InTemp® CX5500 Cellular Gateway Manual
InTemp CX5500
Cellular Gateway
Included Items:
• Mounting kit
• AC adapter
• Cellular Antenna (2)
Required Items:
• InTempConnect
account
• InTemp app
• Device with iOS or
Android™ and
Bluetooth
• CX series loggers
Setting up the Gateway
Follow these instructions to set up the gateway in your current
location.
1. Set up roles on the InTempConnect website for
gateway privileges.
a. Go to www.intempconnect.com and follow the prompts
to set up an administrator account or skip to the next
step if you already have an account.
b. Log in to the account at www.intempconnect.com.
c. If you are an administrator or if you created the account
and you are setting up the gateway, skip to step 2; you
automatically have the required privileges. Otherwise,
create a role or edit an existing role to add the
privileges. Click System Setup and then Roles.
d. Click Add Role and select an existing role or complete
the Description field. Note: You must be an
InTempConnect administrator or a user with Manage
Users and Roles privileges to add a Role.
e. Select privileges from the Available Privileges list on the
left and click the right arrow to move them to the
Assigned Privileges list on the right as shown in this
example.
29023-A
The InTemp CX5500 Gateway uses Bluetooth® Low Energy (BLE) to regularly configure and
download data from InTemp CX series loggers and upload the data to the InTempConnect®
website automatically using cellular connectivity. The gateway requires an InTempConnect
website account with gateway privileges and a phone or tablet with the InTemp app installed to
set up the gateway.
Specifications
Transmission Range Approximately 30.5 m (100 ft) line-of-sight
Wireless Data Standard Bluetooth 4.2 (BLE)
Connectivity Cellular Cat 1 LTE with 2G/3G fallback
Power Source AC adapter
Dimensions 12.7 x 12.7 x 2.99 cm (5.0 x 5.0 x 1.18 inches)
External Antennae: 3.81 x 19.58 cm (1.5 x 7.71 inches)
Weight 680 g (24 oz)
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU).
Gateway
Description
Privilege
Create Set up shipments of loggers using the
Shipments gateway.
Download Now Download data from the logger with a
and Continue gateway immediately and then
continue logging.
Download Now Download data from the logger with a
and Restart gateway immediately and then restart
the logger.
Download Now Download data from the logger with a
and Stop gateway immediately and then stop
logging.
Edit/Delete Change or delete planned shipments of
Shipments loggers using the gateway.
Manage Logger/ Set up or edit a gateway profile in
Gateway Profiles InTempConnect.
Manage Monitor active gateways in
Gateways InTempConnect and configure loggers
with the gateway.
Gateway Set up and configure a gateway with
Administrator the InTemp app.
Select any other privileges you want the user to have
(privileges for the InTempConnect website are noted
with a cloud icon and privileges for the InTemp app
are noted with a mobile device
f. Select a user for this role and click Save. Or, if you need
to add a user, click Save and then click System Setup >
Users. Click Add User and enter the email address and
first and last name of the user. Select the role with the
gateway privileges for the user and click Save.
Tip: You can assign these roles to the same user or different
users.
icon).
