- Page 2 Transit Damage: Each package is inspected prior to being shipped from the warehouse to insure that is in perfect condition. The column shipping boxes are constructed using extra thick cardboard. Some packaging includes engineered plastic walls, end caps and banding. The columns are packed using engineered plas- tic walls and in dense foam to protect and absorb energy from reasonable drops and impacts.
- Page 3 Product Identification:...
- Page 4 Intended use: This product is intended for use by professional and commercial photographers in a studio envi- ronment with a high ceiling. The wheels are designed to be used indoors on a floor that is smooth, hard, flat and unobstructed. CAUTION: This product is not recommended for use by hobbyists or in a household environ- ment with a low ceiling or carpeted floors.
- Page 5 Component Identification: STA 01-350 MK2-360SPIN...
- Page 6 Component Identification: STA 01-350 MK2-360SPIN Diagram: D...
- Page 7 !CAUTION ! Cross Threading Components: Cross-threading components during assembly is not covered under war- ranty. Cross-threading is a term that describes damage that is caused when a misaligned screw or knob thread is forced into a threaded hole. When this occurs, threads are damaged and are no longer capable of proper opera- tion.
- Page 8 Component Identification: STA 01-350 MK2-360SPIN HD Interface Plate...
- Page 9 Component Identification: STA 01-350 MK2-360SPIN Hand Lever adjustable, 360 degree range of movement, camera head mount plates...
- Page 10 Assembly Steps: 1. Wearing gloves and together with your Assis- Diagram: A tant……..Place the Column Box [long rectangular box] flat on floor. Place some packing materials on the floor. Do not stand the Vertical/Center Column vertically. Remove and Lay the Vertical/ Center Column flat on the floor.
- Page 11 Assembly Steps: 4. Together with your Assistant…Wearing Gloves Diagram: B …..Carefully, Slowly raise and lift until the Vertical/ Center Column until it is standing freely on its wheels. 5. Locate and install three STA 01-350MK2-TS Ad- justable travel stops. One directly below each ver- tical carriage.
- Page 12 Assembly Steps: 7. Locate the M6 Hex Wrench. Locate the loose Vertical / Brake Knob. Locate the location of Verti- cal Carriage / Brake Knob See [See DIAGRAM: D]. With the M6 Hex Wrench FIRST Remove the transportation set screw and THEN replace with Vertical Carriage / Brake Knob.
- Page 13 Use & Maintenance Steps: 11. HAZARD: Stop and take a moment to under- stand the effect of moving the horizontal arms vertically. HAZARD: When the vertical carriage brake knob is released the arm will move down- wards. It is important to always secure one STA 01-350MK2-TS Adjustable travel stop directly un- derneath each of the three vertical carriages.
- Page 14 A studio stand is used by professional and commer- cial photographers to capture images accurately with repeatability. It provides a rigid and stable platform essential for High Resolution Sensors used in DSLR, Medium Format and Large Format camer- as and imaging systems. A studio stand reduces vi- brations that are present when shooting hand held.
- Page 15 Tip Over Hazard: Caution must be used when moving the stand to prevent tip over. Move the stand slowly and avoid uneven surfaces as well as low and high level ob- jects. Additional caution must be used when the Horizontal arm with load (Camera or Laptop Shelf) is used in the upper area above the mid- point of the stand.
- Page 16 STA 01-350 MK2-360SPIN • Options and accessories can be purchased through your preferred authorized retailer or the studiotitanamerica.com website. Options: -Large accessory shelf STA-01-395 for notebook computer -Small accessory shelf STA-01-397A for notebook computer -STA-01-390 3-way head...
- Page 17 STA 01-350 MK2-360SPIN • The column box blue out- er plastic material is Poly- propylene, abbreviated as PP, is a recyclable thermo- plastic polymer widely used in many different products. PP is rugged. PP's resin identification code is 5, and it is recyclable.
