Summary of Contents for Scooterpac Ignite Sport
- Page 1 User ManUal...
-
Page 3: Table Of Contents
7.5.2 Freewheel Mode ............20 Welcome ....................6 7.5.3 Reversing ............... 21 Legal ......................7 Starting the Ignite Sport ........... 22 Safety ....................... 8 Digital Colour Display ............23 Anti-Tip Wheels ................. 8 7.7.1 Odometer ..............24 Safe Inclines ................. 9 7.7.2... - Page 4 Sizes & Weights ..............40 Fuses ..................... 35 12 Servicing ..................... 41 13 Notes..................... 45 Tyre Pressures ................36 Cleaning & Maintenance ..........37 9.5.1 Rubber Mats ..............37 9.5.2 Paintwork ............... 37 10 Warranty ..................... 38 Scooterpac Ignite Sport | User Manual...
-
Page 5: Welcome
Ignite Sport, the mobility scooter for winners. Dealer Name ________________________ With regular maintenance and proper operation your Ignite Sport will give you many years and countless miles of rewarding experiences. This manual contains the Address 1 ________________________ information that you and your authorised Scooterpac dealer will need to keep your Ignite Sport in good working order. -
Page 6: Legal
2 Legal The Scooterpac Ignite Sport is designed to be operated by a single person, in accordance with the legal requirements for operating a Class 3 invalid carriage in the jurisdiction in which it was sold. Operating the vehicle outside of these limitations may invalidate your warranty. -
Page 7: Safety
3 Safety The Ignite Sport should only be operated by a single person, who is not suffering from any condition which impairs vision, hearing, eyesight or the ability to react to sudden changes in surroundings. If you suffer from any of the above, it is recommended that you seek advice from your doctor before operating the Ignite Sport. -
Page 8: Safe Inclines
3.2 Safe Inclines The Ignite Sport can climb inclines of up to 12˚ without danger. On this 12˚ incline, the Ignite Sport can stop, brake and turn. It is possible to attempt steeper inclines, but we strongly suggest that you do not. To reduce the possibility of tipping backwards on inclines, lessen the load on the back of the scooter by sliding the seat forward as much as possible and leaning forward. -
Page 9: Introduction
4 Introduction Your Ignite Sport is a high-tech piece of mobility equipment that will give you years of faithful service and enjoyment. This manual introduces you to the operation, maintenance and care of your Ignite Sport. If you have any questions, or are unsure of anything, please contact the dealer your originally purchased the Ignite Sport from. -
Page 10: Your Ignite Sport
5.1 Intended Use The Ignite Sport is designed for use on smooth pavement or roadway, in accordance with local laws. The Ignite Sport can be used in wet and windy weather, but discretion should be used when planning a journey in adverse weather conditions. -
Page 11: Unintentional Movement
5.2 Unintentional Movement Before boarding, the Ignite Sport should always be stationary. When the Ignite Sport is switched on, it will remain stationary until one of the following: 1. The forward or reverse lever is pulled. 2. The freewheel function is engaged. -
Page 12: Digital Tiller Guide
6 Digital Tiller Guide Figure 2 – Digital Tiller Guide Scooterpac Ignite Sport | User Manual... -
Page 13: Operating Your Ignite Sport
Power On To turn on the Ignite Sport, sit in the Captains Seat and either press the ‘Unlock / Turn On’ button on the fob or the ‘Start/Stop’ button located on the tiller column (see 7.6 Starting the Ignite Sport). -
Page 14: Seat Adjustments
Backrest Adjustment The pitch of the seat can be changed by the lifting lever located on the right-hand side of the seat when seated. Figure 4 – Pull black handle to adjust the backrest Scooterpac Ignite Sport | User Manual... - Page 15 To change the angle of the seat, sit on the seat, pull the swivel handle towards the front of the scooter and turn the seat anti-clockwise. Figure 5 – Pull black handle to adjust the backrest Scooterpac Ignite Sport | User Manual...
-
Page 16: Tiller Adjustments
Try to find a position that allows a good view of the digital control panel and allows full left and right movement of the steering. Figure 6 – Press the black handle down to adjust tiller pitch Scooterpac Ignite Sport | User Manual... -
Page 17: Steering
The Ignite Sport is fitted with a mechanical steering column that ideally should be operated with both hands. When the Ignite Sport is stationary the steering may feel a little heavy or stiff. Steering will become lighter whilst the vehicle is in motion. -
Page 18: Acceleration & Braking
7.5 Acceleration & Braking 7.5.1 Speed Controls The Ignite Sport has several methods for controlling speed; the High and Low Speed Modes and the Max Speed Limiter. 7.5.1.1 High and Low Speed Modes The high (“H”) and low (“L”) speed modes are controlled by the H/L button. The two settings place the scooter in either a 4mph or 8mph mode. -
Page 19: Throttle Levers
To move forward, gently pull the green lever. The Ignite Sport will accelerate up to the maximum allowable speed set by the speed controls. To slow down or stop, release the accelerator and the scooter will stop. In an emergency the handbrake can be applied by pulling the brake handle located on the right of the handlebars. -
Page 20: Reversing
Gently pull the red lever, and the Ignite Sport will begin to slowly move backwards. To slow down or stop, release the red lever and the scooter will stop. In an emergency the handbrake can be applied by pulling the brake handle located on the right of the handlebars. -
Page 21: Starting The Ignite Sport
7.6 Starting the Ignite Sport The Ignite Sport can be started once the Keyless Fob is within proximity to the scooter and the Start/Stop button is pressed (figure 9). The Ignite Sport is powered on and ready to be used after the Scooterpac welcome screen and once the digital colour displays visual data (figure 10). -
Page 22: Digital Colour Display
7.7 Digital Colour Display Figure 11 – Digital Colour Display Scooterpac Ignite Sport | User Manual... -
Page 23: Odometer
8. If necessary, repeat steps 5-7 to adjust the Year, Month, Day, Hour or Minute and adjust. 9. Press the Settings/Back button to return to the main display interface. 10. The date and time will now be set. Scooterpac Ignite Sport | User Manual... -
Page 24: Indicators
To switch them on press either the left or right button once before initiating a manoeuvre. Once the turn is complete and it is safe to do so, press the indicator button again to turn off the indicator. Scooterpac Ignite Sport | User Manual... -
Page 25: Hazard Lights
The electric horn is activated by pressing the button on the tiller top. The horn should only be used in compliance with the Highway Code. The horn will only sound if the scooter is switched on. Scooterpac Ignite Sport | User Manual... -
Page 26: Bluetooth
7.11 Bluetooth The Ignite Sport features integrated Bluetooth connectivity and two speakers built into the tiller column. Mobile devices can be paired with the scooter to play music and audio: 1. Turn on the scooter and your mobile device’s Bluetooth 2. -
Page 27: Screen Mirroring
To mirror the screen from your mobile phone, follow the below instructions: 1. Turn on the Ignite Sport and connect your mobile phone to the scooter via Bluetooth (see 7.11) 2. Using your mobile phone’s App Store download the EYLINK app (see figure 14) 3. -
Page 28: Usb Charging Ports
7.13 USB Charging Ports The Ignite Sport is equipped with USB Charging Ports on the right-hand side of the tiller column. Port 1 is located next to the LED light and Port 2 can be found on right hand side. -
Page 29: Bottle & Mobile Phone Holder
7.14 Bottle & Mobile Phone Holder For your convenience, the Ignite Sport is fitted with two plastic moulded holders. Use these locations to safely store bottled drink and your mobile phone. TOP TIP – The bottle holder should not be used to store alcoholic beverages. -
Page 30: Bag Holder
To access the clip, push the bottom of the holder and the clip will push towards you. The bag holder will carry a maximum weight of 2.5kg. Figure 18 – Bag Holder Scooterpac Ignite Sport | User Manual... -
Page 31: Charge Port
7.16 Charge Port Charging the Ignite Sport can be completed by using the charge port on the tiller. The port is located on the tiller column on the right-hand side. To charge the vehicle, simply connect the supplied charge cable to the port. -
Page 32: Heated Seat
3 red LEDs = High heated seat is off. 2 red LEDs = Medium Figure 20 – Heated seat 1 red LED = Low button Scooterpac Ignite Sport | User Manual... -
Page 33: Maintenance
The seat can then be removed by pulling directly upwards. The batteries in your Ignite Sport should not require any maintenance on a day-to-day basis, however access may be required. The batteries are located under the seat, protected by a black plastic shroud – secured by six screws. -
Page 34: Fuses
9.3 Fuses The fuses used on the Ignite Sport are accessible through a covered hatch on the front of the tiller. To access the fuse board, simply pull down on the retaining clip and slide the cover out of place. Fuses should only be changed by professionals, as improper work may damage the Ignite Sport electrical system. -
Page 35: Tyre Pressures
9.4 Tyre Pressures The tyres on the Ignite Sport are designed to give a good balance between comfort and energy efficiency. Incorrectly inflated tyres may lead to poor handling, reduced range and increased wear. The tyres should always have at least 3mm of tread to provide adequate grip on the road surface. -
Page 36: Cleaning & Maintenance
9.5.2 Paintwork To care for the paint, regularly wash the Ignite Sport using soft cloths and a mild automotive detergent. Apply automotive polish to achieve a high-shine finish. It is highly recommended that polish is applied in areas where the paintwork may be exposed to adverse weather conditions. -
Page 37: Warranty
Scooterpac dealer from which it was purchased. If a repair cannot be completed a replacement part will be fitted. If a manufacturing defect is found, it must be reported in writing to the Scooterpac dealer from which the Ignite Sport was purchased from, within 28 days of purchase. -
Page 38: Specifications
11 Specifications 11.1 Technical Specification Rear Wheel Drive Sealed Transaxle Motor Batteries Dual 12V 75Ah 950W (4 Pole) 24 Volt DC Digital Colour Display Dashboard 16-button Tiller Tyres Pneumatic Max Speed Dial Scooterpac Ignite Sport | User Manual... -
Page 39: Sizes & Weights
+/-3%. Height 1300 mm Varies with user weight, terrain type, battery charge, Tyres 13” pneumatic tyres battery condition, tyre condition. Wheels 8” Alloys Maximum Slope 12 degrees Turning Radius 2125mm Weight 115kg (without batteries) Scooterpac Ignite Sport | User Manual... -
Page 40: Servicing
12 Servicing In order to ensure continued safe operation, the Ignite Sport must be serviced every 12 months. We recommend recording the servicing dates and locations on the sheets below. Always have your Ignite Sport serviced at an authorised Scooterpac dealer, using original Scooterpac parts. - Page 41 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Sport | User Manual...
- Page 42 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Sport | User Manual...
- Page 43 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Sport | User Manual...
-
Page 44: Notes
13 Notes Scooterpac Ignite Sport | User Manual... - Page 46 Brighten your day Tel: 0330 124 1733 E-mail: info@scooterpac.com Web: www.scooterpac.com SP/IGS/M/EN/2024-A...
