Summary of Contents for Studio Titan STA 01-397 U
- Page 2 If the damage is noticeable such as cracks or bro- ken off parts contact your dealer for ex- change. You can also contact Studio Titan America by email with images if you require a second opinion.
- Page 3 Intended use: This product is intended for use by professional and commercial photographers in a studio envi- ronment with a high ceiling. The wheels are de- signed to be used indoors on a floor that is smooth, hard, flat and unobstructed. The Studio Stands with internal counterweight are designed to be used at all times with a load (Camera or laptop shelf or both).
- Page 4 Product Identification:...
- Page 5 Component Identification: STA 01-397 U...
- Page 6 Component Identification: STA 01-397 A...
- Page 7 Assembly Steps: U 1. Tighten the Angle adjustment lever. [refer to page 5 ] 2. Attach small accessory shelf to a 5/8th inch spigot into base adapter and tighten the base adapter securing knob. [refer to page 5 ] 3. Attach small accessory shelf with a 3/8th inch 16 thread standard tripod head screw [the same screw used to connect a ball head to a tripod] [refer to page 5 ]...
- Page 8 Assembly Steps: A 1. Attach the stand adapter to the camera head mount plate on the horizontal arm of your studio stand. Use the original fastener supplied with head mount plate. [refer to page 6] 2. Tighten the Angle adjustment lever. [refer to page 6 ] 3.
- Page 9 Theory of Operation: A studio stand is used by professional and commer- cial photographers to capture images accurately and repeatably. It provides a rigid and stable platform for profes- sional DSLR imaging cameras. It allows the photographer to focus on the subject matter and image composition instead of holding the camera.
- Page 10 The clers. handles are made of plastic. This product does not contain lead. Studio Titan RESERVES THE RIGHT TO MAKE CHANGES AND PRODUCT ENHANCE- MENTS. PRODUCTS SUPPLIED MAY NOT BE EXACTLY AS ADVERTISED OR SHOWN ON THE...
