Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-855-508-3883
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
SAFETY INFORMATION
Please read the entire manual before attempting to assemble, operate, or install the product.
WARNING
•Turn OFF the power to the circuit breaker or fuse box.
•This light fixture requires a 100-240 volt AC power source.
•This light fixture is for outdoor use.
•The light fixture should be mounted approximately 6.6 ft. (2 m) above the ground. If the light fixture is mounted
higher than recommended, the sensor's coverage area will be reduced.
CAUTION
•The electrical wiring must be completed by a qualified electrician, or a person trained to perform electrical
installations. This person must be familiar with similar products and their connection regulations. Remove all
packaging materials from the product.
•The manufacturer does not accept any responsibility for injuries or damage resulting from improper use of the light.
PREPARATION
• Before beginning assembly, installation or operation of product, make sure all parts are present. Compare parts with
package contents list and diagram on previous page. If any part is missing or damaged, do not attempt to assemble,
install or operate the product. Contact customer service for replacement parts.
• Tools Required for Assembly (not included): Screwdriver, Electric drill, Ladder, Level, silicone sealant.
Mounting bracket screw x2
Mounting bracket x1
SKU Number: 356-9465
2500Lumen Multi-Volts
Motion Security Light
Model Number: Z-S-2500-BZ
Mounting bolt x2
356-9466
Z-S-2500-MW
