Kessil PR300 User Manual

PR300
USER MANUAL
PARTS DIAGRAM
G
H
J
I
INSTALLATION GUIDE
1. Carefully take out the contents from the package.
2. Remove the adhesive film from the Protective Glass (J) before use. Clean periodically.
3. Connect the Power Cable (E) to the AC Input Port (I).
4. Plug the power supply into an outlet with the correct voltage specifications (see product specifications for more information).
5. Flip the Main Power Switch (H) to turn PR300 on and off, use the Navigation Pad (B) to change settings shown on the LCD Screen (A),
and press the Menu Button (D) to go to the Home screen.
6. Press the Pause Button (C) to immediately pause and turn the light off anytime.
7. Use provided 3.5mm cables via the Multi-Unit Link Port (G) to sync multiple PR300 units.
8. Connect PR300 to a computer through the USB Type-C Port (F). Does not need to be connected to a computer to run.
PRODUCT SPECIFICATIONS
Power Consumption
Input Voltage
Irradiation Distance
*
Wavelength Options
Average Intensity of PR300 series
(Protective Glass as starting point)
Dimensions (W x L x H)
F
MAX 340W
100 - 240 VAC
20mm - 50mm
427nm, 440nm, 456nm, 467nm, 525nm
442 mW/cm² measured at 12mm
407 mW/cm² measured at 20mm
7.9" x 9.3" x 4.5" / 20.0cm x 23.6cm x 11.5cm
A
B
C
D
E
LCD Screen
A
Navigation Pad
B
Pause Button
C
Menu Button
D
Power Cable
E
USB Type-C Port
F
Multi-Unit Link Port
G
Main Power Switch
H
AC Input Port
I
J Protective Glass
* From Protective Glass to vials placed in the Tank
250110A
