- Page 1 Installation Guide For S-Link Automatic Main Switch AMS-2 DOCUMENT ID: 7995 REVISION: DATE: 2024 LANGUAGE:...
-
Page 2: Table Of Contents
AMS Fuse and Battery Cable Installation ..............................7 S-link System Description ..................................8 Wiring Diagram ...................................... 9 Service........................................10 Service and Support................................... 11 Product Spare Parts and Additional Resources ..........................11 Warranty Statement .................................... 11 Patents........................................11 MC_0020 AMS-2 7995 2024... -
Page 3: Responsibility Of The Installer
Make sure to use the correct fuse for the main switch, based on the installed thruster model. IMPORTANT This manual is to be used in addition to the installation manual for the Sleipner thruster. This manual is intended for professionals only. For Sleipner S-Link™ systems: MC_0105 •... -
Page 4: Main Features
The AMS-2 is protected from severe overcurrent by the Fuse placed in the fuse holder in the AMS-2. • The AMS-2 will automatically detect if the fuse is blown when the system starts up and the user will be informed via the S-Link connected control panel. -
Page 5: Product Dimensions
3.11 Width including fasteners 3.54 Attachment hole from the top 51.5 2.03 Attachment hole from the bottom 92.8 3.65 Attachment hole from the side 37.5 Distance between attachment hole 121.8 Attachment hole from the side 45.7 MG_0321 AMS-2 7995 2024... -
Page 6: Automatic Main Switch (Ams) Installation
Choose an appropriate location (close to tbe battery) for installing the AMS that provides quick and easy access to the shut-off button while minimizing the length of power cables. Secure the AMS using the two mounting holes on each side MG_0570 AMS-2 7995 2024... -
Page 7: Ams Fuse And Battery Cable Installation
Fuse bolts Recommended torque 5 - 7 Spring washer 20 Nm Pull out Push In (14.5 lb/ft) Washer 8 - 10 Recommended Cable configuration for dual cable installation MG_0323 AMS-2 7995 2024... -
Page 8: S-Link System Description
MC_0120 S-Link is a CAN-based control system used for communication between Sleipner products installed on a vessel. The system uses BACKBONE Cables as a common power and communication bus with separate SPUR Cables to each connected unit. Only one S-Link POWER cable shall be connected to the BACKBONE Cable. -
Page 9: Wiring Diagram
24v battery bank. The reason is that there can be a lot of voltage ripple and disturbance on the main 48V battery. S-Link Spur cable ANL Fuse On/O switch Fuse 5A (Optional) 12/24/48V To vessel HOUSEHOLD THRUSTER To thruster system household BATTERY BATTERY MG_0963 AMS-2 7995 2024... -
Page 10: Service
Read the troubleshooting guide in the thrusters manual. If you are unable to identify and resolve the problem, contact the nearest Sleipner service point for assistance. Have the notes from your troubleshooting handy to inform the service person of what you have already checked and observed. -
Page 11: Service And Support
11. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country. Patents MC_0024 At Sleipner we continually reinvest to develop and offer the latest technology in marine advancements. To see the many unique designs we have patented, visit our website www.sleipnergroup.com/patents AMS-2... - Page 12 © Sleipner Group, All rights reserved The information given in the document was right at the time it was published. However, Sleipner Group cannot accept liability for any inaccuracies or omissions it may contain. Continuous product improvement may change the product specifi...
