InTemp CX5001 Gateway Quick Start Guide
®
I am setting up a CX5001 gateway to automatically
download CX loggers to the InTempConnect
1
Go to www.intempconnect.com to set up an
account or log into your existing account (A).
2
In InTempConnect, select System Setup and then Roles.
Click Add Role (A) to create a role for the person who is
setting up the gateway or click an existing role to edit it.
A
3
Type the name of the role (A) for the Description. Select
Login to InTempConnect and the gateway-related
privileges (Manage Gateways, Manage Logger/Gateway
Profi les, and Gateway Administrator) from the Available
Privileges list on the left and click the right arrow button
(B) to move them to the Assigned Privileges list on the
right. Select a user from the Available Users list on the
left and click the right arrow button (C) to move the user
to the Assigned Users list on the right. Click Save (D).
A
D
To add a user, select Users from the System Setup menu, then
clilck Add User, complete the fi elds, and assign the user a role
with gateway privileges.
26286-C MAN-CX5001-QSG
A
B
C
®
cloud.
Connect
4
Click Gateways and then Gateway Profi les. Click Add
Gateway Profi le and type a name (A) for the profi le.
Select the CX logger types you plan to use with the
gateway. Select any of the following options that best
meet your specifi c gateway application needs (B):
• Immediately connect to any logger not seen by this
gateway.
• Immediately connect and download to a logger any
logger with a new sensor alarm.
• Immediately connect to any logger with a low battery
alarm (CX400 and CX450 loggers only).
• Immediately connect to and download any loggers
that have been stopped and are no longer recording
data (CX500, CX600, and CX700 loggers only).
• Select a time to Enable reverse logistics for shipment
loggers after (Shipping applications only).
• Click Save (C).
A
B
C
Refer to the full product manual for details on other confi guration settings.
Go to www.onsetcomp.com/intemp/resources/documentation/21781-
cx5000-gateway-manual.
5
Insert the appropriate plug for your
region into the AC adapter. Connect
the AC adapter to the gateway and
plug it in. Wait a couple of minutes
for the gateway to completely power
up. The LED on the gateway will be
yellow-green while it powers up and
then change to deep green once it is
ready to set up.
Connect
Connect
Mobile
Mobile
Upload Data from the Logger
to the Cloud via the Gateway
