Network module

Advertisement

MELSECNET/10
Network Module
Thank you for buying the Mitsubishi general-purpose programmable
controller MELSEC-QnA Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
©1999 MITSUBISHI ELECTRIC CORPORATION
Before using this product, please read this manual and the relevant manuals introduced in this
manual carefully and pay full attention to safety to handle the product correctly.
The instructions given in this manual are concerned with this product. For the safety instructions
of the programmable controller system, please read the CPU module user's manual.
In this manual, the safety precautions are classified into two levels: "
"
CAUTION".
Under some circumstances, failure to observe the precautions given under "
may lead to serious consequences.
Observe the precautions of both levels because they are important for personal and system
safety.
Make sure that the end users read this manual and then keep the manual in a safe place for
future reference.
AJ72QLP25, AJ72QLR25
MODEL
MODEL
CODE
SH(NA)-080074-D(1112)MEE
SAFETY PRECAUTIONS
(Always read before starting use.)
User's Manual
(Hardware)
AJ72QBR15
AQ-NET10-R-U-E
13JR13
WARNING" and
CAUTION"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELSECNET/10 AJ72QLP25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mitsubishi MELSECNET/10 AJ72QLP25

  • Page 1 MELSECNET/10 Network Module User’s Manual (Hardware) AJ72QLP25, AJ72QLR25 AJ72QBR15 Thank you for buying the Mitsubishi general-purpose programmable controller MELSEC-QnA Series Prior to use, please read both this manual and detailed manual thoroughly and familiarize yourself with the product. MODEL AQ-NET10-R-U-E...
  • Page 2 [DESIGN PRECAUTIONS] WARNING When there are communication problems with the data link, the communication problem station will enter the following condition. Build an interlock circuit into the sequence program that will make sure the system operates safely by using the communication state information. Not doing so could result in erroneous output or erroneous operation.
  • Page 3 [WIRING PRECAUTIONS] WARNING Before installation or wiring, be sure to shut off all phases of the external power supply used by the system. Failure to do so may cause electric shocks or damage the product. CAUTION Always connect the FG terminals to the ground using class D (class 3) or higher grounding exclusively designed for programmable controller.
  • Page 6: Conditions Of Use For The Product

    PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.
  • Page 7: Compliance With Emc And Low Voltage Directives

    COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES (1) Method of ensuring compliance To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated into other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals.
  • Page 8: Performance Specifications

    2. Performance Specifications The performance specifications for Network Modules are indicated as follows. Specifications Item AJ72QLP25 AJ72QLR25 AJ72QBR15 Maximum link X/Y 8192 points points per network 8192 points 8192 points Remote master station → Remote I/O station Maximum link points per station +(2 W) ≤...
  • Page 9 *2: Specialised training and specific tools are required to connect the connector to the optical-fiber cable; the connector itself is a custom product. Please contact your nearest Mitsubishi Electric System Service Corporation when purchasing these items. For general specifications of the network module, refer to the user's manual for the PLC CPU that is to be used.
  • Page 10 4. The Name and Setting of Each Part Indicates the name and setting of each part of Network Modules.
  • Page 11 Name Contents Name Status Contents Normally operating. WDT error occurred (hardware failure) RMT.E. When a blown fuse or I/O check error occurs. (Host station) DUAL Multiplex transfer in execution (OFF: Multiplex transfer not executed) SW.E. Incorrect setting of switches 3) to 4) ST.E.
  • Page 12 Caution Do not change the setting of the DIP switch on the printed circuit board at the side face of the module. Name Contents Reset switch Resets the host station hardware. RESET Station number setting switch Station number setting (factory setting at time of shipping: 1) *2 <Setting range>...
  • Page 13 Name Contents Connector Connect the optical fiber cable. (AJ72QLP25) Front Forward Reverse Reverse Forward Optical fiber cable Connector Connect the coaxial type cable. (AJ72QLR25) Front Reverse Forward Forward Reverse Coaxial Cable Connector Connect the F-type connector. (AJ72QBR15) F-type connector 5. Wiring Please refer to the reference manual of used master module for the wiring for network system.
  • Page 14: External Dimensions

    6. External Dimensions 6.1 AJ72QLP25 Unit: mm (in.) *1: Please confirm details to Mitsubishi Electric System Service Corporation.
  • Page 15 6.2 AJ72QLR25 Unit: mm (in.) 6.3 AJ72QBR15 Unit: mm (in.)
  • Page 16: Warranty

    WARRANTY Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
