- Page 1 EZ Connect ™ Wireless Access Point User Guide SMC2652W V1.0...
- Page 2 Computer A PC or Power Macintosh with an available PCI slot. Package Checklist: 1 x EZ Connect Wireless Access point - SMC2652W 1 x Antenna (dipole, omni-directional) 1 x DC power adapter 1 x Software CD (contains software drivers, utility and manual)
-
Page 3: Installation
Web browser for configuration. • Installation: 1. Select a site - Choose a proper place for your SMC2652W Access point. In general, the best location to place the access point is at the centre of your wireless coverage area, within line of sight to all your mobile stations. - Page 4 SMC2652W. otherwise, the product may be damaged. Configuration Your SMC2652W is a plug and Play device. This means that you do not need to configure it in most cases. If you are adding this devices into an already existing wireless network, or if you need to configure some advanced settings, follow the instructions below.
- Page 5 The information MIB screen displays the categories of information shown above. In the “AP control MIB page”, set the parameters and then double click on “apply” to implement the settings. DS channel - Set the channel number as the operating radio channel.
- Page 6 “Apply”. In the change password screen you may change the password on the access point. As password is required to configure the SMC2652W Access point. We suggest changing your password from the default to ensure network security.
- Page 7 An ad hoc wireless LAN can be used for a branch office or SOHO operation. Infrastructure Wireless LAN The SMC2652W can also provide access to a wired LAN for wireless workstations. An integrated wired and wireless LAN is called an Infrastructure configuration. A Basic Service Set (BSS) consists of a group of wireless PC users, and an access point that is directly connected to the wired LAN.
- Page 8 (SSID) for the wireless card to the BSS ID of the access point you want to connect to. Check with your administrator for the BSS ID of the SMC2652W access point he wants you to connect to. Roaming Wireless PCs A wireless infrastructure can also support roaming for mobile workers.
-
Page 9: Specifications
Control mode is automatically exited when the AP has not detected any push button preeses for approx. 3 seconds. At that point it will flash both LED’s twice, indicating it is proceeding with the boot. SPECIFICATIONS Model SMC2652W Maximum channels ETSI: 13 Maximum clients Operating range Cell seperation... - Page 10 Copyright - New Text ?? Information furnished by SMC brand is believed to be accurate and reliable.However,no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use.No license is granted by implication or otherwise under any patent or patents by SMC.SMC reserves the right to change specifications at any time without notice.
