Gemo PC109X Quick Start Manual

GEMO
Attention, Risk of,
Danger, Warning
•
Dimensions
•
Panel Cut-out
•
Display
•
Sensor Type
•
Measuring Scale
•
Resolution
•
Accuracy
•
Timer Accuracy
•
Control Form
•
Heat Output
•
Alarm Output
•
Cold. Junc. Comp.
•
Line Compensation
•
Sensor Failure
•
Supply Voltage
•
Power Consumption : < 8VA
•
Humidity
•
Altitude
•
EMC
•
Safety
•
Protection Class
•
Operation Temp.
•
Storage Temperature : -10
•
Weight
•
Torque for screwing : Max. 0.5 N.m
WARNING:
if 2 wire Pt100 is used, connect compensation lead
to measuring lead:
(PC109X:17-18, PC107X: 13-14)
no: normally open
nc: normally closed
Do not use any solvents (alcohol, thinners, benzine, acid, etc.) or corrosive substances to clean
the device. Use only a dry and clean non-abrasive cloth. Before cleaning, disconnect the power
supply and mains connections.
Gürbüzoğlu Elektronik San. ve Tic. Ltd. Şti.
Çamlıtepe Cad. No:297 / 3-4 Siteler, Ankara, Türkiye
Tel: +90-312-3503900, Fax: +90-312-3511117
AUTO-TUNE PID TEMPERATURE STEP CONTROLLER
High Voltage,
Risk of Electric Shock
TECHNICAL SPECIFICATION
: PC109X:96x96, PC107X:72x72mm
: PC109X:91x91, PC107X:68x68mm
: 4 Digits 7 Segment (PV), 4 digits 7 Segment (SV)
: J,K,T,S,R type T/C, Pt100 selectable
o
: -100..600 C, J type T/C (Inpt=J),
o
-100..1300 C, K type T/C (Inpt=k), -100.0..999.9
o
-100..400 C, T type T/C (Inpt=t),
o
0..1750 C, S type T/C (Inpt=S)
o
-100..600 C, Pt100, (Inpt=Pt)
o o
: ± 1 C or ± 0.1
: ± 1 % (Over full scale)
: ± % 1.5 (of timer set value)
: ON-OFF or P, PI, PD, PID - selectable
: Relay (NO + NC), 250VAC, 2A, Resistive load, (optional SSR)
: Relay (NO + NC), 250VAC, 2A, Resistive load
o
: 0 .. 50 C (T/C)
: 10 Ohm max. (3 wire Pt100)
: OUT output is active according to P.Err and Ct parameters in case of
sensor failure, measurement out of range or hardware fails to measure
input signal (OUT output is OFF if Perr is 0). For Alarm look "Alarm Output".
: 100..240VAC, 50-60Hz or 24VDC/AC (isolation voltage: 40VAC max.)
: < 70% (non-condensing)
: < 2000 m
: EN 61000-6-1, EN 61000-6-3 (Only light industrial environment)
: EN 61010-1; Pollution degree 1, measurement category I, (Only light industrial
environment, double/reinforced isolated, non-conductive pollution environment)
: IP20; according to EN 60529
o
: 0 .. 50 C
o o
C .. 60 C (no icing)
: < 0.5 kg
CLAEANING
Double / Reinforced
Insulation
-100.0 .. 600.0
-100.0 .. 400.0
0 .. 1750
-100.0 .. 600.0
C
1
PC109X / PC107X
NOT CE Mark
Litter
o
C, J type T/C (Inpt=J.0)
o
C, K type T/C, (Inpt=k.0)
o
C, T type T/C (Inpt=t.0)
o
C, R type T/C (Inpt=r)
o
C, Pt100, (Inpt=Pt.0)
http://www.gemo.com.tr.
e-mail: info@gemo.com.tr
