Panasonic FZ-VEW553 Series Operating Instructions Manual

<For nanoSIM users> „ Inserting
ENGLISH
Thank you for using Panasonic products.
IMPORTANT
To operate this 5G Module, it is necessary to replace the WWAN driver.
For more details about the using this product, please visit the following
website:
https://askpc.panasonic.co.jp/manual/option/w/
„ Supplied accessories
Check and identify the supplied accessories. If you do not find the described ac-
cessories, contact your support office.
z Screw ............................................................................................................ 6
(spare screws included)
z Operating Instructions (this leaflet) .............................................................. 1
Printed in Taiwan
„ Specification
Refer to è
Operating Instructions - Reference Manual.
„ Regulatory Information
For U.S.A.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must ac-
cept any interference received, including interference that may cause undesired
operation.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
z Consult the Panasonic Service Center or an experienced radio/TV technician
for help.
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact:
https://na.panasonic.com/us/support
FCC RF Exposure Warning:
z This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
z This equipment has been approved for portable operation and does not require
any minimum spacing be provided between antennas and all person's body.
z This equipment may not be co-located or operated with any other antenna or
transmitter.
Operating Instructions
5G Module
FZ-VEW553
Model No.
0.45 N•m ± 0.05 N•m
(4.5 kgf•cm ± 0.5 kgf•cm)
DHQX1949ZA/T1
For Canada / Pour le Canada
Canadian ICES-003
CAN ICES(B)/NMB(B)
Innovation, Science and Economic Development Canada (ISED)
This product complies with ISED's licence-exempt RSSs.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
series
(2) this device must accept any interference, including interference that may
cause undesired operation of the device.
RF Exposure Warning
z This equipment complies with ISED's radiation exposure limits set forth for an
uncontrolled environment.
z This equipment has been approved for portable operation, and does not
require any minimum spacing be provided between antennas and all person's
body.
Innovation, Sciences et Développement économique Canada (ISDE)
Cet équipement est conforme aux normes sans licence CNR d'ISDE.
Son fonctionnement est soumis aux deux conditions suivantes :
(1) ce dispositif ne peut produire de brouillage, et
(2) ce dispositif doit accepter le brouillage, y compris le brouillage pouvant entraî-
ner le fonctionnement non désiré de l'appareil.
Avertissement d'exposition aux RF
z Cet équipement est conforme aux limites d'exposition aux rayonnements
d'ISDE établies pour un environnement non contrôlé.
z Ce équipement a été approuvé à des fins d'opération portable; aucun espace-
minimum entre les antennes et le corps de l'utilisateur n'est requis.
For Europe
<Only for model with a "CE" mark on the product>
The declaration of conformity is available at https://www.ptc.panasonic.eu
Manufactured by:
Panasonic Connect Co., Ltd.
4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
Importer for EU:
Panasonic Connect Europe GmbH
HS1024-0
Hagenauer Strasse 43, 65203 Wiesbaden, Germany
Authorised Representative in EU:
Panasonic Connect Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Maximum radio - frequency power transmitted in the frequency bands
Type of Communica-
wireless
WWAN W-CDMA
(EM9190)
W-CDMA
LTE
LTE
LTE
LTE
LTE
LTE
LTE
LTE
LTE
LTE
5G
5G
5G
5G
5G
5G
Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying
documents means that used electrical and electronic products
must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products,
please take them to applicable collection points in accordance with
your national legislation.
By disposing of them correctly, you will help to save valuable
resources and prevent any potential negative effects on human
health and the environment. For more information about collection and recycling,
6-1-M
please contact your local authority.
Penalties may be applicable for incorrect disposal of this waste, in accordance
with national legislation.
25A-1-M
Declaration of Conformity (DoC)
"Hereby, Panasonic declares that this product is in compliance
with the essential requirements and other relevant provisions
of EU Council Directives."
Frequency band
tion Mode
1920 - 1980 MHz (Band I)
880 - 915 MHz (Band VIII)
1920 - 1980 MHz (Band 1)
1710 - 1785 MHz (Band 3)
2500 - 2570 MHz (Band 7)
880 - 915 MHz (Band 8)
832 - 862 MHz (Band 20)
703 - 748 MHz (Band 28)
2010 - 2025 MHz (Band 34)
2570 - 2620 MHz (Band 38)
2300 - 2400 MHz (Band 40)
3400 - 3600 MHz (Band 42)
1920 - 1980 MHz (n1)
1710 - 1785 MHz (n3)
703 - 748 MHz (n28)
2496 - 2690 MHz (n41)
3400 - 4200 MHz (n77)
3400 - 3800 MHz (n78)
7-1-M
30D-1-Ca
18A-2-E
Maximum
transmit power
24.5 dBm
24.5 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.0 dBm
24.5 dBm
24.5 dBm
24.5 dBm
24.5 dBm
24.5 dBm
24.5 dBm
18-2-1-E
36B-1-E
