SMC Networks EZ Switch SMCGS16 Specifications page 2

TECH SPECS - SMCGS16 / SMCGS24
PORTS
• SMCGS16
• 16-port auto-MDIX 10/100/1000Mbps
RJ-45 auto-sensing ports
• SMCGS24
• 24-port auto-MDIX 10/100/1000Mbps
RJ-45 auto-sensing ports
NETWORK MEDIA
• 10Base-T, UTP/STP category 3 or 5 cable
• 100Base-T, UTP/STP category 3 or 5 cable
• 1000BASE-TX, UTP/STP category 5 cable, 4 pairs
LED
• System – Power
• Link/Activity
• 100/1000Mbps
WEIGHT
• SMCGS16 - 2.0 kg (4.40 lbs)
• SMCGS24 - 2.19 kg (4.8 lbs)
SIZE
• 330 x 204 x 44 mm
• 13 x 8 x 1.7 in
MEMORY BUFFER
• 400 Kbits
MAC ADDRESS
• 8K
TEMPERATURE
• Operating- 320 to 1040F
• 00 to 400C
• Storage- -400 to -940F
• -400 to -700C
HUMIDITY
• Operating- 10% to 90%
• Storage- 5% to 90%
FORWARDING METHOD
• Store and Forward
POWER CONSUMPTION
• SMCGS16 - 15.8 watts
• SMCGS24 - 24.2 watts
POWER DISSIPATION
• 130BTU/hr maximum
INPUT POWER REQUIREMENT
• 100-240VAC@50 -60Hz
SAFETY & EMI
• FCC Class A
• CISPR Class A
• EN 61000-3-2/3
• CE
• CSA (UL1950, CSA22.2.950), TUV/GS (EN60950)
• TUV/GS (EN60950)
STANDARDS
• IEEE802.3
• IEEE802.3u
• IEEE802.3ab
• IEEE802.3x
CERTIFICATION
• CE Mark
IMMUNITY
• IEC 1000-4-2,3,4,6
EMI
• FCC Class B
WARRANTY
• Please check www.smc.com for the warranty
terms in your country/region
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country
contact information
© 2010 SMC Networks. SMC and the SMC logo are registered trademarks
of SMC Networks in the United States or other countries. Other trademarks
or registered trademarks are the property of their respective owners. Infor-
mation is subject to change without notice. All rights reserved.
4/2010
www.smc.com
POWER TO CONNECT
