Making Network Connections

Table 4-4 Maximum 1000BASE-ZX Gigabit Ethernet Cable Length

Fiber Size
9/125 micron
single-mode fiber
Note: For link spans exceeding 70 km, you may need to use premium single mode fiber
or dispersion shifted single mode fiber.

100 Mbps Fast Ethernet Collision Domain

Type Cable Type
100BASE-TX Category 5 or better 100-ohm UTP or STP 100 m (328 ft)

10 Mbps Ethernet Collision Domain

Type Cable Type
10BASE-T Twisted Pair, Categories 3, 4, 5 or better
100-ohm UTP

Cable Labeling and Connection Records

When planning a network installation, it is essential to label the opposing ends of
cables and to record where each cable is connected. Doing so will enable you to
easily locate inter-connected devices, isolate faults and change your topology
without need for unnecessary time consumption.
To best manage the physical implementations of your network, follow these
guidelines:
• Clearly label the opposing ends of each cable.
• Using your building's floor plans, draw a map of the location of all
network-connected equipment. For each piece of equipment, identify the devices
to which it is connected.
• Note the length of each cable and the maximum cable length supported by the
switch ports.
• For ease of understanding, use a location-based key when assigning prefixes to
your cable labeling.
• Use sequential numbers for cables that originate from the same equipment.
• Differentiate between racks by naming accordingly.
• Label each separate piece of equipment.
• Display a copy of your equipment map, including keys to all abbreviations at each
equipment rack.
4-6
Fiber Bandwidth
N/A

Table 4-5 Maximum Fast Ethernet Cable Length

Table 4-6 Maximum Ethernet Cable Length

Maximum Cable Length
70 m - 100 km (43 ft - 62
miles)
Max. Cable Length
Max. Cable Length
100 m (328 ft)
Connector
LC
Connector
RJ-45
Connector
RJ-45
