Immergas 3.031393 Installation

GENERAL WARNINGS.
All Immergas products are protected with suitable transport packaging.
The material must be stored in a dry place protected from the weather.
This instruction manual provides technical information for installing the Immergas kit. As for the other issues related to kit installation (e.g. safety in
the workplace, environmental protection, accident prevention), it is necessary to comply with the provisions specified in the regulations in force and with the
principles of good practice.
Improper installation or assembly of the Immergas appliance and/or components, accessories, kits and devices can cause unexpected problems for people, animals
and objects. Read the instructions provided with the product carefully to ensure proper installation.
Installation and maintenance must be performed in compliance with the regulations in force, according to the manufacturer's instructions and by
professionally qualified staff, meaning staff with specific technical skills in the plant sector, as envisioned by the law.
INSTALLATION.
If the appliance leaves the factory with "B" configuration (open chamber and fan assisted), change the configuration to type "C" (sealed chamber and fan
assisted) by disassembling the Ø 80 adapter, the bracket, the clip and the gasket on the cover (Fig. 1 Det. A).
Attention: the boiler must be installed exclusively with an original Immer-gas "Green Range" air intake device made of plastic and a visible stainless
steel terminal for the flue extraction, as required by the regulations in force.
Positioning the gaskets (Fig. 2): check the correct positioning of the gaskets before assembly. In the event that the lubrication of the components (already
carried out by the manufacturer) is not sufficient, remove the residual lubri-cant by using a dry cloth. Then spread the elements with commonly-used or
industrial grade talc to facilitate the installation.
Kit assembly (Fig. 1): install the Ø 80/125 adapter with gasket (1) on the central hole of the boiler to the end stop. Fasten the unit to the cover us-
ing the metal-sheet plate (2 Fig. B) screwing it with the screws previously removed from the boiler. Engage the bend Ø 80/125 (3) with the male
side (smooth) to the end stop on the adapter (1). Insert the reduction Ø 80/125 - Ø 110/160 (4) with male side (smooth) in the female side of
the bend (3) (with lip seal) up to the end stop. Then insert the Ø 110/160 termi-nal (5) into the reduction, making sure to have previously
inserted the two internal and external sealing plates (7) on the terminal. Fix the sealing plates to the wall with the screws and plugs supplied
(6). This will ensure the sealing efficiency of the kit components.
External grid (Fig. 3): the Ø 110/160 intake/exhaust terminal, if properly installed, is pleasant to look at on the outside of the building. Make sure that the internal
and external sealing plates are correctly brought to the stop and fixed with screws to the internal and external walls.
N.B.: for safety purposes, do not obstruct the boiler intake/exhaust terminal, even temporarily.
• Extension pipes and concentric elbows Ø 110/160 push-fitting gasket. To install any push-fit extensions with other flue extraction elements, it is
necessary to do the following: install the concentric pipe or elbow with the male side (smooth) on the female section (with lip seal) to the end stop on the
previously installed element. This will ensure the sealing and joining of the elements correctly.
The kit Ø 110/160 can be installed with the rear, right side, left side or front outlet.
Application to Victrix Pro.
- With rear outlet (Fig. 4): Using the horizontal intake/exhaust kit, without the special extensions, the maximum distance between the vertical exhaust
axis and the outside wall is 1188 mm. The 1000 mm pipe length enables routing through a wall with maximum thickness of 860 mm.
Cod. 1.044887 - Rev. ST.005142/001
HORIZONTAL TERMINAL KIT
CODE 3.031393
IE
Ø 110/160
