Onset InTemp CX5000 Quick Start

Quick Start for the InTemp
I am setting up a CX5000 gateway for automatic
download of CX loggers to the InTempConnect
cloud.
1
Go to www.intempconnect.com to set up an
account or log into your existing account (A).
2
In InTempConnect, click Settings and then Roles.
Click Add Role (A) to create a role for the person
who will be setting up the gateway or click an
existing role to edit it.
A
3
Type the name of the role (A) for the Description.
Select "Login to InTempConnect" plus the gateway-
related privileges (Manage Gateways, Manage
Logger/Gateway Configs, Manage Shipments,
and Gateway Administrator) from the Available
Privileges list on the left and click the right arrow
button (B) to move them to the Assigned Privileges
list on the right. Select a user from the Available
Users list on the left and click the right arrow
button (C) to move the user to the Assigned Users
list on the right. Click Save (D).
A
D
Tip: If you need to add a user, click the Users tab and
then Add User, fill in the fields, and assign the user a role
with gateway privileges.
21853-F MAN-CX5000-QSG
CX5000 Gateway
®
A
B
C
®
Connect
Connect
Upload Data from the Logger
to the Cloud via the Gateway
4
Click Gateways and then Configuration Profiles.
Click Add Configuration Profile and type a name (A)
for the configuration. Select the CX logger type. If
the gateway will be used in a storage application
(i.e. a clinic or office), enter these settings (B):
• Select Download and Restart for when to
connect.
• Select "Immediately connect to a logger with
a new sensor alarm."
• DO NOT select "Immediately connect to a
logger not seen by this gateway."
• Choose to connect to loggers every week.
Click Save (C).
A
B
C
Tip: Refer to the full product manual for details on other
configuration settings. Go to www.onsetcomp.com/intemp/
resources/cx5000-manual.
5
Insert the appropriate plug for your region into
the AC adapter. Connect the AC adapter to the
gateway and plug it in. Wait a couple of minutes
for the gateway to completely power up. The
LED on the gateway will be yellow-green while it
powers up and then change to deep green once it
is ready to set up.
Connect
Mobile
Mobile
