Specifications - SMC Networks EZ Connect Turbo SMC2435W Datasheet

Specifications

Data Rate
•
Up to 22Mbps with Auto
Fallback to 11/5.5/2/1 Mbps
Operating Range
•
Up to 352m
(distance performance may be effected
by variables such as barrier composition
and local environment interference)
Network Configuration
•
Ad-Hoc (Peer to Peer)
•
Infrastructure
Radio Signal Type
•
Direct Sequence Spread Spectrum (DSSS)
Media Access Protocol
•
CSMA/CA (Collision Avoidance)
with ACK
Security
•
64-/128-/256-bit Wired
Equivalent Privacy (WEP)
RF Frequency
•
2471MHz – 2497 MHz – Japan Band
•
2400MHz – 2483.5MHz – North
America, Europe and Extended
Japan Band
•
2455MHz – 2475MHz – Spain
•
2446.5MHz – 2483.5MHz – France
Operating Channel
•
11 Channels (US, Canada)
•
13 Channels (Europe)
•
14 Channels (Japan)
RF Output Power
•
16.5-18 dBm
Sensitivity
•
-80 dBm @ 22 Mbps
•
-84 dBm @ 11Mbps
•
-87 dBm @ 5.5 Mbps
•
-90 dBm @ 2 Mbps
•
-92 dBm @ 1 Mbps
Frequency Stability
•
Within + 25 ppm
Data modulation type
•
BPSK (1Mbps)
•
QPSK (2Mpbs)
•
CCK (5.5/11Mbps)
•
PBCC (5.5/11/22 Mbps)
Operating Systems
•
Windows 98/ME/2000/XP
Antenna Gain
•
2 dBi max.
SMC Networks Europe
Head Offi ce
Edifi cio Conata II
Fructuós Gelabert 6-8 20, 4a
08970 - Sant Joan Despi
Barcelona
Spain
Telephone: +34 93 477 4920
Facsimile: +34 93 477 3774
SMC Networks Central Europe
Telephone: +49 (0) 89 92861-0
Facsimile: +49 (0) 89 92861-230
SMC Networks CIS
Telephone: +7 095 789 35 73
Facsimle: +7 095 789 35 73
SMC Networks Denmark
Telephone: +45 (0) 566 62283
Facsimile: +45 (0) 566 62286
SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their respective holders. © Copyright 2002 SMC Networks, Inc.
Antenna Type
•
Built in diversity patch antenna
LED Indicators
•
Power/TX/RX
Power Voltage
•
3.3 or 5 Volt + 5%
Power Consumption
•
650 mA by TX (Max)
•
350mA by RX
Dimension
•
128 x 54 x 9.6 mm
Weight
•
181g
Interface
•
CARDBUS PCMCIA Type II
Compliance
•
USA: FCC Part 15 Class B and C
•
Europe: ETSI EN 300 328-2 and ETSI EN
301 489-1, -17, EN60950, CE-Mark
•
Canada: ISC RSS139
•
Japan: Telec RCR STD 33, T66; JETA
•
WiFi Compliant
Temperature Range
•
Operating: -0 C - +60 C
•
Storage: -20 C - +70 C
Humidity
•
Operating: 0% to 70%
•
Storage: 0% to 95% Noncondensing
Standards
•
IEEE 802.11b
Warranty
•
Limited Lifetime
SMC Networks Eastern Europe SMC Networks Sub-Saharan Africa
Telephone: +49 (0) 89 92861 142 Telephone: +27 113 14 48 73
Facsimile: +49 (0) 89 92861-230 Facsimile: +27 113 14 91 33
SMC Networks Italia SMC Networks South-East Europe
Telephone : +39 (0)33 55 70 86 02 Telephone: +49 (0) 89 74 08 00 80
SMC Networks Netherlands Facsimile: +49 (0) 89 74 08 00 81
Telephone: +31 627 075227 SMC Networks Southern Europe
Facsimile: +31 334 557 330 Telephone: +33 (0) 1 41 38 32 32
SMC Networks Nordic Facsimile: +33 (0) 1 41 38 01 58
Telephone: +46 (0) 8 687 0700 SMC Networks Spain and Portugal
Facsimile: +46 (0) 8 87 62 62 Telephone: +34 (0) 636 2043
SMC Networks Northern Europe Facsimile: +34 (0) 636 2044
Telephone: +44 (0)118 974 8700 SMC Switzerland
Facsimile: +44 (0)118 974 8701 Telephone:+41 (0) 19409971
SMC Networks North West Africa Facsimile:+41 (0) 19409972
Telephone: +216 71 23 66 16
Facsimle:+216 71 75 14 15
EZ Connect™
SMC2435W
Turbo 11/22 Mbps Auto-
Sensing Wireless Cardbus
Adapter
