- Page 1 SUPPORT CALL GUARANTEE OREA550 MOTOR DRIVE KIT For sliding gates Ref. 114464 24 V SLIDING GATES 500 KG COMPATIBLE WITH ALL SOLAR OPTION SMARTPHONE EASY TO KINDS OF GATE COMPATIBLE OPTION INSTALL www.avidsen.com...
-
Page 2: Table Of Contents
MOTOR DRIVE KIT FOR SLIDING GATE CONTENTS A - SAFETY 10.1 - Additional photocells 10.2 - Additional control parts INSTRUCTIONS 10.3 - Key selector 10.4 - Emergency stop parts 10.5 - Solar power kit 1 - OPERATING PRECAUTIONS 2 - INSTALLATION PRECAUTIONS D - BEGINNING 3 - MAINTENANCE AND CLEANING OPERATION... - Page 3 E - USE AND LEGAL INFORMATION 1 - WARNING 2 - OPENING/CLOSING 1 - TECHNICAL CHARACTERISTICS 2.1 - Type of command 2 - WARRANTY 2.2 - Operating modes 3 - HELP AND ADVICE 2.2.1 - “Semi-automatic closing” mode 33 2.2.2 - “Automatic closing” mode 4 - PRODUCT RETURNS/AFTER-SALES 2.2.3 - “Collective”...
-
Page 4: A - Safety Instructions
Avidsen cannot be held liable for any use that does related to their development. not comply with the instructions in this manual and This automatic gate opening mechanism, and causes damage. -
Page 5: Maintenance And Cleaning
Keep the remote controls out of the recharge them as they may explode! reach of children. The Avidsen company shall not be responsible This symbol means that devices no in case of damage if installation is not longer in use should not be disposed of conducted as indicated in these instructions. -
Page 6: B - Product Description
MOTOR DRIVE KIT FOR SLIDING GATE B - PRODUCT DESCRIPTION 1 - KIT CONTENTS x 24 x 24 Geared motor Washers Rack Rack mounting screws Flashing light Floor fastening pin Remote control Release key 2 - EQUIPMENT REQUIRED (NOT INCLUDED) The tools and screws required for the installation must be in good condition and compliant with applicable safety standards. -
Page 7: C - Installation
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION HAZARD ANALYSIS SAFETY CHECKS ON THE GATE REGULATION • The guide rail must be perfectly straight, Installation of a motorised gate or a motor drive on horizontal and fastened correctly to the ground. an existing gate within the framework of “Residential”... -
Page 8: Safety Rules
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION Grille, net or safety edge Upper runner Clearance zone Rail Open end stop Close end stop SAFETY RULES The actual opening of a gate may create dangerous situations for people, goods and vehicles in the vicinity that by nature, cannot always be avoided by design. - Page 9 MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION To avoid any risk of confinement in the gate clearance zone, the safety distances given in the diagram below must be observed. post gate stop 8 mm view from above P = 500 mm minimum if T is greater than 100 mm P = 200 mm minimum if T is less than 100 mm On the upper runners There is a risk of hands getting caught between the upper runners and the gate.
-
Page 10: Attaching Components
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION opening. There are two solutions to remove this hazard: - Install a screen or net on the gate. The mesh must be no larger than 20 x 20 mm. - Install one or two safety edges on the post. grille or net safety edge 1 safety edge... -
Page 11: Attaching The Geared Motor
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION Flashing light Attachment : page 15 Reception photocell Attachment : page 16 Transmission photocell Attachment : page 16 opening direction Rack Geared motor Attachment : page 13 Attachment : page 11 inner side of the property •... - Page 12 MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION Post Post 15 mm Gate Gate 15 mm 5.5 cm 5.5 cm Post Template Template Foundation Foundation view from above The cable run between must comply with applicable standards (NFC 15-100). Either the cable is 80 cm deep with red warning mesh, or the cable is run through a sheath.
-
Page 13: Attaching The Rack
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION When the motor is horizontal (adjust horizontality using the nuts under the motor), tighten the locknuts to block the clamp nut, then tighten the clamp nuts to keep the motor in position. Leave an air gap under the motor to prevent water from stagnating under the motor. - Page 14 MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION - Using a ruler and spirit level, assemble and attach the remaining rack components to the gate. Once attached, all components must be perfectly aligned and level. ruler level 10mm 3 - INSTALLING THE FLASHING LIGHT The flashing light must be attached to the top of the pillar on which the motor unit is mounted, and it must be visible from both the inside and the outside.
-
Page 15: Attaching The Set Of Photocells
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 4 - ATTACHING THE SET OF PHOTOCELLS Important notes: • The photocells must be perfectly aligned and parallel to each other. • The reception photocells (RX is indicated at the back) must be installed at the same side of the gate as the geared motor. -
Page 16: Connections
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 30 cm min 60 cm max outer side of the property perfect alignment 10 cm min / 15 cm view from above outer side of the property Mounting: • Mount the photocells on the posts. •... - Page 17 MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION Typical connection flashing light wired control part (contactor, motor intercom, etc.) 2 x 0.5 mm RX photocell 3 x 1.5 mm TX photocell Telephone cable emergency stop part (punch button, 2 x 0.5 mm safety edge, 2 set of photocells, etc.)
-
Page 18: Electronic Control Card
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 6 - ELECTRONIC CONTROL CARD For ease of connection, all terminal blocks are removable. battery transfo red LED connection green LED connection battery transformer fuse settings fuse buttons gateopening HALL pedestrian antenna motor sensor... -
Page 19: Flashing Light
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 8 - FLASHING LIGHT • Connect the flashing light wires to the terminal block as shown in the diagram below and reconnect the terminal block. • Maintain the polarity. • Use 2 x 0.5 mm section cable at least. -
Page 20: Optional Accessories
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 10 - OPTIONAL ACCESSORIES Backup battery Set of Additional remote Videophone photocells control additional 0.5 m rack Connected Coded Solar power kit module keypad 10.1 - ADDITIONAL PHOTOCELLS For use when the gate is not visible. You must install a second set of photocells to prevent the gate from opening when an item (car, person, etc.) is behind the gate. - Page 21 MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION Primary edge protection By connecting the photocells in this way, the system reacts to a break of one or the other infrared beams only during closing. stop post post view from above Primary and secondary edge protection In the previous case, the second set cannot be mounted to protect the secondary edge of the gate during opening.
-
Page 22: Additional Control Parts
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION 10.2 - ADDITIONAL CONTROL PARTS Gate control Pedestrian control HALL push-button, push-button, intercom output, intercom output, key contact key contact Note: These control parts must be normally open dry contacts. It is possible to use several wired control parts on the same input, but for this they must be connected in parallel: HALL push-button,... -
Page 23: Solar Power Kit
MOTOR DRIVE KIT FOR SLIDING GATE C - INSTALLATION No emergency stop part connected Leave the connector One part connected Two parts connected (serial assembly) 10.4 - SOLAR POWER KIT This motor drive may be completely powered by solar energy. To do this, there is a battery and solar panel kit that can be connected instead of the 230V power supply. -
Page 24: D - Beginning Operation
MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION 1 - SETTINGS INTERFACE All LEDs are turned off except the green LED • If the green LED is not lit, press PROG. Indicators - Lit up green LEDs are an error code (see paragraph “Event history and error code”). - Page 25 MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION...
-
Page 26: Photocell Alignment Procedure
To find out more, please check out our tu- • Press and hold “–” › the gate should close › torials at www.avidsen.com/fr/assistance/ release the button. tutoriel-sav If the gate opens instead of closing, the motor is connected backwards. -
Page 27: Programming Remote Controls
MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION Meaning The motor has run for 60 seconds on closing without the gate finding a stop; this is not normal. The motor has run for less than 3 seconds to open the gate; this is not normal. Can the gate open and close freely? The motor has run for less than 3 seconds to close the gate;... -
Page 28: Motor Force
MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION learnt, follow the procedure below Semi-automatic mode (mode 1) (default) • Press “–” for 3 seconds and L1 will switch on. • Closed gate -> to open the gate, press and •... -
Page 29: Time Delay
MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION • PTo change the operating mode, use the “+” and • Use the “–” and “+” buttons to change this value “-” buttons, then confirm with the SET button. (see table below). At the time of this confirmation, the system will •... -
Page 30: Speed
MOTOR DRIVE KIT FOR SLIDING GATE D - BEGINNING OPERATION 3.2.1 - SPEED You can adjust the speed by a value of 0 to 5. To adjust this value, follow this procedure • Press PROG for 3 seconds › L0 will flash once and L1 will turn on. -
Page 31: Photocell Self-Test (Optional)
To activate or deactivate this function, follow situations. the procedure below Avidsen cannot be held liable for any installation or • Press PROG for 3 seconds › L0 will flash once use that does not comply with the instructions and and L1 will turn on. -
Page 32: Opening/Closing
MOTOR DRIVE KIT FOR SLIDING GATE E - USE these instructions for any later use. General Safety Obligations 2.2 - OPERATING MODES • This device is not intended for use by children or persons with reduced physical, sensory or mental The operating mode is set by following the abilities or lack of experience or familiarity, unless instructions in the “operating mode”... -
Page 33: Collective" Mode
MOTOR DRIVE KIT FOR SLIDING GATE E - USE manoeuvre is complete. is cut, the gate will wait for the beam to be cleared before closing again. If, after 3 minutes, the beam At any time, you can stop the gate’s movement by has still not been cleared, automatic closing will be activating a command (total or partial). -
Page 34: Motor Engagement
MOTOR DRIVE KIT FOR SLIDING GATE E - USE months: motor operation, photocells, control devices, etc. 2 - OPERATING INDICATORS This system has two operating indicators: the battery charge level (optional) and the event log. 3 - BATTERY VOLTAGE (FOR OPTIONAL SOLAR POWER KIT) You can display the battery charge level. -
Page 35: Anomaly Guide
MOTOR DRIVE KIT FOR SLIDING GATE E - USE 4 - ANOMALY GUIDE To find out more, please check out our tutorials on our website www.avidsen.com/fr/assistance/tutoriel-sav TYPE OF FAULT PROBABLE CAUSE WHAT YOU SHOULD DO When activating the opening No 230-volt power supply... - Page 36 MOTOR DRIVE KIT FOR SLIDING GATE F - MAINTENANCE AND UPKEEP Meaning Type The emergency stop input has been activated A card power supply fault has been detected. It may be a short-circuit on the +12V output. check the connections. An obstacle has been detected in the gate when opening.
-
Page 37: Manual Control
MOTOR DRIVE KIT FOR SLIDING GATE F - MAINTENANCE AND UPKEEP 4.1 - MANUAL CONTROL You can manoeuvre the gate with no programming, for example during installation, to check the opening direction is correct. • To enter manual mode, press “SET” for 3 seconds and LED L3 will fl ash. -
Page 38: Technical Characteristics
The technical characteristics are provided as an indication only and for a temperature of +20°C. The company Avidsen reserves the right to modify these characteristics at any time, while under all circumstances guaranteeing these products’ smooth operation and the type of use intended, in an aim to improve these products. - Page 39 MOTOR DRIVE KIT FOR SLIDING GATE G - TECHNICAL AND LEGAL INFORMATION Remote control Type: AM On/Off Keying (OOK) modulation. 16-bit Rolling code Type encoder (i.e. 65,536 possible combinations) 433.92 MHz Frequency 3V, CR2032 battery Power supply 4 keys Keys < 10 mW Radiated power 2 years at a rate of 10 x 2s uses per day Battery life -20°C / +60°C...
-
Page 40: Warranty
SERVICE for 3 years from the date of purchase. Proof of purchase must be retained for the duration of Avidsen undertakes to keep a stock of spare parts the warranty period. for this product throughout the contractual warranty • The warranty does not cover damage caused by negligence, knocks or accidents. -
Page 41: Declaration Of Conformity
Brand: AVIDSEN Trade description: Motorisation kit for sliding gates Trade reference: 114464 Kit consists of: An integrated electronic geared motor + 1 flashing light + 2 remote controls + 1 set of photocells NAME AND POSITION OF SIGNATORY: Alexandre Chaverot, CEO Declares with full responsibility that: The product complies with the RED 2014/53/EU directive. - Page 42 Avidsen 19 avenue Marcel Dassault 37200 Tours - France...
