Panasonic FZ-VDM553 Quick Start Manual

TOUGHBOOK Universal Bay
You can select from the following options.
FZ-VDM553 FZ-VBD553
DVD MULTI Drive Blu-ray Disc Drive
Pack Pack
IMPORTANT
<Only when using optional 5G Module>
l
Before inserting the 5G Module, please confirm the version of BIOS and EC by performing the following operation.
1. Click
Please update the BIOS version to V3.00L17 or later and the EC version to V3.00L11 or later with following web page.
https://global-pc-support.connect.panasonic.com/dldocs/86674
Inserting an option to the TOUGHBOOK universal bay
1. Turn off the computer and disconnect the AC adaptor.
IMPORTANT
To insert a SSD pack, turn off the computer completely the following.
l
Similarly for other options, we recommend that you turn off the computer completely the following.
l
1. Click
2. Click [Restart now] in "Advanced startup".
3. Click [Restart now] on the "We'll restart your device so save your work" screen.
4. Click [Turn off your PC].
2. Turn your computer over and remove the battery pack.
<When using second battery pack>
Remove the second battery pack.
l
Make sure no foreign objects are under the computer.
3. Insert an option to the TOUGHBOOK universal bay.
The dummy pack may have been inserted.
l
1. <When using 5G Module>
Remove the screws (A).
Use the PH 1 (PH #1) screwdriver.
FZ-VSD551
SSD Pack Smart Card
Reader
(Start) - [All apps] - (Panasonic PC Settings Utility) -
(Start) - [Settings] - [System] - [Recovery].
FZ-VSC552 FZ-VDR553
DVD-ROM Drive
Pack
FZ-VBR551 / FZ-VBR552
Barcode Reader <Only for North
America>
(Support) - (System).
FZ-VEW553
5G Module
