QLR21, A1SJ71QBR11 Specifications Item A1SJ71QLR21 A1SJ71QBR11 8192 points Maximum link points per 8192 points network 8192 points PLC to PLC <2000 bytes network • Remote master station → remote I/O station <1600 bytes Maximum link • Remote I/O station → remote master station points per Remote I/O station...
  • Page 17 Specifications Item A1SJ71QLR21 A1SJ71QBR11 • Loop back function due to abnormality detection and cable disconnection (A1SJ71QLR21) • Diagnostic function for local link circuit check • Prevention of system down due to shifting to control station (Only for PLC to PLC networks) RAS function •...

  • Page 18: Handling

    3. HANDLING 3.1 Cable length restrictions between stations (1) The main modules case is made of plastic, so do not drop it or subject it to strong impacts. (2) Do not dismount the printed wiring board from the case. It may damage the module.

  • Page 19: The Name And Setting Of Each Part

    4. THE NAME AND SETTING OF EACH PART Indicates the name and setting of each part of Network Modules. A1SJ71QLP21 A1SJ71QLP21S Display of Display of hardware version hardware version D or earlier F or earlier A1SJ71QLR21 A1SJ71QBR11...
  • Page 20 Name Contents Name Status Contents Normally operating. WDT error occurred (hardware failure) Operating as control station or remote master station Operating as sub-control station S.MNG or remote sub-master station The position of switch for Multiplex transfer in execution DUAL (OFF: Multiplex transfer not the display switch over executed)
  • Page 21 Name Contents Name Status Contents Error occurred when receive data processing is delayed OVER <Cause> Hardware failure, cable fault, noise, A1SJ71QLP21 etc. • Consecutive 1s exceeding the specified number were received. • Length of received data is too short. AB.IF <Cause>...
  • Page 22 Name Contents Station number Station number setting (factory setting at time of shipping: 1) *3 setting switch Type Setting 1 to 64 :Station number PLC to PLC Other than 1 to 64 :Setting error (The SW.E. LED network ST.NO. turns ON) second :Remote master station Remote I/O...
  • Page 23 Name Contents Mode setting (factory setting at time of shipping: 0) Mode Name Contents Online (automatic Data link with automatic online online return effective) return effective Not used (Setting to this turns on the SW.E. LED.) Offline Disconnects the host station. Checks the forward loop of the Forward loop test whole network system.
  • Page 24 Name Contents Conditions Operation condition setting setting switch (factory setting at the time of shipping: all off) Contents REM. N.ST/ MNG/ Network type PLC to PLC network Remote I/O network D.S.M P.S.M Normal station/ D.PRM Control station/ parallel ST. SIZE Station type Multiple sub master sub masters station *6...
  • Page 25 Name Contents Connect the optical fiber cable. A1SJ71QLP21: hardware version G or later A1SJ71QLP21S: hardware version E or later Front For- For- ward verse verse ward Optical Connector fiber cable (A1SJ71QLP21(S)) A1SJ71QLP21: hardware version F or earlier A1SJ71QLP21S: hardware version D or earlier Front For- For-...
  • Page 26 Name Contents Connect the coaxial type cable. Connector Front For- For- (A1SJ71QLR21) verse ward ward verse Coaxial Cable Connect the F-type connector. F-type connector Connector (A1SJ71QBR11) When preventing loop back by turning OFF the power source of the External power programmable controller CPU, supply an external power source.

  • Page 27: Wiring

    5. WIRING 5.1 Precautions for Laying Optical Fiber Cables (1) The optical fiber cable type that can be used differs depending on the station to station distance. Type Distance between stations SI optical fiber cable 500m (1640.5 ft.) H-PCF optical fiber cable 1000m (3281 ft.) Broad-band H-PCF optical fiber cable 1000m (3281 ft.)

  • Page 28: Precautions When Installing The Coaxial Cables

    (6) Connect the cable connector and module connector securely until you hear a "click" sound. (7) Please wire IN/OUT of the connector for the cable correctly. Please do loopback test, the set confirmation test, and the bureau order confirmation test after wiring. It might be generated that a baton abnormal passing cannot be generated when miswiring and the downed bureau which cannot do the loopback of an arbitrary bureau do the row again even by the reclosing of the power supply.
  • Page 29 (5) Consider wiring using double-shielded coaxial cable in places that are subject to large amounts of noise. Enlarged view of cable Double shielded coaxial cable Sheath Sheath Mitsubishi Cable ... 5C-2V-CCY Internal conducter Grounding Insulation External...

  • Page 30: For The Coaxial Bus Type

    (7) Please wire SD/RD of the connector for the cable correctly. Please do loopback test, the set confirmation test, and the bureau order confirmation test after wiring. It might be generated that a baton abnormal passing cannot be generated when miswiring and the downed bureau which cannot do the loop back of an arbitrary bureau do the row again even by the reclosing of the power supply.
  • Page 31 (7) Consider wiring using double-shielded coaxial cable in places that are subject to large amounts of noise. Enlarged view of cable Double shielded coaxial cable Sheath Sheath Mitsubishi Cable ... 5C-2V-CCY Internal conducter External External conductor Grounding...
  • Page 32 (8) Do not pull any of the connected coaxial cables. This will cause a faulty contact, cable disconnection, or damage to the module. (9) Make sure to connect a terminal resistor to both terminal stations of the coaxial bus type network system. (10) A white oxide, which may be deposited on the F-type connector depending on the operating environment, is not producted in the fitting portion, posing no functional problems.

  • Page 33: Connecting The Connector For The Coaxial Cables

    5.2.3 Connecting the Connector for the Coaxial Cables The following section explains how to connect the BNC connector (connector plug for the coaxial cable) to the cable. (1) Structure of the BNC connector and coaxial cable The structure of the BNC connector and coaxial cable are shown in the figure below.
  • Page 34 (c) Cut the external conductor, insulation material and internal conductor to the dimensions shown below. However, cut the external conductor to the same dimension as the tapered section of the clamp and smooth it down to the clamp. Insulator Internal conductor Clamp and external conductor Applicable cable 3C-2V...

  • Page 35: External Dimensions

    6. EXTERNAL DIMENSIONS 6.1 A1SJ71QLP21 Printed writing board 93.6 34.5 (0.26) (3.69) (1.36) Unit: mm (in.) *1 Please confirm details to Mitsubishi Electric System Service Corporation. 6.2 A1SJ71QLP21S Printed writing board 93.6 69.5 (0.39) (0.26) (3.69) (2.74) Unit: mm (in.)

  • Page 36: A1Sj71Qlr21

    6.3 A1SJ71QLR21 Printed writing board 93.6 34.5 (0.26) (3.69) (1.36) Unit: mm (in.) 6.4 A1SJ71QBR11 Printed writing board At the time of installation of F-type connector 34.5 93.6 (0.26) (3.69) (3.69) (1.36) (0.43) Unit: mm (in.)

  • Page 38: Warranty

    WARRANTY Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
