ECO-WORTHY ECOS 30-U User Manual

12v/24v 30a solar charge controller

Advertisement

Available languages

Available languages

Quick Links

Solar Charge Controller
SUPPORT
If
you are experiencing technical problems and cannot find a solution in this manual,please
contact ECO-WORTHY for further assistance.
·Call:1-866 939 8222(US)
·Email: customer.service@eco-worthy.com
12V/24V 30A
User Manual
Batt
12V
+44 20 7570 0328(UK)
132
Bulk
V
+49 693 1090 113(DE)
Version: 1.0

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOS 30-U and is the answer not in the manual?

Questions and answers

Summary of Contents for ECO-WORTHY ECOS 30-U

  • Page 1 12V/24V 30A Solar Charge Controller User Manual Bulk Batt SUPPORT you are experiencing technical problems and cannot find a solution in this manual,please contact ECO-WORTHY for further assistance. ·Call:1-866 939 8222(US) +44 20 7570 0328(UK) +49 693 1090 113(DE) ·Email: customer.service@eco-worthy.com...
  • Page 3: Table Of Contents

    Contents ..........1 Safety Precautions ...........1 Product Overview ..........2 Key Features ............2 Installation ........3 Description of Icons ........4 Description of Pages ............5 Setting ..........6 How To Setup ..........9 Specifications ..........10 Output Mode ..........11 Error Codes ...........12 Troubleshooting...
  • Page 4: Safety Precautions

    Safety Precautions ● Read and save this manual carefully before installation. ● DO NOT try to open or repair the controller. ● Cut off power supply before installing the controller. ● Install the controller indoors and keep it dried and well-ventilated. ●...
  • Page 5: Key Features

    Key Features Reverse connection protection ● Short-circuit protection ● Auto reduce power when product is overheated ● Over current protection ● Under and over voltage protection ● Installation 1. Measure and drill 4*6mm holes on the wall. Install the control- ler with M4 self drilling screws and make them tightened.
  • Page 6: Description Of Icons

    3. Check to ensure all cables are wired correctly. First connect battery to the controller then solar panels, the controller will get started automatically. Description of Icons Icon Name Status Description Daytime(PV in) Nighttime(No PV) Battery Battery status indication Charging Battery is charging DC load is on Output...
  • Page 7: Description Of Pages

    Description of Pages Change parameters with " " and " " buttons. Home Page: battery voltage Page 1: Solar panel voltage Page 8: Output mode Page 2: Charging current Page 7: 30 days total power generation Page 3: Battery voltage Page 6: Today's total power generation Load Page 4: load current...
  • Page 8: Setting

    Setting Charging Parameters Tip: The following settings work for 12V battery. All values need to be doubled when a 24V battery is connected. Battery Type FLD(Default) LiFePO4 (FLP) Default 14.6V Default 14.5V Bulk Charge 14.6V 14.4V 14.2V (adjustment range 9.8-14.8V) (adjustment range 9.8-14.8V) Voltage Default 14.8V...
  • Page 9: How To Setup

    How To Setup Long press the button for 3S to the Setting Page. Short press the button to choose different Setting Page. The changeable number on the page will flash. Change it with " " and " " buttons. Any Setting Page with 5S of inactivity will go back to the Home Page. Choose battery type LFP Battery SLD Battery...
  • Page 10 CUS mode: default 14.8V (adjustment range 9.8-14.8V) Absorb Charge Voltage (CUS Only) Default 120min (adjustment range 0-180min) Absorb Charge Time (CUS Only) CUS mode: default 13.8V (adjustment range 9.6-14.6V) Float Change Voltage(CUS Only) LFP mode: default 11.2V (adjustment range 9-14V) CUS mode: default 11.2V (adjustment range 9-14V) Over Discharge Voltage LFP mode: default 13.0V (adjustment range 9.6-14.6V)
  • Page 11 Default 14.6V (adjustment range 9.6-14.8V) Overcharge Recovery Voltage (CUS Only) All Battery Mode:default 16 (adjustment range 0-17) Output Mode Temperature Unit...
  • Page 12: Specifications

    Specifications Product Model ECOS 30-U Max Charging Current System Voltage 12/24V Auto Recognition Battery Type FLD,LFP,SLD,GEL,CUS (FLD by default ) Max PV Input Voltage 25V@12V;50V@24V Max Output Current USB Port 5V/2A *2 Size 150*94*33mm Weight 240g Self Dissipation <15mA(12/24V) Cable AWG 8AWG(10mm2)...
  • Page 13: Output Mode

    Output Mode Control Mode Description Number Turn on the load when solar panel stops generating ①Exclusive Light Control power; turn off the load when solar panel restarts. When solar panel stops generating power, turn on the ②Light&Time Control load and keep it for 1 hour When solar panel stops generating power, turn on the ②Light&Time Control load and keep it for 2 hour...
  • Page 14: Error Codes

    Error Codes Battery is Overvoltage Battery is Over-discharge PV input is Overvoltage PV input is Overcurrent Output is Over current Internal is Overtemperature Load short-circuit protection PV short-circuit protecition -11-...
  • Page 15: Troubleshooting

    Troubleshooting Fault Solution Test the voltage of the battery terminal with a Screen and LED multimeter. If the voltage reading is 10~60V and the indicator is off, contact the supplier for repairing. indicator won’t turn on Check the wring, fuse and breaker. Check the wring, fuse and breaker.
  • Page 16 ECO-WORTHY Tel(DE): +49 693-1090-113 customer.service@ www.eco-worthy.com Tel(US): 1-866-939-8222 eco-worthy.com Tel(UK): +44 20 7570 0328...
  • Page 17 Bulk Batt UNTERSTÜTZUNG Wenn Sie technische Probleme haben und in diesem Handbuch keine Lösung finden können, wenden Sie sich bitte an öko-würdig, um weitere Unterstützung zu erhalten. ·Call:1-866 939 8222(US) +44 20 7570 0328(UK) +49 693 1090 113(DE) ·Email: customer.service@eco-worthy.com...
  • Page 19 Inhalt ........1 Sicherheitsvorkehrungen ..........1 Produktübersicht ..........2 Hauptmerkmale ...........2 Installation .........3 Beschreibung der Symbole ........4 Beschreibung der Seiten ...........5 Einstellung ........6 Wie stellt man das ein ..........9 Spezifikationen ...........10 Ausgangsmodus ..........11 Fehlercodes ...........12 Fehlerbehebung...
  • Page 20: Sicherheitsvorkehrungen

    Sicherheitsvorkehrungen ● Lesen Sie dieses Handbuch vor der Installation sorgfältig und speichern Sie sie sorgfältig. ● Versuchen Sie nicht, den Controller zu öffnen oder zu reparieren. ● Schneiden Sie die Stromversorgung vor, bevor Sie den Controller installie- ren. ● Installieren Sie den Controller in Innenräumen und halten Sie ihn getrocknet und gut belüftet.
  • Page 21: Hauptmerkmale

    Hauptmerkmale ● Umgekehrter Anschlussschutz ● Kurzschlussschutz ● Automatischer Strom reduzieren, wenn das Produkt überhitzt ist ● Über den aktuellen Schutz ● Unter- und Überspannungsschutz Installation 1. Messen und bohren Sie 4*6 mm Löcher an der Wand. Installieren Sie den Controller mit M4 -Selbstbohrschrauben und bringen Sie sie fest.
  • Page 22: Beschreibung Der Symbole

    3. Überprüfen Sie, ob alle Kabel korrekt verdrahtet sind. Schließen Sie zuerst die Batterie an den Controller an, und als Solarmodule startet der Controller automatisch. Beschreibung der Symbole Symbol Name Status Beschreibung Tag (PV in) Nacht (kein PV) Batterie Batteriestatusanzeige Ladung Batterie lädt Ausgabe...
  • Page 23: Beschreibung Der Seiten

    Beschreibung der Seiten Ändern Sie die Parameter mit den Schaltflächen " " und " ". Homepage: Batteriespannung Seite 1: Solarpanelspannung Seite 8: Ausgabemodus Seite 2: Aufladen aktuell Seite 7: 30 Tage Gesamtzahl der Stromerzeugung Seite 3: Batteriespannung Seite 6: Die heutige Gesamtleistungserzeugung Load Seite 4: Strom laden Seite 5: Interne Temperatur des Controllers...
  • Page 24: Einstellung

    Einstellung Ladeparameter Tipp: Die folgenden Einstellungen funktionieren für 12 -V -Akku. Alle Werte müssen verdoppelt werden, wenn eine 24 -V -Batterie angeschlossen ist. Akku-Typ LiFePO4 (FLP) FLD (Standard Standard 14,6 V Standard 14,5 V Schüttladung 14,6V (Einstellbereich 9,8-14,8 V) (Einstellbereich 9,8-14,8 V) Stromspannung Standard 14,8 V Gleichstellung...
  • Page 25: Wie Stellt Man Das Ein

    Wie stellt man das ein Drücken Sie die Taste für 3s auf die Einstellseite. Kurz gesagt, drücken Sie die Taste, um eine unterschiedliche Einstellungsseite auszuwählen. Die veränderbare Nummer auf der Seite blinkt. Ändern Sie es mit " " und " "...
  • Page 26 CUS-Modus: Standard 14,8 V (Einstellbereich 9,8-14,8 V) Ladungsspannung absorbieren (Nur CUS) Standard 120 min (Einstellbereich 0-180 min) Ladungszeit absorbieren (Nur CUS) CUS-Modus: Standard 13,8 V (Einstellbereich 9,6-14,6 V) Schwimmerwechselspannung (Nur CUS) LFP-Modus: Standard 11,2 V (Einstellbereich 9-14 V) CUS-Modus: Standard 11,2 V (Einstellbereich 9-14 V) Überflussspannung LFP-Modus: Standard 13,0V (Einstellbereich 9,6-14,6 V) CUS-Modus: Standard 12,2 V (Einstellbereich 9,6-14,6 V)
  • Page 27 Standard 14,6 V (Einstellbereich 9,6-14,8 V) Überladungsrückgewinnungsspannung (Nur CUS) Der gesamte Batteriemodus: Standard 16 (Einstellbereich 0-17) Ausgangsmodus Temperatureinheit...
  • Page 28: Spezifikationen

    Spezifikationen Produktmodell ECOS 30-U Max Ladestrom Systemspannung 12/24V Autoerkennung FLD, LFP, SLD, GEL, CUS Akku-Typ (FLD standardmäßig) Max PV -Eingangsspannung 25V@12V; 50V@24 V Maximaler Ausgangsstrom USB-Anschluss 5V/2A Größe 150*94*33 mm Gewicht 240g Selbstaufteilung <15 mA (12/24 V) Kabel AWG 8AWG (10mm2)...
  • Page 29: Ausgangsmodus

    Ausgangsmodus Steuermodus Beschreibung Nummer Schalten Sie die Last ein, wenn die Solarpanel nicht mehr Strom ①Exclusive Lichtsteuerung erzeugt. Schalten Sie die Last aus, wenn die Solarpanel neu startet. Wenn die Solarpanel nicht mehr Strom erzeugt, schalten Sie die Last ②Light & Time Control ein und halten Sie sie 1 Stunde lang auf Wenn die Solarpanel nicht mehr Strom erzeugt, schalten Sie die ②Light &...
  • Page 30: Fehlercodes

    Fehlercodes Die Batterie ist Überspannung Der Akku ist überdacht PV -Eingang ist Überspannung Der PV -Eingang ist überstromig Die Ausgabe ist überstrom Intern ist die Übertemperatur Laden Sie den Kurzschlussschutz PV-Kurzschlussschutz -11-...
  • Page 31: Fehlerbehebung

    Fehlerbehebung Fehler Lösung Testen Sie die Spannung des Batterieklemmens mit Bildschirm und LED einem Multimeter. Wenn der Spannungswert 10 bis -Indikator werden nicht 60 V beträgt und der Indikator ausgeschaltet ist, wenden Sie sich an den Lieferanten zur Reparatur. eingeschaltet Überprüfen Sie Wring, Fuse und Breaker.
  • Page 32 ECO-WORTHY Tel(DE): +49 693-1090-113 customer.service@ www.eco-worthy.com Tel(US): 1-866-939-8222 eco-worthy.com Tel(UK): +44 20 7570 0328...
