Page 1
Model 3/Y Ultra RGB 64-color Ambient Lighting System Installation Instruction Packing List Main control power extension cable Four footwell lights and four storage box ① ⑥ lights Four-door outline lights Four footwell extension cables ② ⑦ OBD adapter cable Main control box extension cable ③...
Page 2
+1-949 3584 793 parts of the product and can display the damage. (If the product is notified of the damage after Email: support@hansshow.com installation, claims and reissues will not be accepted, and you will need to purchase the parts again at...
Page 3
Installation Step 1. Loosen the screws in these two locations, then gently pry and release the clips to remove the door trim panel by lifting it upwards (the rear left and right doors can be removed in the same way) 2.
Page 4
Installation Step 3. Insert the door outline light (you can use a tool for assistance if needed) 4. Insert along the gap...
Page 5
Installation Step 5. Pry open the storage box light and remove it 6. Install our storage box light and secure the wires using ties...
Page 6
Installation Step 7. Once aligned with the mounting holes, press it in firmly 8. Use a pry bar to lever open the side panel and remove the wireless charging plug...
Page 7
Installation Step 9. Unscrew the screws around the side trim and remove it 10. Securely fasten the corresponding ambient lighting strip in place with screws...
Page 8
Installation Step 11. Remove the triangular trim panels on the left and right sides 12. Take off the wooden trim panel from the center console...
Page 9
Installation Step 13. Stick the center console ambient lighting strip onto the trim panel and restore it to its original position 14. Insert the wireless charging plug and put the side trim back in place (press it in while aligning with the clips)
Page 10
Installation Step 15. Connect the OBD adapter cable (note: the original vehicle has a blue plug, but here it is already connected with the adapter cable, so it has a white plug) 16. Connect the power plug of the OBD adapter cable to the one-to-four power cable (ensure that the corresponding wires are routed to their respective doors)
Page 11
Installation Step 17. Thread the ACC wire through the small hole in the seat (you can use a threading tool for assistance, make sure to hide the wire along the seat perimeter) 18. Bend the hose and pull it out, then thread the wire through the hose and into the inside of the car door...
Page 12
Installation Step 19. hread the threading tool inside 20. Wrap the corresponding ACC wire and threading tool with tape to facilitate wire routing...
Page 13
Installation Step 21. Pull the wire out from this location 22. Reconnect the wires to the door trim panel, and connect the ACC wire to the control box...
Page 14
Installation Step 23. Insert the plugs of the door outline lights and storage box lights into the control box 24. Stick the back of the control box with 3M adhesive and place it in this position, then restore the original vehicle door...
Page 15
Installation Step 25. Disassemble the door speaker (the front left and right doors can be disassembled in the same way) 26. Loosen these three screws, pry open the clips using a pry bar, then lift upwards to remove the door trim panel and unplug the connector...
Page 16
Installation Step 27. Unscrew the screws to remove the door speaker 28. Thread the power wire of the ambient lighting along the door harness using a threading tool (if necessary)
Page 17
Installation Step 29. Secure the speaker in place by tightening the screws 30. Plug in the door outline lights and storage box lights...
Page 18
Installation Step 31. Use 3M adhesive to stick the control box and secure it in place at this location 32. Reconnect the wires and ensure they are properly plugged in...
Page 19
Installation Step 33. Cover the soundproofing cotton and install the car trim panel 34. Lower the upper part along the window trim, align it with the clips on the door trim panel, press it in, and then restore it to its original position...
Page 20
Installation Step 35. Pry open this trim panel 36. Pry open this kick panel...
Page 21
Installation Step 37. Pry open this clip 38. Pry open the trim panels on both sides of the center console armrest...
Page 22
Installation Step 39. Plug in the connector of the extension cable 40. Connect the control box...
Page 23
Installation Step 41. Plug in the extension cable for the center console ambient lighting 42. Connect the extension cable to the center console ambient lighting...
Page 24
Installation Step 43. Route the two wires to the driver's footwell area 44. Connect the plug of the center console ambient lighting to the footwell light under the driver's side lower cover.
Page 25
Installation Step 45. Route this wire to the rear air conditioning vent 46. Pass the wire through this hole and then connect the plug...
Page 26
Installation Step 47. Connect the plug 48. Connect the button plug...
Page 27
Installation Step 49. Place the button underneath the center console bracket, ensuring that the wire harness is neatly hidden along the edge 50. Guide the footwell light along the center console armrest to the vicinity of the lower cover near the steering wheel air vent. Secure it in place using 3M adhesive.
Page 28
Installation Step 51. Thread the extension cable of the main control box through the small hole in the seat frame.(you can use a tool for assistance if needed) 52. The threading result should look like this...
Page 29
Installation Step 53. Secure the excess wire harness of the footwell light under the seat using cable ties 54. Route the other wire to the area under the driver's seat by threading it through the small hole in the seat...
Page 30
Installation Step 56. Thread the second footwell wire along the rear air conditioning vents and then through the small hole under the driver's seat 57. Secure the footwell light wiring using zip ties in a similar manner as the previous one, ensuring it is firmly in place...
Page 32
APP Installation Instructions and Operation Guide 1. Use WeChat, Alipay, or a browser to scan this QR code and enter the corresponding download page to select the installation. 2. After installation, open your phone's Bluetooth settings and the app. In the Bluetooth search bar, select 'Start Search' to discover the Bluetooth device named 'Pocket Link C.' Choose to connect to the device.
Page 33
APP Installation Instructions and Operation Guide Instructions for operating the mobile app: 3. In the "Colorful Mode" interface, adjust various colorful lighting effects and their speed. The sensitivity of rhythm can be adjusted to control the frequency of flashing.
Page 34
Button Usage Instructions One-Click Start Flashing Mode Seven Color Lively/Relaxing Adjustment Rhythm Breathing Mode Long Press to Turn...
Page 35
Comman Troubleshooting Guide Trouble Reason Solution Separate control - car door light not Incorrect power supply method Power source: Constant or ACC voltage for window regulator working Voltage instability, below operating Power supply voltage needs to be greater than 7.5V voltage Colors are abnormal and out of sync One of the RGB color channels is short-...
