Programming Guide | VLT® HVAC Drive FC 131
Table 15: Control Word
(continued)
Bit
07
08
09
10
11
12
13
14
15
16-05 Main Actual Value [%]
Default value: 0.00%
Setup:
1 setup
Data type: Int16
View the main actual value sent from the drive via bus.
16-09 Custom Readout
Default value: 0.00 CustomReadoutUnit
Setup: 1 setup
Data type:
Int32
View the user-defined readouts as defined in parameter 0-30 Custom Readout Unit, parameter 0-31 Custom Readout Min Value, and
parameter 0-32 Custom Readout Max Value.
16-1* Motor Status
4.13.2
Parameters for reading the motor status values.
16-10 Power [kW]
Default value: 0.000 kW
Setup:
1 setup
Data type: Uint32
View the actual motor power in kW. The value shown is calculated on the basis of the actual DC-link voltage and DC-link current.
16-11 Power [hp]
Default value: 0.000 hp
162 | Danfoss A/S © 2024.11
Bit=0
No warning
Speed ≠ ref.
Local control
Out of range
Not running
No function
Voltage OK
Current OK
Thermal-level OK
Bit=1
Warning
Speed = ref.
Bus control
Frequency OK
Running
No function
Above limit
Above limit
Above limit
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Parameter Descriptions
Range (-200.00–200.00%)
-2
True
Range (0.00–9999.00
CustomReadoutUnit)
-2
True
Range (0.000–1000.000 kW)
-3
True
Range (0.000–1000.000 hp)
AU370727746889en-000201 / 130R0994
