Owner's Manual
Freedom One
Freedom One Lectern
55355
(Includes lectern, equipment rack,
and unit-to-unit connector kit)
55366
Equipment rack only
55367
Unit-to-unit connector kit
55368
Freedom One Lectern only
Equipment rack - 55366
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported within 5
days of receipt. To report information regarding missing parts or
damage, to purchase parts or accessories, or if you have any
questions, please contact us.
Thank you for purchasing Spectrum products!
??
™
Sit-to-Stand (S2S) workstation
Unit-to-unit Connector Kit - 55367
Avant d'utiliser ce produit:
• Veillez à lire ce guide
• Respectez les consignes de sécurité et d'utilisation
• Vérifiez que vous disposez de toutes les pièces
nécessaires à l'installation
Les pièces endommagées pendant le transport doivent faire
l'objet d'un rapport dans les 5 jours de leur réception. Veuillez
prendre contact avec nous si des pièces manquent ou sont
abîmées, si vous avez des questions, ou encore pour acheter
des pièces ou des accessoires.
Merci pour votre achat d'un produit Spectrum!
www.spectrumfurniture.com
Owner's Manual
Le manuel du propriétaire
El manual del propietario
Important
Antes de utilizar este producto:
• Lea este manual
• Cumpla con todas las instrucciones de prevención de
• Revise que todas las partes y las cantidades correctas
Si alguna parte se dañó durante el embarque, deberá reportarla
en un lapso de 5 días a partir de la recepción. Para reportar
cualquier información sobre partes faltantes o dañadas, para
adquirirlas o comprar accesorios, o bien, si tiene alguna duda,
póngase en contacto con nosotros.
Specs
Specs
Spécifications
Spécifications
Especificaciones
Especificaciones
Freedom One Lectern w/
Equipment Rack - 55355
Freedom One Lectern - 55368
Importante
accidentes y operativas
estén incluidas
¡Gracias por adquirir productos Spectrum!
800-235-1262
800-235-1262
Video
Video
Vidéo
Vidéo
Vídeo
Vídeo
0115923R8 Page 1 of 11
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Industries Freedom One Sit-to-Stand S2S
Summary of Contents for Spectrum Industries Freedom One Sit-to-Stand S2S
- Page 1 Owner’s Manual ™ Freedom One Sit-to-Stand (S2S) workstation Freedom One Lectern 55355 (Includes lectern, equipment rack, and unit-to-unit connector kit) 55366 Equipment rack only 55367 Unit-to-unit connector kit 55368 Freedom One Lectern only Freedom One Lectern w/ Equipment Rack - 55355 Equipment rack - 55366 Unit-to-unit Connector Kit - 55367 Freedom One Lectern - 55368...
- Page 2 This lectern must always be used by adults or with adult supervision. serviceable parts or user-maintenance requirements. If servicing is necessary, please contact Spectrum Industries for assistance. Warning - Relocating audio and/or video equipment to furniture not specifi cally CAUTION designed to support audio and/or video equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.
- Page 3 Equipment rack assembly / setup Attach casters or glides ” for casters ” for glides 1. Determine if you want casters or glides installed. Figure 1A. Caster Glide Note: Because the equipment rack needs to be flipped upside-down to install the casters/glides, Spectrum does not recommend installing any rack-mount equipment until Figure 1A the rack has been flipped back upright.
- Page 4 Lectern assembly / setup ” for casters Swapping casters for glides (optional) ” for glides Note: The Freedom One Lectern comes with factory-installed casters. If a more permanent non-moving lectern is needed, the casters can easily be replaced with the included glides. Figure 2A. 1.
- Page 5 Unit-to-unit connector kit assembly / setup 1. Attach connector kit to equipment rack 1. Determine which side of the lectern you want the equipment rack mounted to. 2. Lay the equipment rack down on the floor with the side opposite the lectern down. Figure 3A shows assembly with the equipment rack on the left-side of the lectern.
- Page 6 6. Carefully lift and tip up the equipment rack. Be careful not to apply any side load to the casters while tipping as it could cause damage. Figure 3B. 7. Place blocking under the equipment rack to support and level the assembly. Equipment rack Place blocking here...
- Page 7 3. Attach lectern to equipment rack 1. Move the lectern over the installed connector tubes on the equipment rack. Figure 3D. 2. Remove the necessary hole plugs in the lectern base to access mounting holes. 3. Align the lectern base mounting holes with the connector tubes. 4.
- Page 8 Lectern lower modesty panel adjustment Note: If the modesty panels become misaligned and interference occurs when extending or retracting, follow these steps to adjust. 1. Push the worksurface down to the lowest position. Figure 5A. 2. Loosen the (7) 1/4-20 x 15mm JC bolts attaching the lower modesty panel to the base. 3.
- Page 9 Accessories Flip-up Shelf - 68204 Clear Acrylic Locking Door - 68153 Solid Locking Door - 68152 (can be mounted to be hinged from (can be mounted to be hinged 21.1875”W x 30”D the left or right-side) from the left or right side) 50 lb max capacity Available in black or silver sparkle Available in black or silver sparkle...
- Page 10 Si une maintenance est requise, sous la surveillance d’un adulte. communiquer avec Spectrum Industries pour obtenir de l’aide. Avertissement - Reloger un équipement audio ou vidéo sur un Avertissement - Un enfant qui grimpe sur un meuble d’équipement meuble non conçu pour supporter cet équipement pourrait entraîner...
-
Page 11: Warranty
Product Registration Dear customer, Product Number: Spectrum Industries would like to thank you for your purchase. Please take a moment to register your product for valuable warranty and product information. Locate the product and serial num- Serial Number: bers on the label located either on the inside of the front door, or under the main worksurface.
