Sony TC-707S Service Manual

TC-707S
TC-707SD
Power Requirements:
Track System:
Reef Size:
Tape Speed:
Recording Time:
{with 1,800 ft. tape)
Frequency Response:
Signal-to-Noise Ratio:
Wow and Flutter:
Serial No. 1261 to 1440.
Serial No. 11501 to 11600.
Serial No. 11601 and later.
Serial No, 1353 to 1592.
Serial No. 11601 to 11950. ~
Serial No. 11951 and later.
SPECIFICATIONS
50/60 Hz, 90W
Two-track stereo and mono
7" (18cm) maximum
714 ips and 334 ips
(19 cm/s and 9,5 cm/s)
Tape speed
71 ips 45 min.
(19 cm/s)
33/4 ips 1.5 hrs
(9.5 cm/s)
20 ~ 25,000 Hz at 71% ips (19 cm/s)
20 ~ 18,000 Hz at 334 ips (9.5cm/s)
(with standard tape)
20 ~ 30,000 Hz at 714 ips (19 cm/s)
20 ~ 20,000 Hz at 334 ips (9.5 cm/s)
(with SONY SLH tape)
54dB (with standard tape)
57 dB (with SONY SLH tape)
0.04% at 714 ips (19 cm/s)
0.1% at 334 ips (9.5cm/s)
Record Bias Frequency:
Inputs:
Outputs:
Semiconductors:
Dimensions:
Weight:
Canadian Model
AEP Model
E Model
Approx. 120kHz
Two MIC inputs
Impedance: 6002
Maximum sensitivity: 0.19mV (~72 dB)
Two LINE iNputs
Impedance: 100k2
Maximum sensitivity: 0.06V (-22 dB)
Two LINE OUTputs
impedance: 100k or more
Output level: 0.775V (0 dB)
HEADPHONE output
Load impedance: 82
Output level: 0.037 V (-26.5 dB)
44 transistors and 51 diodes
TC-707S: 166164 (W) x 172742 (H) x 1034" (D)
(430 x 453 x 271mm)
TC-707SD: 147 (W) x 163%4 (H) x 914" (D)
(378 x 408 x 234mm)
TC-707S: 49lb 60z (22.4kg)
TC-707SD: 42 Ib 130z (19.4kg)
