Patriot Lighting 91650 Manual

OPERATION
Dusk-to-dawn operation enables the light fixture to automatically turn ON when dark outside and turn OFF when the
sun rises, thus saving energy costs.
Turn the power on at the fuse/breaker box, turn any connected wall switch to the ON position and leave it ON at all
times to enable dusk-to-dawn function automatically.
Illuminance: ON < 30 LUX; OFF > 80 LUX
Working temperature: -22°F ~ 104°F ( -30℃ ~ 40℃)
Note: When power is initially turned ON, wait 1 to 2 minutes for the system's circuit to stabilize.
The fixture should be installed in good photosensitivity, away from obstacles affecting its acceptance of natural light.
If an artificial light source (e.g. automobile headlights) should accidentally activate the photocell and turn off the unit,
the time delay is about 10 seconds.
TROUBLESHOOTING
Issues Possible cause
Lights will not 1. Light switch is turned off.
come on 2. Light bulb is loose or burned out.
3. Fuse is blown or circuit breaker is turned off.
4. Incorrect circuit wiring
5. The fixture senses daylight.
The light cycles The photocell light sensor is sensing reflected
ON and OFF light.
The light flickers The light fixture is wired through a dimmer
switch.
The light stays The light sensor is in a shaded area.
ON.
CARE AND MAINTENANCE
Before cleaning:
1. Ensure the power is off.
2. To prolong the original appearance, clean the light fixture with clear water and a soft, damp cloth only.
3. Do not use abrasive cleaners. Do not apply paints, solvents, or any other chemicals on this light fixture. They
could cause a premature deterioration of the finish and may void the warranty.
FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails due to a defect in material
workmanship within five (5) years from the date of original purchase, simply bring this lighting fixture with the original sales receipt back to
your nearest MENARDS retail store. At its discretion, PARTIOT LIGHTING agrees to have the product or any defective part(s) repaired or
R
replaced with the same or similar PATRIOT LIGHTING product or part free of charge, within the stated warranty period, when returned by
R
the original purchaser with original sales receipt. This warranty; (1) excludes expendable parts including but not limited to light bulbs; (2) does
not cover damage that has resulted from abuse or misuse; and (3) does not cover any losses, labor, injuries to persons/property or costs.
This warranty does give you specific legal rights and you may have other rights, which vary from state to state.
Solution
1. Turn light switch on.
2. Check bulb and replace if burned out.
3. Replace fuse or turn circuit breaker on.
4. Verify wiring is correct.
5. Cover the photocell sensor. Wait 10
seconds until the fixture turns ON.
Relocate the light fixture to a location
where there is no reflected light.
Replace the dimmer with a standard
ON/OFF switch.
The fixture should be moved to a location
with enough light in the daylight hours for
the light sensor to work.
R
R
4
Questions, problems, missing parts?
Please email us at customer-service@ewccglobal.com.cn,
or call us at 1-888-722-5089.
PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
BB
Outlet box screw
Mounting bracket
x 1 (pre-attached)
DD EE
Wire connector Rubber washer x 4
x 2 (2pcs pre-attached, 2pcs spare)
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product.
WARNING
Turn off electricity at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or
switching off circuit breaker).
This product must be installed by persons with experience in household wiring or by a qualified electrician. The
electrical system and the method of electrically connecting the fixture to it must be in accordance with the National
Electrical Code and local building codes.
SKU Number: 356-9486 356-9487
Model Number: 91650, 91651
Dusk to Dawn Dual Head Security Light
CC
Mounting screw x 4
x 2 (2pcs pre-attached, 2pcs spare)
FF
Coverplate gasket
x 1 (pre-attached)
1
