CAUTION: Use leather work gloves and safety glasses when handling the box, when
opening the box and when assembling the product.
HAZARD: Strapping is under tension and can jump when cut. Strapping and Buckles,
Protective Edging, Plastic Walls, Plastic Caps and Product Components and parts should be
handled with care. Work slowly, use extra caution to avoid any sharp edges.
Additional Tools may be Required: The essential tools are included. The following tools
are recommended to be on site: Box Cutter, Scissors, Screw Driver, Plyers or Adjustable
wrench, Metric Hex / Allen Key set
STA 01‐360 series
1
Advertisement
Related Manuals for Studio Titan STA 01-360
Summary of Contents for Studio Titan STA 01-360
- Page 1 CAUTION: Use leather work gloves and safety glasses when handling the box, when opening the box and when assembling the product. HAZARD: Strapping is under tension and can jump when cut. Strapping and Buckles, Protective Edging, Plastic Walls, Plastic Caps and Product Components and parts should be handled with care.
- Page 2 Transit Damage: Each package is inspected prior to being shipped from the warehouse to insure that is in perfect condi- tion. The column shipping boxes are constructed us- ing extra thick cardboard. Some packaging includes engineered plastic walls, end caps and banding. The columns are packed using engineered plastic walls and in dense foam to protect and absorb energy from reasonable drops and impacts.
- Page 3 Intended use: This product is intended for use by professional and commercial photographers in a studio envi- ronment with a high ceiling. The wheels are de- signed to be used indoors on a floor that is smooth, hard, flat and unobstructed. The Studio Stands with internal counterweight are designed to be used at all times with a load (Camera or laptop shelf or both).
- Page 4 Component Identification: STA 01-360 STA 01‐360 series...
- Page 5 Component Identification: STA 01-360 STA 01‐360 series...
- Page 6 If Counterweight strap is NOT present: the coun- ter weight is loose and can move inside the col- umn. Do not stand the column vertically. Stop the SET-UP and Contact us through the Studio Titan America website for further instructions. Please email: info@studiotitanamerica.com with the best phone number to reach you.
- Page 7 Assembly Steps: 2 Attach the three Leg Assemblies to the base. [See Diagram: A] The Hex Key tool is supplied and fasteners are supplied attached to the Base. Use the supplied Hex Key Loosen the fasteners, insert the legs and then re-tighten by hand. Note: two of the leg assemblies are supplied with foot plungers.
- Page 8 Assembly Steps: 5 Together with your Assistant…Wearing Gloves …..Carefully, Slowly raise and lift until the Vertical/ Center Column until it is standing freely on its wheels. 6 Locate the M8 Hex Wrench. Remove the two M8 x 20 bolts from the Vertical carriages. [See DI- AGRAM: B] Locate the Horizontal Arm/Bar Car- riage Assembly See [component identification] page.
- Page 9 Assembly Steps: 8 Locate two M8 Hex wrenches. Locate the Bas- ket. Locate the Basket Shaft, See [component identification] page. With the first M8 hex key hold the M8 bolt at the top of the Basket shaft. With the second M8 hex key loosen the M8 bolt at the bottom of the Basket shaft.
- Page 10 Use & Maintenance Steps: 11 HAZARD: Stop and take a moment to under- stand the effect of the counterweight. HAZARD: The counterweight forces the vertical column to travel towards the top of the Studio Stand. With- out a load [Camera, laptop, etc] on the horizontal Arm/Bar it can travel quickly towards the top of the stand.
- Page 11 Theory of Operation: A studio stand is used by professional and com- mercial photographers to capture images accu- rately with repeatability. It provides a rigid and stable platform essential for High Resolution Sen- sors used in DSLR, Medium Format and Large Format cameras and imaging systems.
- Page 12 Tip Over Hazard: Caution must be used when moving the stand to prevent tip over. Move the stand slowly and avoid uneven surfaces as well as low and high level ob- jects. Additional caution must be used when the Hor- izontal arm with load (Camera or Laptop Shelf) is used in the upper area above the midpoint of the stand.
- Page 13 Assembly Diagrams STA 01‐360 series...
- Page 14 Assembly Diagrams STA 01‐360 series...
- Page 15 Assembly Diagrams STA 01‐360 series...
- Page 16 STA 01-360 Specification • Total Height : 192cm / 75.59 in • Working Height Maximum : 180cm / 70.86 in (measured from Camera Plate to floor) • Working Height Minimum : 50cm / 19.7 in (measured from Camera Plate to floor) •...
