- Page 1 Mitel Base Station & IPBL, Installation Guide 32/1531-ANF90143 Uen A...
-
Page 2: Abbreviations And Glossary
Also referred to as Call Manager. Radio Fixed Part DECT base station part of the DECT Infrastructure. TDM-DECT base station connected to an IPBL or the local RFP part in an IPBS. 32/1531-ANF90143 Uen A... -
Page 3: Table Of Contents
Table of Contents Introduction ..............................1 Description ..............................2 IPBS1 ..................................2 IPBS2/IPBS3 ................................4 IPBL ..................................7 BS3x0 ..................................9 BS3x2 ..................................11 AC-adapter ................................14 Installation of the Base Station ........................16 Base Station Cabling ............................16 Install the Base Station ............................16 Power the Base Station............................ -
Page 5: Introduction
(12.1.5) Installation and Operation.pdf. For information about supported PBXs contact your supplier. In previous documentation, IPBS Base Station (or IPBS) was sometimes referred to as IP-DECT Base Station. In previous documentation, IPBL was sometimes referred to as IP-DECT Gateway. 32/1531-ANF90143 Uen A... -
Page 6: Description
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description Description This section gives a general description of the following devices: • IPBS1, see 2.1 IPBS1, page 2 • IPBS2 and IPBS3, see 2.2 IPBS2/IPBS3, page 4 • IPBL, see 2.3 IPBL, page 7... - Page 7 INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide Power Distribution The IPBS1 can be powered using the following methods: • Power over Ethernet, IEEE 802.3af • A local AC-adapter For more information about power distribution, see 3.3 Power the Base Station, page 23...
-
Page 8: Ipbs2/Ipbs3
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description • Two antennas • A mounting bracket • Two screws with wall plugs The IPBS1 cannot be mounted with the antennas pointing downwards as the mounting bracket does not support it. - Page 9 INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide 2.2.1 IPBS2/IPBS3 with Internal Antenna Figure 2. IPBS2/IPBS3 Overview Used for cable ties to provide strain relief for cables Front view Back view Reset Back view while lying down Power Supply...
- Page 10 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description Software For information on how to update the software in the IPBS2/IPBS3, see the applicable Installation and Operation Manual for the IPBS2/IPBS3. Connectors • Two 8-pin RJ45 modular jacks for LAN/PoE and powering LEDs The IPBS2/IPBS3 has one RGB LED to indicate status.
-
Page 11: Ipbl
INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide Deployment: Bad sync 400 ms blue, 600 ms off, The IPBS2/IPBS3 is in deployment mode and 400 ms blue, 600 ms off, does not have adequate air sync coverage. 400 ms yellow. -
Page 12: Led Indication
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description 10BASE-T/100BASE-T Ethernet interface. LAN1 port must be used in the IP-DECT system (LAN2 port is for administration only). Note: This is not applicable when RSTP is used. For information about RSTP, see the applicable Installation and Operation Manual for the device. -
Page 13: Bs3X0
INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide Description Base station LED Not lit No speech activity in RFP. Flashing All speech channels occupied in RFP. Steady Speech activity in RFP. Description Sync/Ref sync LED Not lit No sync communication established. - Page 14 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description Figure 4. BS3x0 Overview Front view Back view LED2 LED1 Data/Power Data/Power Test (RJ12) (RJ45) (RJ45) Contents of the Box The box in which the base station is packed contains: •...
-
Page 15: Bs3X2
INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide • A 6-pin RJ12 modular jack for factory testing LEDs Status of LED1 (lower LED) Description Steady Green Power LED Status of LED2 (upper LED) Description Not lit Base station operational and no traffic on the base station. - Page 16 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description 2.5.1 BS3x2 with Internal Antenna Figure 5. BS3x2 Overview Used for cable ties to provide strain relief for cables Front view Back view DIPswitch Back view while lying down DECT...
- Page 17 INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide Software The software in the BS3x2 can be updated by downloading new software without disconnecting the equipment. Certain HW revisions are not backwards compatible with all SW versions. The article numbers can be found on the label at the back of the device.
-
Page 18: Ac-Adapter
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Description DIP switch 1: ON 1880-1900 MHz (Europe, Africa, Middle East, Australia, New Zealand and parts of Asia) DIP switch 2: ON DIP switch 1: OFF 1900-1920 MHz DIP switch 2: ON... - Page 19 INSTALLATION GUIDE Description Mitel Base Station & IPBL, Installation Guide Versions (different type of mains plug) For European countries except UK Order. no.: BSX-0013 For UK, Australia and North America Order. no.: 660538 If local power supply is used for the RFPs, the EPP cable pair must NOT be connected.
-
Page 20: Installation Of The Base Station
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Installation of the Base Station This section describes how to install the IPBSs, BS3x0 and BS3x2. All three base stations can be fixed to a wall, a ceiling, a pole or a beam, by means of the mounting bracket included. When fixing the base station to a wall or ceiling the included plugs and screws must be used. - Page 21 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Figure 7. Fixing the mounting bracket to a wall. Ceiling 65 mm (IPBS1, BS3x0) 100 mm (IPBS3, IPBS2, It is critical that the mounting bracket is securely and firmly attached to the wall or ceiling, this is especially important if it is mounted more than 2 m above the floor: •...
- Page 22 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Fix the mounting bracket to a pole or beam using the metal band, see Figure 8. Fixing the mounting bracket to a pole or beam., page Figure 8.
- Page 23 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Figure 9. Minimum distances between a cable duct and the mounting bracket 65 mm 57 mm 125 mm 75 mm 70 mm 15 mm thick cable ducts 3.2.5...
- Page 24 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Back view while lying down MCX connectors Mount the base station (3), see 3.2.9 Mount the Base Station, page Figure 10. Connect external antennas. antenna antenna bracket...
- Page 25 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station 3.2.6 Secure the Cable For safety reasons secure the base station cable to a convenient point at about 30 cm from the base station. If for some reason the base station drops, it is secured by the cable.
-
Page 26: Connect The Base Station Cables
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Pin the BS3x0/BS3x2 Cable Figure 13. Connector pinning of the Data connector RJ45 modular jack SC = Serial Channel EPP = Express Power Pairs NC = Not Connected If local power supply is used, the EPP cable pair must NOT be connected. -
Page 27: Power The Base Station
The IPBS supports Power over Ethernet, IEEE 802.3af, class 2. The power source will allocate 7W to the IPBS. This must be regarded when planning the powering of the IPBSs so that the power limit of the PoE power source is not exceeded. - Page 28 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the Base Station Only approved power supply according to valid editions of EN/IEC/CSA/UL/AU/NZS 62368-1 is to be used when the base station is powered by a local power supply.
-
Page 29: Installation Of The Ipbl
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the IPBL Installation of the IPBL This section describes how to install the IPBL. Install the IPBL Figure 15. Install the IPBL Base Station Synchronization Reference IP DECT Gateway... -
Page 30: Pin The Ipbl Cable
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the IPBL Pin the IPBL Cable All data cables used for the IPBL is standard CAT5 unshielded cable. It is assumed that installation personnel know how to crimp these connectors to a cable. -
Page 31: Power The Ipbl
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the IPBL Cut the cable to the correct length. Connect the cable to a RJ45 modular jack. For information on the pinning, see below. If local power supply is used for the RFP, the EPP cable pairs must NOT be connected. -
Page 32: Fans Replacement
INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide Installation of the IPBL Figure 18. Pinning of the 110/230 VAC power supply Connect the power cable on the IPBL. Connect the power cable in a wall socket with protected earth. -
Page 33: Appendix Arfp Power Consumption
INSTALLATION GUIDE RFP Power Consumption Mitel Base Station & IPBL, Installation Guide Appendix A RFP Power Consumption The table below show power consumption for a base station connected to and powered from the IPBL/PBX. The maximum cable length for base stations connected to the IPBL/PBX must not exceed 1700 meters. - Page 34 INSTALLATION GUIDE Mitel Base Station & IPBL, Installation Guide RFP Power Consumption Table 2 Power consumption (watts) of base stations and cabling when powered from the PBX. (continued) 1000 1100 1200 1300 1400 1500 1600 1700 32/1531-ANF90143 Uen A...
-
Page 35: Appendix B Related Documents
Appendix B Related Documents 13/1531-ANF90114 Mitel IP-DECT_System (12.1.5) Installation and Operation.pdf...
