3.4 TV-OUT Function Instruction

3.4.1 How to enable the TV-OUT function of nVIDIA M64
series.
1. Set the correct jump of VGA card for TV formats (PAL B/G NTSC....).
2. Bootup the system from monitor.
3. To Connect the signal cable between TV-OUT of VGA and TV's Video input and
turn on the TV.
4. After launch 'display proper ties' then :
A. Click 'Settings'
B. Click 'Advanced... '
C. Click 'Output Device'
D. Select 'TV'
E. Click 'Change For mat..'
3.4.2 How to adjustment screen position?
1. When the output of your VGA is set to
Monitor, You can click 'Device Setting' to
adjust the screen position
WARNING:
The Monitor
scrambled if you adjust the screen position
over the required range.
display may become
D
9
A
C
E
B
