Summary of Contents for Scooterpac Atom Fold
-
Page 4: Table Of Contents
Freewheel Lever ..............13 14 Specifications .................. 28 Removing Batteries ............14 15 Servicing ..................... 29 Tiller Controls ............... 15 16 Notes..................... 31 Folding & Unfolding ..............17 10 Armrest Adjustments ..............21 10.1 Width ..................21 Scooterpac Atom Fold | User Manual... -
Page 5: Welcome
Dealer Name ________________________ Congratulations on purchasing your Scooterpac Atom Fold. With regular maintenance and proper operation your Atom Fold will give you many years and Address 1 ________________________ countless miles of rewarding experiences. This manual contains the information that you and your authorised... -
Page 6: Intended Purpose
2 Intended Purpose This mobility scooter has been designed to help people with limited mobility move around more easily and independently. The user has full control over the mobility scooter. Scooterpac Atom Fold | User Manual... -
Page 7: Important Information
The manufacturer also expects the user has received assistance from the authorised mobility supplier and/or prescribing health care professional in ensuring the user clearly understands how to safely operate this product. Scooterpac Elevation House 23 Commercial Road Lowestoft Suffolk NR32 2TD United Kingdom Certifications Scooterpac Atom Fold | User Manual... -
Page 8: Safety Warnings
Avoid driving over loose surfaces such as gravel. Never use the product under the influence of alcohol. Always drive forwards down gradients, kerbs and other obstacles. Do not operate the product until the assembly and inspection have been completed. Scooterpac Atom Fold | User Manual... -
Page 9: Safe Inclines
4.1 Safe Inclines The Atom Fold can climb inclines of up to 10˚ without danger. On this 10˚ incline, the Atom Fold can stop, brake and turn. It is possible to attempt steeper inclines, but we strongly suggest that you do not. To reduce the possibility of tipping backwards on inclines, lessen the load on the back of the scooter by sliding the seat forward as much as possible and leaning forward. -
Page 10: Unintentional Movement
5 Unintentional Movement Before operating, the Atom Fold should always be stationary. When the Atom Fold is switched on, it will remain stationary until the forward and reverse lever is pushed or pulled. Do not attempt to operate the mobility scooter when standing. -
Page 11: Contents
6 Contents Atom Fold Lithium Battery Charger Keys Armrests Allen Keys Scooterpac Atom Fold | User Manual... -
Page 12: Features
Onboard Charging Port Forward / Reverse Lever Folding Handle Tiller Folding Mechanism Front Wheel Backrest Armrest Cushion Armrest Width Adjusting Nut Armrest Height Adjusting Nut Battery Freewheel Lever Anti-Tip Wheel Rear Wheels Folding Basket Scooterpac Atom Fold | User Manual... -
Page 13: Operating Instructions
8 Operating Instructions 8.1 Freewheel Lever The freewheel lever is located on the rear left of the Atom Fold. When the lever is in the lower position, the mobility scooter is in freewheel mode and can be moved freely. The mobility scooter will power on but the movement controls will not work. -
Page 14: Removing Batteries
When lifting and transporting the mobility scooter, removing the batteries decreases the overall weight, making it easier to carrier. Please note – the standard Atom Fold includes one lithium battery and one empty storage box. To increase the maximum range from one charge an additional battery can be purchased and stored onboard. -
Page 15: Tiller Controls
8.3 Tiller Controls Scooterpac Atom Fold | User Manual... - Page 16 Scooterpac Atom Fold | User Manual...
-
Page 17: Folding & Unfolding
9 Folding & Unfolding Folded Position Risk of falling when the scooter is folded and vertically positioned. Scooterpac Atom Fold | User Manual... - Page 18 Step 1 To fold the seat, pull the folding handle upwards. Scooterpac Atom Fold | User Manual...
- Page 19 Step 2 Push the seat down towards the footrest. Scooterpac Atom Fold | User Manual...
- Page 20 Step 3 Pull the tiller folding mechanism to release the tiller. Then fold the tiller down towards the backrest buckle. Scooterpac Atom Fold | User Manual...
-
Page 21: Armrest Adjustments
10 Armrest Adjustments 10.1 Width 10.2 Height Scooterpac Atom Fold | User Manual... -
Page 22: Troubleshooting & Fault Codes
There is a faulty connection to the motor. Check all connections between the motor and controller. The motor has a short circuit. Please contact an authorised Scooterpac dealer. Not applicable / fault code not used. -
Page 23: Maintenance
Before performing maintenance work, turn off the mobility scooter and remove the batteries. Component Daily Weekly Monthly Every 3 Months Every 12 Months Battery Tyres Power Connection Chassis Clean Seat Cushion Electromagnetic Brakes Scooterpac Atom Fold | User Manual... -
Page 24: Battery Maintenance
If you plan to store and not use your mobility scooter for more than one week, please remove the lithium battery from the Atom Fold. This will help extend the life of your battery. Scooterpac Atom Fold | User Manual... -
Page 25: Cleaning
To maintain the life of your mobility scooter keep it clean and dry. Please wipe your scooter after using. 12.3.1 Framework To care for the framework, wipe the Atom Fold using soft microfibre cloths. TOP TIP – Please do not use water or wash the framework. -
Page 26: Warranty
To ensure validity, the Warranty must be registered to Scooterpac within 14 days of purchase. 13.1 One-Year Warranty From of the date of delivery the warranty is valid for one year. Scooterpac will provide a warranty on the chassis, brake, motor and electrical components. -
Page 27: Warranty Policy
The warranty does not extend to the consequential costs resulting from fault clearance, freight and travel costs, loss of earnings, expenses, etc. The manufacturer will not accept responsibility for any damage or injury caused by misuse or non- observation of the instructions set out in this user manual. Scooterpac Atom Fold | User Manual... -
Page 28: Specifications
Turning Radius 1400mm type, tyre condition and vehicle loading. Footrest Fold-away Excluding batteries, cushions, armrests and basket. Due to manufacturing tolerances and continuous product improvement this specification can be subject to variance of +/-3%. Scooterpac Atom Fold | User Manual... -
Page 29: Servicing
15 Servicing In order to ensure continued safe operation, the Atom Fold must be serviced every 12 months. We recommend recording the servicing dates and locations on the sheets below. Always have your Atom Fold serviced at an authorised Scooterpac dealer, using original Scooterpac parts. - Page 30 Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Scooterpac Atom Fold | User Manual...
-
Page 31: Notes
16 Notes Scooterpac Atom Fold | User Manual... - Page 32 Brighten your day SP/AF/M/EN/2025-A...
