Iso-Tech LUX-1335 Instruction Manual

ISO-TECH
DIGITAL LIGHT METER
LUX-1335
INSTRUCTION MANUAL
lux
20
Kfc
Klux
fc
I INTRODUCTION
·
The ISO-TECH LUX-1335 digital light meter is a precision
instrument used to
footcandle）.
·
It meets CIE photopic spectral response.
·
It is fully cosine corrected for the angular incidence of light.
·
The meter is a compact, tough and easy to use instrument.
·
The light sensitive component used in the meter is a very
stable, long-life silicon photodiode and spectral response filter.
· U.S. Pat. No. Des. 446,135
II FEATURES
·
Light measurement ranging from 0.01 lux ~ 0.1 klux / 0.01 fc
~ 0.01 kfc, respectievely.
·
High accuracy and rapid response.
·
Data-hold function
·
Digital and analogue graphical display
·
Automatic zeroing.
·
Meter corrected for spectral relative efficiency.
·
No manual correction factor calculations for non-standard
light sources.
·
Short rise and fall times.
·
Peak-hold function
·
Selectable scale – Lux or fc
·
Auto power off after 30 minutes.
·
Maximum and minimum measurements.
·
Relative reading function.
measure illuminance
1
（lux,
